考虑接触热阻的非连续转子快速启动热分析

徐宁; 王庆超; 王震林; 刘占生

doi:10.13224/j.cnki.jasp.2017.12.011

考虑接触热阻的非连续转子快速启动热分析

doi: 10.13224/j.cnki.jasp.2017.12.011

1.
哈尔滨工业大学能源科学与工程学院，哈尔滨 150001；中国船舶重工集团公司哈尔滨船舶锅炉涡轮机研究所，哈尔滨 150078
2.
哈尔滨工业大学能源科学与工程学院，哈尔滨 150001

基金项目: 青年科学基金(11602071)

计量
- 文章访问数: 873
- HTML浏览量: 124
- PDF量: 539
- 被引次数: 0
出版历程
- 收稿日期: 2016-09-02
- 刊出日期: 2017-12-28

Thermal analysis for fast start up of noncontinuous rotor considering thermal contact resistance

摘要

摘要: 针对燃气轮机转子非连续性的结构特点，通过考虑粗糙表面的接触热阻，建立了螺栓联接结构的热结构耦合分析模型。研究了快速启动过程中轮毂间接触面上的温度分布及最大应力的变化规律，并分析了表面粗糙度和预紧力等接触参数对接触面间的温度分布、拉紧力及最大应力的影响。结果表明：热冲击下粗糙表面间的接触热阻对接触面的温度分布及最大应力影响明显，接触参数对螺栓联结结构的温度场、应力场及热变形特性影响较大。研究成果可为燃气轮机转子设计、热致振动分析及故障诊断提供理论依据。
- 非连续转子 /
- 接触热阻 /
- 螺栓联结结构 /
- 快速启动 /
- 热结构耦合
Abstract: The thermalstructure coupling analysis for bolted connection was modeled according to the structural features of noncontinuous rotor, taking thermal contact resistance of rough surface into account. The timevarying relationship of temperature distribution and maximum stress during the fast startup of the turbine was investigated. The influence of contact properties, such as roughness and pretightened force, on temperature distribution, tensioning force and maximum stress was analyzed. Results indicated that, the thermal contact resistance had great influence on temperature distribution of contact surface and maximum stress of bolted connection under the thermal impact, the contact property had influence on temperature distribution, deformation distribution and maximum stress. The research provides theoretical basis for the design of gas turbine, contributing to the analysis of thermally induced vibration and fault diagnosis.
- non-continuous rotor /
- thermal contact resistance /
- bolted connection structure /
- fast start up /
- thermalstructure couple

HTML

参考文献(15)

[1]	THOMPSON B D,GROBLER J.Development US Navy gas turbine vibration analysis expertise:LM2500 vibration and trim balance［C］∥Proceedings of ASME Turbo Expo:Turbine Technical Conference and Exposition.Copenhagen,Denmark:American Society of Mechanical Engineers,2012:243-253.
[2]	王安良,赵剑锋.接触热阻预测的研究综述［J］.中国科学（技术科学）,2011,41(5):545-556.WANG Anliang,ZHAO Jianfeng.Review of prediction for thermal contact resistance［J］.Science China（Technologica）,2011,41(5):545-556.(in Chinses)
[3]	FUKUOKA T.Finite element analysis of the thermal and mechanical behaviors of a bolted joint［J］.Journal of Pressure Vessel Technology,2005,127(4):402-407.
[4]	FUKUOKA T,NOMURA M,SHINO K.Analysis of heat flow around bolted joints and variations of axial bolt force［J］. Transactions of the Japan Society of Mechanical Engineers:Part A,2007,131(6):171-176.
[5]	THOMPSON M K.A multiscale iterative approach for finite element modeling of thermal contact resistance［D］.Cambridge:Massachusetts Institute of Technology,2007.
[6]	LU M,GENG H,XU G,et al.Analytical and experimental study of dynamic characteristics of rod fastened rotorbearing system under preload saturation［R］.ASME Paper GT2003-95397,2003.
[7]	ALBAN C,TOLSTYKH M,HILTY D,et al.Characterizing compressor rotor unclamp in a gas turbine engine［C］∥Proceedings of ASME Turbo Expo:Turbine Technical Conference and Exposition.Copenhagen,Denmark：American Society of Mechanical Engineers,2012:1083-1087.
[8]	YOVANOVICH M M.Four decades of research on thermal contact,gap,and joint resistance in microelectronics［J］.IEEE Transactions on Components and Packaging Technologies,2005,28(2):182-206.
[9]	YOVANOVICH M M,CULHAM J R,TEERTSTRA P.Calculating interface resistance［J］.Electronics Cooling,1997,3(2):24-29.
[10]	YNC H.Thermal contact conductance of nominaly flat surfaces［J］.Heat and mass transfer,2006,43(1):1-5.
[11]	BAHRAMI M,YOVANOVICH M M,CULHAM J R.Thermal joint resistances of conforming rough surfaces with gas filled caps［J］.Journal of Thermophysics and Heat Transfer,2004,18(3):318-325.
[12]	SRIDHAR M R,YOVANOVICH M.Review of elastic and plastic contact conductance models：comparison with experiment［J］.Journal of Thermophysics and Heat Transfer,1994,8(4):633-640.
[13]	ZHANG Y,DU Z,SHI L,et al.Determination of contact stiffness of rodfastened rotors based on modal test and finite element analysis［J］.Planta,2010,132(9):275-282.
[14]	HE P,LIU Z,WANG G,et al.Rotor dynamic analysis of tiebolt fastened rotor based on elasticplastic contact［R］.ASME Paper GT2011-45796,2011.
[15]	丁有宇,周宏利.汽轮机强度计算［M］.北京：水利电力出版社,1985.
