基元叶栅攻角特性多目标优化

成金鑫

doi:10.13224/j.cnki.jasp.2017.12.032

基元叶栅攻角特性多目标优化

doi: 10.13224/j.cnki.jasp.2017.12.032

成金鑫

北京航空航天大学能源与动力工程学院，北京 100191

基金项目: 国家自然科学基金（51576007）

计量
- 文章访问数: 930
- HTML浏览量: 236
- PDF量: 432
- 被引次数: 0
出版历程
- 收稿日期: 2016-05-06
- 刊出日期: 2017-12-28

Multiobjective optimization of incidence features for cascade

摘要

摘要: 采用多段Bezier曲线对轴流压气机叶型予以参数化表达，通过Isight优化平台，结合S1流面数值模拟分析，以改良的非支配排序遗传算法(NSGAⅡ)对美国NASA单级轴流跨声压气机Stage 35的动叶和静叶叶中截面基元叶栅进行攻角特性的多目标优化，优化目标是降低全攻角范围内的总压损失系数以及拓宽攻角适应性范围。以总压损失系数最小点以及总压损失系数相对最高点和最低点的差值作为优化目标函数，叶栅流量不变为约束条件。结果表明：优化显著降低了动、静叶叶中截面基元叶栅的总压损失系数，并使其攻角适应性范围分别拓宽了5°和3°。
- 基元叶栅 /
- 多目标 /
- 优化 /
- 总压损失系数 /
- 攻角特性
Abstract: MultiBezier curve was adopted to describe the cascade of the axial flow compressor in parameterized form. By taking the Isight software as optimization platform, the calculation program of the S1 surface was adopted to calculate the flow field, and the improved nondominated sorting genetic algorithm (NSGAⅡ) was employed to conduct the multiobjective optimization of the features of incidence for the cascade of the middle section of rotor and stator of Stage35, which was onestage axial flow transonic compressor from NASA. The optimization goal was to reduce the total pressure loss coefficient in the whole range of the incidence and widen the adaptive range of the incidence. The lowest total pressure loss coefficient and the difference between the relatively highest and the lowest point of total pressure loss coefficient were set as the optimization objective functions. The flow rate of the cascade constant was set as constraint. Results indicated that the optimization greatly reduced the total pressure loss coefficient of the cascade of the middle section of rotor and stator, and widened the range of the incidence of the middle section of rotor and stator by 5° and 3° respectively.
- cascade /
- multi-objective /
- optimization /
- total pressure loss coefficient /
- incidence features

HTML

参考文献(17)

[1]	SANFORD F,ROBERT B,MCCLURE,et al.A unique supersonic inlet unsteady aerodynamic cascade experiment［R］.AIAA 74-0622,1974.
[2]	YOUNG J B.Twodimensional nonequalibrium wetstream calculations for nozzles and turbine cascades［J］.Journal of Turbomachinery,1992,114(3):569-579.
[3]	JIRI B.Aerodynamic shape optimization of turbomachinery cascades［R］.AIAA 97-32475,1997.
[4]	MOHAMMADI B.Optimal shape design,reverse mode of automatic differentiation and turbulence［R］.AIAA 97-0099,1997.
[5]	HADRIEN M,MARC M,FRANCOIS G.Gradient span analysis method:application to multipoint aerodynamic shape optimization of a turbine cascade［R］.ASME Paper 2015-GT-091006,2015.
[6]	PIRONNEAU O.On optimum shapes in stokes flow［J］.Journal of Fluid Mechanics,1973,59(2):117-128.
[7]	JAMESON A.Aerodynamic design via control theory［J］.Journal of Computing,1988,3(3):233-260.
[8]	PINI M,PERSICO G,DOSSENA V.Robust adjointbased shape optimization of supersonic turbomachinary cascades［R］.ASME Paper 2014-GT-27064,2014.
[9]	SCHAFER O,FRUHAUF H,BAUER B,et al.Application of a NavierStokes analysis to flows through plane cascades［J］.Journal of Engineering for Gas Turbine and Power,1986,108(1):103-111.
[10]	ERNESTO B,CLAUDIO C,RITA P.Aerodunamic optimization of an impulse turbine cascade including laminar/turbulent transition prediction［R］.ASME Paper 2010-GT-22026,2010.
[11]	ZHANG Chaolei,FENG Zhenping.Aerodynamic shape design optimization for turbomachinery cascade based on discrete adjoint method［R］.ASME Paper 2011-GT-45805,2011.
[12]	LI Yingchen,FENG Zhenping.Threedimensional aerodynamic design of turbine blades using the adjoint method［R］.ASME Paper 2008-GT-51225,2008.
[13]	GU Chuangang,LUO Laiqin,MIAO Yongmiao.Experimental investigations of flows through a plane cascade at large angles of attack with separations［J］.Journal of Turbomachinery,1988,110(7):323-328
[14]	王正明,王嘉炜.动静叶栅优化改型及其性能分析［J］.工程热物理学报,2005,26(2):231-233.WANG Zhengming,WANG Jiawei.Optimization and performance analysis of stator and rotor cascades［J］.Journal of Engineering Thermophysics,2005,26(2):231-233.(in Chinese)
[15]	舒信伟,谷传纲,杨波,等.基于Pareto类遗传算法的基元叶栅多工况优化［J］.工程热物理学报,2008,29(4):599-601.SHU Xinwei,GU Chuangang,YANG Bo,et al.Cascade multipoint optimization based on paretoGA［J］.Journal of engineering thermophysics,2008,29(4):599-601.(in Chinese)
[16]	REID L,MOORE R D.Performance of singlestage axialflow transonic compressor with rotor and stator aspect ratios of 1.19 and 1.26,respectively,and with design pressure ratio of 1.82［R］.NASA TP-1338,1978.
[17]	王坤.基于吸力面型线调适的轴流压气机叶片造型方法研究［D］.北京:北京航空航天大学,2015.WANG Kun.Research on axialflow compressor blade modeling based on adjustment of suction curve［D］.Beijing:Beijing University of Aeronautics and Astronautics,2015.(in Chinese)
