一种双S形二元排气系统红外特性的模型实验

王丁; 吉洪湖; 卢浩浩; 王浩

doi:10.13224/j.cnki.jasp.2017.12.020

一种双S形二元排气系统红外特性的模型实验

doi: 10.13224/j.cnki.jasp.2017.12.020

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 988
- HTML浏览量: 332
- PDF量: 469
- 被引次数: 0
出版历程
- 收稿日期: 2016-05-29
- 刊出日期: 2017-12-28

Experiment on infrared signature of a model of serpentine twodimensional exhaust system

摘要

摘要: 通过模型实验测量了一种双S形二元(2-D)喷管排气系统壁面压力和温度分布,以及分别在侧向、下方和上方探测面上的红外辐射强度分布,并与基准轴对称排气系统作了对比分析。实验结果表明:双S形二元喷管排气系统在上方探测面上,红外辐射强度比较大,最大值出现在10°探测角；相比基准轴对称排气系统,双S形二元排气喷管系统红外辐射强度在0°探测角方位平均降低了75.5%,在侧向、下方及上方探测面上90°探测角方位分别降低了57.6%、50.9%和17.3%。
- 排气系统 /
- 双S形二元喷管 /
- 红外辐射 /
- 红外抑制 /
- 模型实验
Abstract: The pressure and temperature distributions on the surface of a model of serpentine twodimensional（2D）nozzle exhaust system were measured, and its infrared radiation(IR) intensity on the side, lower and upper detection planes were also measured; these results were compared with those of a relevant axisymmetric exhaust system. The results showed that, the radiation intensity of serpentine 2D nozzle exhaust system on the upper detection plane was much higher than that on other two planes, with the maximum value at angle 10°; compared with axisymmetric exhaust system, the radiation intensity of serpentine 2-D nozzle exhaust system reduced by 75.5% at angle 0°, and 57.6%, 50.9% and 17.3% at angle 90° respectively on the side, lower and upper detection planes.
- exhaust system /
- serpentine twodimensional (2-D) nozzle /
- infrared radiation /
- infrared suppression /
- model experiment
