气体止推箔片轴承试验台设计及试验

徐方程; 刘占生; 张广辉; 张雯; 孙毅

doi:10.13224/j.cnki.jasp.2016.09.032

气体止推箔片轴承试验台设计及试验

doi: 10.13224/j.cnki.jasp.2016.09.032

1. 哈尔滨工业大学能源科学与工程学院, 哈尔滨 150001;
2. 中国航天科技集团公司中国运载火箭技术研究院, 北京 100076;
3. 哈尔滨工业大学航天学院, 哈尔滨 150001

基金项目:

国家自然科学基金（11572098）

详细信息

作者简介:
徐方程(1985-),男,浙江金华人,副教授,博士后,主要研究方向为气体箔片轴承、挤压油膜阻尼器及转子动力学等.

中图分类号: V229⁺.2;TH133.37
计量
- 文章访问数: 1043
- HTML浏览量: 83
- PDF量: 534
- 被引次数: 0
出版历程
- 收稿日期: 2015-02-11
- 刊出日期: 2016-09-28

Test rig design and experiment of gas thrust foil bearing

1. School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China;
2. China Academy of Launch Vehicle Technology, China Aerospace Science and Technology Corporation, Beijing 100076, China;
3. School of Astronautics, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 设计并制造了带有箔片密封式活塞加载装置的气体止推箔片轴承试验台，对带有冷却通道和径向辐射分布波纹箔片的止推箔片轴承进行了试验研究，分别在15000，20000，25000r/min转速下采用摩擦力矩法对带有冷却通道的止推箔片轴承进行了承载力测试试验.结果表明：带有箔片密封结构的活塞式加载装置能够很好地实现止推轴承加载功能，验证了试验台设计的成功，该止推箔片轴承在不同转速下分别得到了145，195，260N的推力，并且轴承承载力和气膜间隙成非线性关系.
- 箔片密封 /
- 活塞 /
- 气体止推箔片轴承 /
- 摩擦力矩 /
- 承载力
Abstract: A gas thrust foil bearing test rig was designed and manufactured, and a piston loading mechanism with a foil seal was used to apply the load to thrust foil bearing. A thrust foil bearing with cooling air channels and radial radiation distribution bump foil was tested. The bearing load capacity at the speed of 15000, 20000, 25000r/min was measured by using friction torque method. Results show that the piston loading mechanism with this foil seal structure can supply enough load to the thrust foil bearing and the successful test rig design was certificated. Moreover, this type thrust foil bearing can achieve 145,195,260N respectively at these different speeds. The bearing load capacity has a nonlinear relationship with gas film thickness.
- foil seal /
- piston /
- gas thrust foil bearing /
- friction torque /
- load capacity

HTML

参考文献(19)

[1]	Walowit J A,Anno J N.Modern developments in lubrication mechanics[M].London:Applied Science Publishers Limited,1975.
[2]	Heshmat H,Walowit J A,Pinkus O.Analysis of gas-lubricated foil journal bearings[J].Journal of Lubrication Technology,1983,105(4):647-655.
[3]	Heshmat H,Walowit J A,Pinkus O.Analysis of gas-lubricated complaint thrust bearings[J].Journal of Lubrication Technology,1983,105(4):638-646.
[4]	Roger K C P,Heshmat H.Compliant foil bearing structural stiffness analysis:Part I theoretical model including strip and variable bump foil geometry[J].Journal of Tribology,1992,114(2):394-400.
[5]	Ruscitto D,McCormick J,Gray S.Hydrodynamic air lubricated compliant surface bearing for an automotive gas turbine engine:I journal bearing performance[R].NASA CR-135368,1978.
[6]	Peng Z C,Khonsari M M.Hydrodynamic analysis of compliant foil bearings with compressible air flow[J].Journal of Tribology,2004,126(3):542-546.
[7]	Peng Z C,Khonsari M M.On the limiting load-carrying capacity of foil bearings[J].Journal of Tribology,2004,126(4):817-818.
[8]	Andrés L S,Kim T H.Improvements to the analysis of gas foil bearings integration of top foil 1D and 2D structural models[R].ASME Paper GT2007-27249,2007.
[9]	Kim D,Ki J,Kim Y,et al.Extended three-dimensional thermo-hydrodynamic model of radial foil bearing:case studies on thermal behaviors and dynamic characteristics in gas turbine simulator[J].Journal of Engineering for Gas Turbine and Power,2012,134(5):052501.1-052501.13.
[10]	Kim T H,Sim K.Thermohydrodynamic analysis of bump-type gas foil bearings using bump thermal contact and inlet flow mixing models[J].Tribology International,2012,48:137-148.
[11]	Roger K C P.Dynamic structural properties of compliant foil thrust bearings-comparison between experimental and theoretical results[J].Journal of Tribology,1994,116(1):70-75.
[12]	Iordanoff I.Analysis of an aerodynamic compliant foil thrust bearing:method for a rapid design[J].Journal of Tribology,1999,121(4):816-822.
[13]	Heshmat C A,Xu D S,Heshmat H.Analysis of gas lubricated foil thrust bearings using coupled finite element and finite difference methods[J].Journal of Tribology,1999,121(1):199-204.
[14]	Park D J,Kim C H,Jang G H,et al.Theoretical considerations of static and dynamic characteristics of air foil thrust bearing with tilt and slip flow[J].Tribology International,2008,41(4):282-295.
[15]	Lee D,Kim D.Design and performance prediction of hybrid air foil thrust bearings[J].Journal of Engineering for Gas Turbine and Power,2011,133(4):042501.1-042501.13.
[16]	Conboy T M.Real-gas effects in foil thrust bearings operating in the turbulent regime[J].Journal of Tribology,2013,135(3):031703.1-031703.12.
[17]	Hryniewicz P,Locke D H,Heshmat H.New-generation development rigs for testing high-speed air-lubricated thrust bearings[J].Tribology Transactions,2003,46(4):556-559.
[18]	Dykas B, Bruckner R,DellaCorte C,et al.Design,fabrication,and performance of foil gas thrust bearings for microturbomachinery applications[J].Journal of Engineering for Gas Turbines and Power,2009,131(1):012301.1-012301.8.
[19]	Lee Y B,Kim T Y,Kim C H,et al.Thrust bump air foil bearings with variable axial load:theoretical predictions and experiments[J].Tribology Transactions,2011,54(6):902-910.
