典型阶梯篦齿高转速密封性能试验

王鹏飞; 郭文; 张靖周

doi:10.13224/j.cnki.jasp.2017.12.031

典型阶梯篦齿高转速密封性能试验

doi: 10.13224/j.cnki.jasp.2017.12.031

1.
南京航空航天大学能源与动力学院，南京210016；中国航空发动机集团有限公司四川燃气涡轮研究院，成都 610500
2.
中国航空发动机集团有限公司四川燃气涡轮研究院，成都 610500
3.
南京航空航天大学能源与动力学院，南京210016

计量
- 文章访问数: 766
- HTML浏览量: 145
- PDF量: 442
- 被引次数: 0
出版历程
- 收稿日期: 2016-05-07
- 刊出日期: 2017-12-28

Experiment on seal characteristics of high ratational speed of stepped labyrinth seals

摘要

摘要: 在高转速密封试验设备上，进行了实际尺寸阶梯篦齿压比(1.05～28)、相对密封间隙(齿尖密封间隙和齿宽比)(24～40)、泄漏流雷诺数(1900～28000)及旋转速度(0～12000r/min)等对密封性能影响的试验。结果显示：篦齿流量系数随压比变大而上升，随相对密封间隙变大而降低；转速低于5000r/min时，旋转对篦齿流量系数影响不明显，高转速、小压比时，篦齿流量系数随转速的升高而降低，降幅超过301%；较小雷诺数下，篦齿流量系数随雷诺数的减小快速降低，雷诺数超过6000以后，篦齿流量系数受雷诺数的影响不明显；气流通过阶梯篦齿第一道齿的压力损失最小，通过最后一道齿的压力损失最大，通过中间各齿的压力损失相当。基于试验测试数据，修正了典型阶梯篦齿流量系数的求解关系式，修正后的关系式计算值与实测值吻合良好。
- 空气系统 /
- 篦齿 /
- 密封性能 /
- 流量系数 /
- 压力分布
Abstract: Experiments were carried out to investigate the seal characteristics of real size models of a typical steppedlabyrinth seal. Flow coefficients of the labyrinth seal were obtained in a high speed experiment facility at different pressure ratios (105－28), relative sealing clearances (24－40), Reynolds numbers(1900－28000) and rotational speeds (0－12000r/min).Results indicated that the flow coefficient of labyrinth seal rose with the increase of pressure ratio, and decreased with a higher relative sealing clearance. No noticeable change of flow coefficient was found when the labyrinth seal ran under a rotational speed of 5000r/min. However, under high rotational speed and low pressure ratio conditions, the flow coefficient declined more than 301% as the operating speed went up. Moreover, under the conditions with lower Reynolds numbers, a rapid drop of flow coefficient was found with the decreasing Reynolds numbers. When the Reynolds numbers were larger than 6000, no clear effect on flow coefficients can be observed. Axial pressure distribution measurements showed that pressure drop reached its minimum and maximum values when air flowed through the first and the last seal tooth respectively, the pressure dropped through the remaining teeth were almost uniform. According to the findings, an empirical expression to evaluate flow coefficients of steppedlabyrinth seals was also obtained, and agreed with the experimental results perfectly.
- air system /
- labyrinth /
- seal characteristics /
- flow coefficients /
- pressure distribution

HTML

参考文献(18)

[1]	ZIMMERMANN H,WOLFF K H.Air system correlations：Part 1 labyrinth seals［R］.ASME Paper 98-GT-206,1998.
[2]	WITTIG S,KIM S.Scaling effects on leakage losses in labyrinth seals［J］.Journal of Engineering for Power,1983,105(2):305-309.
[3]	BRAUN E,DULLENKOPF K,BAUER H J.Optimization of labyrinth seal performance combining experimental numerical and data mining methods［R］.ASME Paper GT2012-68077,2012.
[4]	MORRISON G L,CHI D.Incompressible flow in stepped labyrinth seals［R］.ASME Paper 85-FE-4,1985.
[5]	SCHRAMM V,WILLENBORG K,KIM S,et al.Influence of a honeycomb facing on the flow field and discharge behavior of a stepped labyrinth seal［R］.ASME Paper 2000-GT-0291,2000.
[6]	WILLENBORG K,KIM S,WITTIG S.Effects of Reynolds number and pressure ratio on leakage loss and heat transfer in a stepped labyrinth seal［J］.Journal of Turbomachinery,2001,123(4):815-822.
[7]	MICHAUD M,VAKILI A,MEGANATHAN A.An experimental study of labyrinth seal flow［R］.Atlanta,Georgia :International Joint Power Conference,2003.
[8]	胡东旭,贾力,杨立新.篦齿封严泄漏特性的实验［J］.航空动力学报,2014,29(3):549-555.HU Dongxu,JIA Li,YANG Lixin.Experiment on leakage characteristics in labyrinth seal［J］.Journal of Aerospace Power,2014,29(3):549-555.(in Chinese)
[9]	WASCHKA W,WITTIG S,KIM S.Influence of high rotational speeds on the heat transfer and discharge coefficients in labyrinth seals［R］.ASME Paper 90-GT-330,1990.
[10]	LI Jun,YAN Xin,FENG Zhenping.Effects of pressure ratio and fin pitch on leakage flow characteristics in high rotating labyrinth seals［R］.ASME Paper 2006-GT-91145,2006.
[11]	PAOLILLO R,MOORE S,CLOUD D,et al.Impact of rotational speed on the discharge characteristic of stepped labyrinth seals［R］.ASME Paper GT2007-28248,2007.
[12]	王锁芳,吕海峰.转静态封严篦齿流场的数值分析和密封性能的试验［J］.航空动力学报,2005,20(3):445-449.WANG Suofang,L Haifeng.Numerical analysis of flow and experimental investigation of labyrinth sealing characteristics at rotational and static states［J］.Journal of Aerospace Power,2005,20(3):445-449.(in Chinese)
[13]	纪国剑,吉洪湖.阶梯篦齿与衬套轴向位置和转速对密封性能影响的实验［J］.航空动力学报,2008,23(3):421-424.JI Guojian,JI Honghu.Experimental investigation of effect of step axial location and rotating speed on leakage of stepped labyrinth［J］.Journal of Aerospace Power,2008,23(3):421-424.(in Chinese)
[14]	纪国剑,吉洪湖,曹广州.旋转对小间隙篦齿蜂窝结构密封性能的影响［J］.南京航空航天大学学报,2008,40(2):142-145.JI Guojian,JI Honghu,CAO Guangzhou.Effect of rotating speed on leakage characteristics of labyrinthhoneycomb seal with small clearance［J］.Journal of Nanjing University of Aeronautics and Astronautics,2008,40(2):142-145.(in Chinese)
[15]	YAN Xin,LI Jun,SONG Liming,et al.Investigations on the discharge and total temperature increase characteristics of the labyrinth seals with honeycomb and smooth lands［R］.ASME Paper GT2008-50399,2008.
[16]	王鹏飞,刘玉芳,郭文,等.直通式篦齿密封性能的数值分析和试验研究［J］.燃气涡轮试验与研究,2009,22(1):32-36.WANG Pengfei,LIU Yufang,GUOWen,et al.Numericalanalysis and experimental investigation of straightthrough labyrinth sealing characteristic［J］.Journal of Gas Turbine Experiment and Research,2009,22(1):32-36.(in Chinese)
[17]	王鹏飞,郭文,张靖周.旋转封严篦齿风阻温升的试验研究与数值分析［J］.航空动力学报,2013,28(6):1402-1408.WANG Pengfei,GUO Wen,ZHANG Jingzhou.Experimental investigation and numerical analysis of windage heating in rotating labyrinth seals［J］.Journal of Aerospace Power,2013,28(6):1402-1406.(in Chinese)
[18]	KOOL G A,KLOOSTERMAN A B,RADEMAKER E R,et al.Advanced seal test rig validation and operation［R］.ASME Paper 2006-GT-90915,2006.
