旋转盘腔稳态换热试验的时间相关性

丁水汀; 赵罡; 邱天; 于航

doi:10.13224/j.cnki.jasp.2018.03.001

旋转盘腔稳态换热试验的时间相关性

doi: 10.13224/j.cnki.jasp.2018.03.001

1.
北京航空航天大学能源与动力工程学院北京市航空器/发动机复杂系统安全性重点实验室，北京 100191；先进航空发动机协同创新中心，北京 100191；北京航空航天大学能源与动力工程学院，北京 100191
2.
北京航空航天大学能源与动力工程学院，北京 100191

基金项目: 航空发动机复杂系统安全性教育部长江学者创新团队（IRT0905）；中国博士后科学基金（2016M591047）

计量
- 文章访问数: 1199
- HTML浏览量: 228
- PDF量: 834
- 被引次数: 0
出版历程
- 收稿日期: 2016-09-05
- 刊出日期: 2018-03-28

Time-related steady heat transfer experiments in rotating disk cavity

摘要

摘要: 在稳态换热试验中，试验没有达到稳定就测量会增大误差，常见工况中盘面平均努塞尔数Nu误差的半衰期为2500~2700s。为判断试验是否达到稳定或可测量状态，采用瞬态计算方法对旋转盘腔换热试验的稳定时间的判定方法进行了研究。数值计算结果表明：对于旋转盘腔换热试验，稳定时间较长。提供了一种通过试验精度判定稳定时间和可测时间的方法，试验前可以由固体非稳态导热的傅里叶数估算可测时间。建议试验过程中每隔一段时间观测传感器数值，观测时间间隔按对数规律确定，直到传感器数值不变以确定达到稳定状态。
- 旋转盘腔 /
- 换热试验 /
- 稳定时间 /
- 误差分析 /
- 瞬态导热
Abstract: Errors in steady heat transfer experiments increase if it is measured before steady state, and the half-life period of errors of average Nusselt number is about 2500~2700s in general conditions. In order to modify the state of heat transfer experiments, rotating disk cavity heat transfer experiments were performed by transient numerical simulation. Results presented showed that it was a long time before steady state in heat transfer experiment of cavity. An approach of predicting steady time and allowable measurement time was developed by permissive errors of experiments, and allowable measurement time can be pre-calculated before experiments by Fourier number. Its also suggested that the sensors be observed per minutes by regularity of logarithm until the numbers of sensors are constant, then the experiment is in steady state.
- rotating disk cavity /
- heat transfer experiment /
- steady time /
- error analysis /
- transient heat conduct

HTML

参考文献(18)

[1]	葛萍,方勇,解本政,等.温度测试系统中的误差分析与控制方法［J］.信息与电子工程,2011,9(6):790-794.GE Ping,FANG Yong,XIE Benzheng,et al.Error analysis and control in the temperature measuring system［J］.Information and Electronic Engineering,2011,9(6):790-794.(in Chinese)
[2]	GUNTHER A,UFFRECHT W,ODENBACH S.Local measurements of disk heat transfer in heated rotating cavities for several flow regimes［J］.Journal of Turbomachinery,2012,134(5):051016.1-051016.9.
[3]	佟显义,徐微,辛欣,等.燃气稳态温度测量及误差分析［J］.中国测试,2015,41(增刊1):105-108.TONG Xianyi,XU Wei,XIN Xin,et al.Gas steady temperature measurement and error analysis［J］.China Measurement and Test,2015,41(Suppl.1):105-108.(in Chinese)
[4]	雷震,李怡,付琳琳.液氧主容器温度测量误差分析与改进方法［J］.火箭推进,2015,41(6):92-98.LEI Zhen,LI Yi,FU Linlin.Analysis and improvement methods for temperature measurement error of LO2 main container［J］.Journal of Rocket Propulsion,2015,41(6):92-98.(in Chinese)
[5]	丁水汀,张弓,李烨,等．旋转盘腔盘缘热流密度的敏感性分析［J］.推进技术,2012,33(2)：263-268.ING Shuiting,ZHANG Gong,LI Ye.Sensibility analysis of the heat flux in the rotating cavity［J］.Journal of Propulsion Technology,2012,33(2)：263-268.(in Chinese)
[6]	丁水汀,张弓,李烨,等．旋转盘腔进气位置的敏感性分析［J］.航空动力学报,2011,26(8)：1681-1687.DING Shuiting,ZHANG Gong,LI Ye,et al.Sensibility analysis of the air inlet composition in the rotating cavity［J］.Journal of Aerospace Power,2011,26(8)：1681-1687.(in Chinese)
[7]	丁水汀,李烨,张弓,等．旋转盘腔盘罩间隙比的敏感性分析［J］.航空动力学报,2012,27(3)：528-535.DING Shuiting,LI Ye,ZHANG Gong,et al.Sensibility analysis of gap ratio in the rotating cavity［J］.Journal of Aerospace Power,2011,27(3)：528-535.(in Chinese)
[8]	丁水汀,李烨,张弓,等.旋转盘腔预旋角度的敏感性分析［J］.航空动力学报,2011,26(10)：2251-2257.DING Shuiting,LI Ye,ZHANG Gong,et al.Sensibility analysis of inlet pre-swirl angle in the rotating cavity［J］.Journal of Aerospace Power,2011,26(10)：2251-2257.(in Chinese)
[9]	徐国强,陶智,丁水汀,等.高位垂直进气旋转盘流动与换热的实验研究［J］.航空动力学报,2000,15(2)：164-168.XU Guoqiang,TAO Zhi,DING Shuiting,et al.Experimental investigation on flow and heat transfer in shrouded rotating disk with high-positioned air inflow［J］.Journal of Aerospace Power,2000,15(2)：164-168.(in Chinese)
[10]	徐国强,张笙,罗翔,等.高位垂直进气径向出流旋转盘腔换热的实验研究［J］.航空动力学报,2006,21(5)：820-823.XU Guoqiang,ZHANG Sheng,LUO Xiang,et al.Experimental investigation on flow and heat transfer in shrouded rotating disk with high-positioned air inflow［J］.Journal of Aerospace Power,2006,21(5)：820-823.(in Chinese)
[11]	徐国强,陶智,丁水汀,等.中心进气旋转盘流动与换热的数值研究［J］.航空动力学报,2000,15(2):169-173.XU Guoqiang,TAO Zhi,DING Shuiting,et al.Numerical study on flow and heat tranfer in shrouded rotating disk system with central air inflow［J］.Journal of Aerospace Power,2000,15(2):169-173.(in Chinese)
[12]	徐国强,赵熙,罗翔,等.直接供气预旋转静系的换热［J］.航空动力学报,2012,27(10):2161-2168.XU Guoqiang,ZHAO Xi,LUO Xiang,et al.Heat transfer in direct transfer pre-swirl rotro-stator system［J］.Journal of Aerospace Power,2012,27(10):2161-2168.(in Chinese)
[13]	闻洁,赵桂林,陶智,等.红外成像仪用于传热实验的研究［J］.北京航空航天大学学报,2003,29(8)：700-703.WEN Jie,ZHAO Guilin,TAO Zhi,et al.Studies on infrared camera using in heat transfer experiments［J］.Journal of Beijing University of Aeronautics and Astronautics,2003,29(8)：700-703.(in Chinese)
[14]	PELLE J,HARMAND S.Convective heat transfer in a rotor stator system air gap with multiple suctions of fluid through the stator［J］.Journal of Heat Transfer,2011,133(7):165-180.
[15]	张达,罗翔,徐国强,等.转静系盘腔转盘风阻温升实验［J］.航空动力学报,2015,30(5)：1047-1056.ZHANG Da,LUO Xiang,XU Guoqiang,et al.Windage heating experiment on rotating disc in cavity of rotor-stator system［J］.Journal of Aerospace Power,2015,30(5)：1047-1056.(in Chinese)
[16]	徐凤花.示温漆技术在航空发动机高温部件表面温度测试上的应用研究［D］.成都：电子科技大学,2009.
[17]	熊庆荣,朱国成,钟明.三头部燃烧室火焰筒壁面温度测试研究［J］.航空动力学报,2016,31(4):775-779.XIONG Qingrong,ZHU Guocheng,ZHONG Ming.Experiment investigation of temperature measurement on the wall of flame tube for a triple combustor［J］.Journal of Aerospace Power,2016,31(4):775-779.(in Chinese)
[18]	徐国强,詹国治,丁水汀,等.高位垂直进气转静系旋转盘流动与换热计算［J］.推进技术,2000,21(4):40-43.XU Guoqiang,ZHAN Guozhi,DING Shuiting,et al.Numerical calculation for flow and heat transfer of a shrouded rotating disk with high-positioned air-inlet［J］.Journal of Propulsion Technology,2000,21(4):40-43.(in Chinese)
