径向冷却通道截面特征长度对气冷稳定器性能影响

刘友宏; 罗一夫

doi:10.13224/j.cnki.jasp.2017.12.013

径向冷却通道截面特征长度对气冷稳定器性能影响

doi: 10.13224/j.cnki.jasp.2017.12.013

北京航空航天大学能源与动力工程学院，北京 100191

计量
- 文章访问数: 773
- HTML浏览量: 129
- PDF量: 457
- 被引次数: 0
出版历程
- 收稿日期: 2016-05-01
- 刊出日期: 2017-12-28

Effect of radial cooling channel sectional characteristic length on air cooled flameholder

摘要

摘要: 通过研究径向冷却通道截面特征长度的改变对气冷稳定器的冷态流场、冷却性能及流动损失的影响，为其进一步的优化设计提供参考依据。采用经过实验验证的CFD方法，对某气冷稳定器进行了数值模拟研究，在所研究的特征长度范围内，结果表明：特征长度的增加，减少了径向冷却通道下部的进气阻力，使得风兜引气率增加了667%；下部出气孔出流由于受到回流涡的影响，出流量明显低于上部出气孔，特征长度的改变对出流量分布的影响不大；特征长度的增加会加强径向稳定器近环形稳定器处的外壁面冷却效果，但是会减弱径向稳定器近中心锥处的外壁面冷却效果；特征长度的增加，使得出口总压恢复系数下降了0.086%，沿程总压恢复系数曲线向下移动。
- 截面特征长度 /
- 气冷稳定器 /
- 径向冷却通道 /
- 冷态流场 /
- 冷却性能 /
- 流动损失
Abstract: To study the impact of radial cooling channel section characteristic length change on air cooled flameholder cooled flow field, the cooling performance and flow loss, and also provide reference for further optimization design, a numerical simulation was performed by using an experimentally validated CFD method. Within the range of the characteristic length, the results indicated that, increasing the characteristic length reduced the lower portion intake resistance of radial cooling channel, so the air pocket entraining rate caused an increase of 667%. Due to the impact of vortex, the mass flow of the vent holes at the lower portion was significantly lower than that at the upper portion. Changing characteristic length had little effect on the mass flow distribution. Increasing the characteristic length enhanced the outer wall cooling effect of radial flameholder adjacent to the ring flameholder, but weakened the outer wall cooling effect of radial flameholder close to the inner cone. Due to the increase of the characteristic length, outlet total pressure recovery coefficient decreased by 0086% and total pressure recovery coefficient distribution curve along the afterburner moved downward.
- sectional characteristic length /
- air cooled flameholder /
- radial cooling channel /
- cooled flow field /
- cooling performance /
- flow loss

HTML

参考文献(15)

[1]	金莉,谭永华.火焰稳定器综述［J］.火箭推进,2006,32(1):30-34.JIN Li,TAN Yonglin.Study on flameholders［J］.Journal of Rocket Propulsion,2006,32(1):30-34.(in Chinese)
[2]	LOVETT J A,BROGAN T P,PHILIPPONA D S,et al.Development needs for advanced afterburner designs［R］.AIAA-2004-4192,2004.
[3]	张孝春,孙雨超,刘涛.先进加力燃烧室设计技术综述［J］.航空发动机,2014,40(2):24-30,60.ZHANG Xiaochun,SUN Yuchao,LIU Tao.Summary of advanced afterburner design technology［J］.Aeroengine,2014,40(2):24-30,60.(in Chinese)
[4]	RICHARD R,MARLBOROUGH C.Convectively cooled flameholder for premixed burner：US4073137［P］.1978-02-14.
[5]	MARIO E A.Gascooled flameholder assembly：US 5076062［P］.1991-12-31.
[6]	IVAN E W,JEFFREY C M,JOHN A M.Gas turbine engine ignition flameholder with internal impingement cooling：US5396761［P］.1995-03-14.
[7]	JEFFREY C M,JOHN A M.Cooled spraybar and flameholder assembly including a perforated hollow inner air baffle for impingement cooling an outer heat shield:US5396763［P］.1995-03-14.
[8]	FRANK A G,TIMOTHY J F,IVAN E W.Augmenter with integrated fueling and cooling:US5813221［P］.1998-09-29.
[9]	OLIVIER M M,XAVIER J P,JACQUES A M.Afterburner for a turbofan engine:US5400589［P］.1995-05-28.
[10]	JEANYVES C,FABRICE B,MICHEL,et al.Dispositif de post combustion dun turboréacteur:FR2709342［P］.1995-09-22.
[11]	FRDRIC B B,MICHEL A A D,ERIC C L L L.Optimally cooled,carbureted flameholder:US6112516［P］.2000-09-05.
[12]	刘涛,张志学,张孝春,等.新型气冷稳定器流场数值模拟研究［R］.沈阳:中国航空学会第14届燃烧与传热传质学术交流会,2007.
[13]	刘涛,张孝春,徐兴平,等.航空发动机加力燃烧室跨流气冷稳定器流场研究［J］.航空发动机,2014,40(3):29-33.LIU Tao,ZHANG Xiaochun,XUN Xingping,et al.Study on flowfield of air cooled flameholder for aetoengine afterburner［J］.Aeroengine,2014,40(3):29-33.(in Chinese)
[14]	《航空发动机设计手册》总编委会.航空发动机设计手册:第11册加力燃烧室［M］.北京:航空工业出版社,2001.
[15]	陈懋章.粘性流体动力学基础［M］.北京:高等教育出版社,2002.
