共轴刚性旋翼气动干扰及操纵特性分析

祁浩天; 史勇杰; 徐国华; 黄水林

doi:10.13224/j.cnki.jasp.2017.12.025

共轴刚性旋翼气动干扰及操纵特性分析

doi: 10.13224/j.cnki.jasp.2017.12.025

1.
南京航空航天大学直升机旋翼动力学国家级重点实验室，南京 210016
2.
中国航空工业集团公司中国直升机设计研究所，江西景德镇 333001

基金项目: 国家自然科学基金(11302103); 江苏高校优势学科建设工程基金

计量
- 文章访问数: 773
- HTML浏览量: 97
- PDF量: 500
- 被引次数: 0
出版历程
- 收稿日期: 2016-05-30
- 刊出日期: 2017-12-28

Analysis of aerodynamic interaction andtrim characteristics of rigid coaxial rotor

摘要

摘要: 建立了一套基于高效配平策略和嵌套网格技术的共轴刚性旋翼气动数值分析方法。流场求解采用雷诺平均NavierStokes方程，空间离散采用Roemonotone upstreamcentered schemes for conservation laws（MUSCL）格式，湍流模型为SpalartAllmaras模型；配平计算中引入“差量修正”策略。分析了共轴刚性旋翼模型在不同飞行状态下的气动干扰现象和操纵特性。结果表明：所建立的配平方法在同等精度下，比传统方法可显著节省计算时间；共轴刚性旋翼间距较小，其气动干扰明显强于普通共轴旋翼；悬停状态下，由于受上旋翼下洗流影响，下旋翼总距较大但拉力较小；小速度前飞时气动干扰引起下旋翼气流不对称性增大，双旋翼周期变距差也变大；采用适当的升力偏置量，可以提高共轴刚性旋翼气动效率。
- 共轴刚性旋翼 /
- 旋翼配平 /
- 气动干扰 /
- NavierStokes方程 /
- 嵌套网格
Abstract: A numerical method based on highefficient trim strategy and moving overset grid technique was developed to predict the aerodynamic characteristics of rigid coaxial rotor. To simulate the rotors flowfield, the Reynoldsaveraged NavierStokes equations were discretized by Roemonotone upstreamcentered schemes for conservation laws(MUSCL) scheme with SpalartAllmaras turbulence model. A delta trim method was implemented. Researches on the aerodynamic interaction and trim characteristics of a coaxial rigid rotor model were conducted. Results indicated that the delta method consumed much less time than the conventional trim method with the same accuracy. The aerodynamic interaction of rigid coaxial rotor, with a smaller rotors distance, was much stronger than that of normal coaxial rotor. In hover condition, the lower rotor required greater collective pitch while providing less tensile force due to the upper rotors downwash; in low speed forward flight, the aerodynamic interaction brought about a more asymmetrical airflow on the rotors disks, leading to greater difference of cyclic pitches. In addition, the rotors power efficiency can be improved by a proper lift offset.
- rigid coaxial rotor /
- rotor trim /
- aerodynamic interaction /
- NavierStokes equations /
- overset grid

HTML

参考文献(18)

[1]	CHENEY M C J R.The ABC helicopter［R］.AIAA 69-0217,1969.
[2]	COLEMAN C P.A survey of theoretical and experimental coaxial rotor aerodynamic research［R］.NASA-TP-3675,1997.
[3]	GESSOW A.Effect of rotorblade twist and planform taper on helicopter hovering performance［R］.NACA TN-1542,1948.
[4]	周国仪,胡继忠,曹义华,等.共轴式直升机双旋翼载荷计算模型研究［J］.航空动力学报,2003,18(3):343-347.ZHOU Guoyi,HU Jizhong,CAO Yihua,et al.Mathematical model for twin rotor loads of a coaxial helicopter［J］.Journal of Aerospace Power,2003,18(3):343-347.(in Chinese)
[5]	LEISHMAN J G,BHAGWAT M J,BAGAI A.Freevortex filament methods for the analysis of helicopter rotor wakes［J］.Journal of Aircraft,2002,39(5):759-775.
[6]	王强,陈铭,王保兵,等.旋翼几何参数对共轴双旋翼悬停性能的影响［J］.航空动力学,2014,29(6):1434-1443.WANG Qiang,CHEN Ming,WANG Baobing,et al.Effect of geometric parameters of rotor on hovering performance of coaxial rotor［J］.Journal of Aerospace Power,2014,29(6):1434-1443.(in Chinese)
[7]	童自力,孙茂.共轴式双旋翼气动力特性的计算研究［J］.航空学报,1999,20(4):348-350.TONG Zili,SUN Mao.NavierStokes analysis of the aerodynamic properties of coaxial rotors［J］.Acta Aeronautica et Astronautica Sinica,1999,20(4):348-350.(in Chinese)
[8]	许和勇,叶正寅.悬停共轴双旋翼干扰流动数值模拟［J］.航空动力学报,2011,26(2):453-457.XU Heyong,YE Zhengyin.Numerical simulation of interaction unsteady flows around coaxial rotors in hover［J］.Journal of Aerospace Power,2011,26(2):453-457.(in Chinese)
[9]	叶靓,徐国华.共轴式双旋翼悬停流场和气动力的CFD计算［J］.空气动力学学报,2012,30(4):437-442.YE Liang,XU Guohua.Calculation on flow field and aerodynamic force of coaxial rotors in hover with CFD method［J］.Acta Aerondynamica Sinica,2012,30(4):437-442.(in Chinese)
[10]	朱正,招启军,李鹏.悬停状态共轴刚性双旋翼非定常流动干扰机理［J］.航空学报,2016,37(2):568-578.ZHU Zheng,ZHAO Qijun,LI Peng.Unsteady flow interaction mechanism of coaxial rigid rotors in hover［J］.Acta Aeronautica et Astronautica Sinica,2016,37(2):568-578.(in Chinese)
[11]	LAKSHMINARAYAN V K,BADER J D.High resolution computational investigation of trimmed coaxial rotor aerodynamics in hover［J］.Journal of the American Helicopter Society,2009,54(4):42008-42031.
[12]	樊枫,徐国华,史勇杰.基于CFD方法的直升机旋翼/尾桨非定常气动干扰计算［J］.航空动力学报,2014,29(11):2633-2642.FAN Feng,XU Guohua,SHI Yongjie.Calculation of unsteady aerodynamic interaction between mainrotor and tailrotor of helicopters based on CFD method［J］.Journal of Aerospace Power,2014,29(11):2633-2642.(in Chinese)
[13]	ROE P L.Approximate riemann solvers,parameter vectors,and difference schemes［J］.Journal of Computational Physics,1981,43(2):357-372.
[14]	SPALART P R,ALLMARAS S R.A oneequation turbulence model for aerodynamic flows［R］.AIAA 92-0439,1992.
[15]	KIM J W,PARK S H,YU Y H.Euler and NavierStokes simulations of helicopter rotor blade in forward flight using an overlapped grid solver［R］.AIAA-2009-4268,2009.
[16]	DREES J M.A theory of airflow through rotors and its application to some helicopter problems［J］.Journal of the Helicopter Association of Great Britain,1949,3(2):79-104.
[17]	CROSS J L,WATTS M E.Tip aerodynamics and acoustics test:a report and data survey［R］.NASA-RP-1179,1988.
[18]	HARINGTON R D.Fullscaletunnel investigation of the staticthrust performance of a coaxial helicopter rotor［R］.NACA TN-2318,1951.
