并列双方柱的疏水涂层防冰效果结冰风洞实验评估

肖春华; 程尧; 乔宝英; 唐乔乔

doi:10.13224/j.cnki.jasp.2018.03.004

并列双方柱的疏水涂层防冰效果结冰风洞实验评估

doi: 10.13224/j.cnki.jasp.2018.03.004

1.
中国空气动力研究与发展中心空气动力学国家重点实验室,四川绵阳 621000
2.
中国空气动力研究与发展中心飞行器结冰与防除冰重点实验室,四川绵阳 621000

基金项目: 国家自然科学基金委员会资助面上项目（11572338）；国家重点基础研究计划（973计划）（2015CB755804）

计量
- 文章访问数: 1090
- HTML浏览量: 212
- PDF量: 721
- 被引次数: 0
出版历程
- 收稿日期: 2017-07-24
- 刊出日期: 2018-03-28

Icing wind tunnel test evaluation on anti-icing effects of hydrophobic coating on two parallelized square cylinders

摘要

摘要: 采用结冰风洞实验研究的方法,利用0.3m×0.2m结冰风洞主实验段,在不同结冰气象条件下对涂覆在并列双方柱实验模型表面的不同纳米疏水涂层结冰特性进行了实验研究,对左右并排的方柱实验模型表面的结冰外形进行了测量和比较,建立了基于9个结冰外形几何特征量的防冰效果量化评估方法,对有、无纳米疏水涂层表面的结冰外形几何特征量无量纲化偏差进行了计算和分析。研究表明：基于结冰外形几何特征量的防冰效果量化评估方法可以较好地评估纳米疏水涂层的防冰效果。与未涂覆防冰涂层的铝合金材料相比,硅橡胶及其添加颗粒的纳米涂层均具有一定的防冰性能,与硅橡胶涂层相比,有的添加颗粒的纳米涂层防冰效果略好一点,而有的略差一点,没有明显提高。在硅橡胶基底材料中添加纳米疏水颗粒,可以在涂层表面构筑一些微纳结构,从而起到防冰作用。因此,在硅橡胶涂层中添加纳米疏水颗粒是一种值得探索的防冰涂层制备研究方向,但如果仅采用物理混合搅拌的方法,纳米颗粒难以在硅橡胶涂层表面形成稳定疏水性能的微纳乳突结构。纳米疏水涂层只能降低结冰速率,无法完全杜绝材料表面的结冰现象。
- 防冰 /
- 疏水涂层 /
- 并列双方柱 /
- 结冰风洞 /
- 微纳结构
Abstract: Anti-icing effects of different nano hydrophobic coatings on two parallelized square cylinders test model were studied using icing experimental method in the main test section of 0.3m×0.2m icing wind tunnel under different icing weather conditions.The ice shapes on left and right parallelized square cylinders test model were measured and compared respectively.The quantitative method of evaluating anti-icing effect was established on the basis of nine geometric characteristics parameters of ice profile.The nondimensional deviation of ice profile geometric characteristics parameters were calculated and analyzed between the coated model and the clean model.The study shows that the quantitative test evaluation method based on ice profile geometric characteristics parameters can evaluate the anti-icing effect of nano hydrophobic coating.The silicone rubber coating and other coatings added in different nano particles have some anti-icing capability.The silicone rubber coating added in different proportion of nano particles show comparative anti-icing capability compared with the silicone rubber coating in the present study.Adding small amount of nano hydrophobic particles in the silicone rubber coating can construct some micro-nano structures, which can enhance the hydrophobic and anti-icing effects.Therefore, it is a valuable way to fabricate anti-icing coating by adding different nano hydrophobic particles into the silicone rubber coating.But it is not easy for the nano hydrophobic particles to form a stable micro-nano structures with hydrophobic and anti-icing performance on the silicone rubber coating just by physical mixing and stirring methods.The nano hydrophobic coating can reduce the icing velocity, but cant stop icing phenomena completely.
- anti-icing /
- hydrophobic coating /
- two parallelized square cylinders /
- icing wind tunnel /
- micro-nano structures

HTML

参考文献(21)

[1]	LYNCH F T,KHODADOUST A.Effects of ice accretions on aircraft aerodynamics［J］.Progress in Aerospace Sciences,2001,37(8):669-767.
[2]	KIND R J,POTAPCZUK M G,FEO A,et al.Experimental and computational simulation of in-flight icing phenomena［J］.Progress in Aerospace Sciences,1998,34(5/6):257-345.
[3]	PETTY K R,FLOYD C D J.A statistical review of aviation airframe icing accidents in the U.S［R］.Hyannis,MA:11th Conference on Aviation,Range,and Aerospace,2004.
[4]	ANDERSON D N,REICH A D.Tests of the performance of coating for low ice adhesion［R］.AIAA-97-0303,1997.
[5]	AYRES J,SIMENDINGER W H,BALIK C M.Characterization of titanium alkoxide sol-gel systems designed for anti-icing coatings:Ⅱ mass loss kinetics［J］.Journal of Coatings Technology & Research,2007,4(4):473-481.
[6]	CAO L L,JONES A K,SIKKA V K,et al.Anti-icing superhydrophobic coatings［J］.Langmuir,2009,25(21)：12444-12448.
[7]	KARMOUCH R,COUD S,ABEL G,et al.Icephobic PTFE coatings for wind turbines operating in cold climate conditions［C］∥Poceeding of IEEE Electrical Power & Energy Conference.Halifax,Canada:Institute of Electrical and Electronics Engineers (IEEE),2010,1-6.
[8]	PETRENKO V,COURVILLE Z.De-icing coating for aerofoils［R］.AIAA 2000-0632,2000.
[9]	VARANASI K K,DENG T,SMITH J D,et al.Frost formation and ice adhesion on superhydrophobic surfaces［J］.Applied Physic Letters,2010,97(23):234102.1-234102.3.
[10]	CAI L,WANG R H,HOU P X,et al.Study on restraining frost growth at initial stage by hydrophobic coating and hygroscopic coating［J］.Energy & Buildings,2011,43(5):1159-1163.
[11]	XIAO J,CHAUDHURI S.Design of anti-icing coatings using supercooled droplets as nano-to-microscale probes［J］.Langmuir:the ACS Journal of Surfaces & Colloids,2012,28(9):4434-4446.
[12]	ANTONINI C,INNOCENTI M,HORN T,et al.Understanding the effect of superhydrophobic coating on energy reduction in anti-icing system［J］.Cold Regions Science & Technology,2011,67(1/2):58-67
[13]	WANG Y,XUE J,WANG Q,et al.Verification of icephobic/anti-icing properties of a superhydrophobic surface［J］.ACS Applied Materials & Interfaces,2013,5(8):3370-3381.
[14]	LIAO W Y,JIA Z D,GUAN Z C,et al.Reducing ice accumulation on insulators by applying semiconducting RTV silicone coating［J］.IEEE Transactions on Dielectrics and Electrical Insulation,2007,14(6):1446-1454.
[15]	JIANG X L,MA J,ZHANG Z J,et al.Effect of hydrophobicity coating on insulator icing and DC flashover performance of iced insulators［J］.IEEE Transactions on Dielectrics & Electrical Insulation,2010,17(2):351-359.
[16]	WANG F C,LI C R,L Y Z,et al.Reducing ice accumulation on aluminum conductor by applying superhydrophobic coating［R］.Virginia,USA:IEEE Conference on Electrical Insulation & Dielectric Phenomena,2009.
[17]	肖春华,胡站伟,桂业伟,等.疏水涂层表面防冰效果的结冰风洞实验研究［J］.实验流体力学,2013,27(2):41-45.XIAO Chunhua,HU Zhanwei,GUI Yewei,et al.Test study on anti-icing effects of hydrophobic coating in icing wind tunnel［J］.Journal of Experiments in Fluid Mechanics,2013,27(2):41-45.(in Chinese)
[18]	肖春华,桂业伟,杜雁霞,等.电热除冰传热特性的结冰风洞实验研究［J］.实验流体力学,2010,24(4):22-24. XIAO Chunhua,GUI Yewei,DU Yanxia,et al.Experimental study on heat transfer characteristics of aircraft electrothermal deicing in icing wind tunnel［J］.Journal of Experiments in Fluid Mechanics,2010,24(4):21-24.(in Chinese)
[19]	RUFF G A,ANDERSON D N.Quantification of ice accretions for icing scaling evaluations［R］.AIAA-98-0195,1998.
[20]	DILL L H,CHOO Y K.Representation of ice geometry by parametric functions:construction of approximating NURBS curves and quantification of ice roughness:year 1 approximating NURBS curves［R］.NASA/CR-2004-213071,2004.
[21]	关丽,张晖,杨延莲,等.一种具有防覆冰功能的材料及其制备方法和用途:CN201010174289.0［P］.2010-11-16.
