航空发动机帽罩热气膜防冰的加热特性

柯鹏; 杨慧赟; 王俊凯; 杨春信

doi:10.13224/j.cnki.jasp.2018.03.003

航空发动机帽罩热气膜防冰的加热特性

doi: 10.13224/j.cnki.jasp.2018.03.003

1.
北京航空航天大学交通科学与工程学院飞机/发动机综合系统安全性北京市重点实验室，北京 100191
2.
北京航空航天大学航空科学与工程学院，北京 100191

基金项目: 中央高校基本科研业务费（YWF-14-JTXY-009）

计量
- 文章访问数: 1185
- HTML浏览量: 208
- PDF量: 890
- 被引次数: 0
出版历程
- 收稿日期: 2016-08-09
- 刊出日期: 2018-03-28

Heating characteristics of aero-engine nose cone with film-heating anti-icing systemA

摘要

摘要: 针对复合材料帽罩采用的一种热气膜防冰系统，采用计算流体力学方法研究了其内部冲击换热和外部气膜加热效果。发展了二维轴对称计算方法并与全三维计算结果进行了对比，搭建了热气吹风实验台，利用红外测温仪和热电偶测量帽罩温度，验证了数值计算方法。全面研究了不同射流雷诺数、相对冲击距和气膜缝结构参数对热气加热特性的影响，结果表明：增大射流雷诺数有利于提高内部冲击换热效果和外部气膜加热效果；最佳相对冲击距随射流雷诺数的增大而增大，射流雷诺数为10000~40000范围内最佳相对冲击距在5~8内取得；气膜射流能大幅提高缝后外壁面温度，加热效率与气膜缝宽和位置有关，前缘开设的气膜缝还会提升前缘冲击换热效果。
- 防冰 /
- 帽罩 /
- 计算流体力学 /
- 测温实验 /
- 冲击换热 /
- 气膜加热
Abstract: For the film heating anti-icing system used in composite aero-engine nose cone, a computational fluid dynamics method was adopted to study the internal jet impingement heat transfer and external film heating efficiency. Two-dimensional axisymmetric algorithm was developed and compared with the results calculated by three-dimensional algorithm. A hot-air blowing experimental apparatus was built up and the infrared thermometer and thermocouple were used to verify the numerical simulation method. The effects of Reynolds number, relative impingement distance and structure parameters of film slot on heat transfer characteristics were comprehensively investigated. Results show that increasing Reynolds number is conducive to improving the internal jet impingement heat transfer and external film heating efficiency. The optimal value of relative impingement distance increases with the increasing Reynolds number, and the optimal value is between 5 and 8 when Reynolds number is between 10000 and 40000. Opening film slot can significantly increase the temperature of exterior surface, and heating efficiency is related to the width and location of film slot. Opening film slot at leading edge can also enhance jet impingement heat transfer.
- anti-icing /
- cone /
- computational fluid dynamics /
- temperature-measuring experiment /
- jet impingementheat transfer /
- film heating

HTML

参考文献(15)

[1]	YU Chenxing,KE Peng,YU Guangfeng,et al.Investigation of water impingement on a multi-element high-lift airfoil by Lagrangian and Eulerian approach［J］.Propulsion and Power Research,2015,4(3):161-168.
[2]	MESSINGER B L.Equilibrium temperature of an unheated icing surface as a function of air speed［J］.Journal of the Aeronautical Sciences,1953,20(1):29-42.
[3]	PELLISSIER M P C,HABASHI W G,PUEYO A.Optimization via FENSAP-ICE of aircraft hot-air anti-icing systems［J］.Journal of Aircraft,2011,48(1):265-276.
[4]	YANG Huiyun,KE Peng,YANG Chunxin.Analysis of droplet impingement characteristics of aero-engine nose cone with hot air film ［R］.Seoul:American Society of Mechanical Engineers,2016.
[5]	BRAHMA R K,PADHY I,PRADHAN B.Prediction of stagnation point heat transfer for a single round jet impinging on a concave hemispherical surface［J］.Wrmeund Stoffüber-tragung,1991,26(1):41-48.
[6]	LEE D H,CHUNG Y S,KIM M G.Technical note turbulent heat transfer from a convex hemispherical surface to a round impinging jet［J］.International Journal of Heat and Mass Transfer,1999,42(6):1147-1156.
[7]	张永恒,周勇,王良璧.圆形冲击射流传热性能的实验研究［J］.热科学与技术,2006(1):38-43. ZHANG Yongheng,ZHOU Yong,WANG Liangbi.Experimental study of heat transfer from round nozzle impinging jet［J］.Journal of Thermal Science and Technology,2006(1):38-43. (in Chinese)
[8]	李志,豆瑞锋,温治,等.单孔射流冲击流动与换热过程的数值模拟［J］.工业炉,2011,33(4):1-7.LI Zhi,DOU Ruifeng,WEN Zhi,et al.Numerical simulation of single-nozzle jet impinging flow and heat transfer process［J］.Industrial Furnace,2011,33(4):1-7. (in Chinese)
[9]	SHARIF M A R,MOTHE K K.Evaluation of turbulence models in the prediction of heat transfer due to slot jet impingement on plane and concave surfaces［J］.Numerical Heat Transfer:Part B Fundamentals,2009,55(4):273-294.
[10]	BERNIER B C,NGUYEN C Q,ZUNIGA H,et al.A study on film cooling uniformity effectiveness trends for various coolant hole geometries［R］.AIAA-2009-5102,2009.
[11]	BOGARD D G,THOLE K A.Gas turbine film cooling［J］.Journal of Propulsion and Power,2006,22(2):249-270.
[12]	HAN J C.Fundamental gas turbine heat transfer［J］.Journal of Thermal Science and Engineering Applications,2013,5(2):021007.1-021007.15.
[13]	周雷声,朱惠人,许都纯,等.带射流收缩通道内部换热特性数值模拟［J］.机械设计与制造,2011(6):230-232.ZHOU Leisheng,ZHU Huiren,XU Duchun,et al.Numerical simulation on internal heat transfer of an contraction channel with jets impingement［J］.Machinery Design and Manufacture,2011(6):230-232. (in Chinese)
[14]	柯鹏，张韵，于广锋，等.航空发动机进口支板外部热气膜对水滴撞击特性的影响［J］.航空动力学报,2017,32(3):621-629.KE Peng,ZHANG Yun,YU Guangfeng,et al.Influence of exterior hot-film on droplet impingement characteristics over aero-engine inlet strut［J］.Journal of Aerospace Power,2017,32(3):621-629. (in Chinese)
[15]	平艳.冲击射流数值模拟中湍流模型的分析与对比［D］.天津:天津大学,2012.PING Yan.Analysis and comparison of turbulence model in simulation of impinging jet flow［D］.Tianjin:Tianjin University,2012. (in Chinese)
