喷油杆和凹腔支板稳定器近距匹配的液雾分布可视化

刘玉英; 周弘毅; 谢奕; 钱佳兴

doi:10.13224/j.cnki.jasp.2018.03.005

喷油杆和凹腔支板稳定器近距匹配的液雾分布可视化

doi: 10.13224/j.cnki.jasp.2018.03.005

北京航空航天大学能源与动力工程学院，北京 100191

基金项目: 航空科学基金（2013ZB51014）

计量
- 文章访问数: 1300
- HTML浏览量: 210
- PDF量: 791
- 被引次数: 0
出版历程
- 收稿日期: 2016-08-31
- 刊出日期: 2018-03-28

Visualization on spray distribution of close-coupled fuel injector and strut with cavity flameholder system

摘要

摘要: 液雾分布与稳定器的燃油布置方式、油气分配、火焰稳定及火焰传播密切相关。以RP-3为雾化介质，在来流马赫数为0.2及来流温度为10~400℃的条件下，采用高速摄影法和激光片光/照相法，对喷油杆与凹腔支板稳定器间隔31.5 mm且顺喷时的液雾分布特点进行了可视化研究，并探讨了来流温度及油气动量比对其液雾分布轨迹的影响。结果表明：顺喷喷油杆与凹腔支板稳定器近距匹配方式有利于燃油在支板前缘形成挡溅雾化；挡溅雾化后的一部分燃油在支板表面形成油膜，并在凹腔前缘与尾缘进行二次雾化，来流温度较高时高温支板表面也有利于燃油的蒸发雾化；另一部分燃油则以类似横向射流的形式进行雾化。当来流温度一定时，油气动量比增大，液雾轴向分布距离和横向穿透深度均增大；来流温度升高，液雾穿透深度增加，油气动量比对液雾分布的影响更明显。
- 液雾分布 /
- 凹腔支板稳定器 /
- 高速摄影法 /
- 激光片光/照相法 /
- 油气动量比 /
- 穿透深度
Abstract: Spray distribution is closely related to the fuel supply methods, fuel-air distribution ratio, flame stability and flame propagation properties of flameholders. Taking RP-3 as atomization medium, the spray distribution characteristics of close-coupled fuel injector and strut with cavity flameholder system were visualized by high-speed photography and laser sheet/photography, under the condition of incoming flow Mach number 0.2, incoming flow temperature varying from 10℃ to 400℃, the distance of fuel injector and stabilizer kept as 31.5mm and the downstream injection direction. Meanwhile, the effects of incoming flow temperature and fuel-to-air momentum flux ratio on spray distribution trajectory were studied as well. The result showed that, downstream injection close-coupled fuel injector and strut with cavity folder system was benificial to the fuel atomization by splashing fuel jet at the leading edge of strut. After the splashing, a part of fuel was distributed on the surface of strut as fuel film and atomized further at the leading edge and trailing edge of cavity, during which higher incoming flow temperature led to faster evaporation. And another part of fuel spray was atomized as cross-flow. Under the same incoming flow temperature, the axial-direction distribution distance and cross-direction penetration depth of spray increased with the fuel-to-air momentum flux ratio. With the increase of air incoming flow temperature, penetration depth increased and fuel-to-air momentum flux ratios effect to spray distribution became more obvious.
- spray distribution /
- strut with cavity flameholder /
- high-speed photography /
- laser sheet/photography /
- fuel-to-air momentum flux ratio /
- penetration depth

HTML

参考文献(24)

[1]	季鹤鸣.新一代战斗机发动机的加力燃烧室技术［J］.国际航空,1996（1）:22-23.JI Heming.Afterburner technology in new generation fighter engines［J］.International Aviation,1996（1）:22-23.(in Chinese)
[2]	EBRAHIMI H B.Overview of gas turbine augmentor design,operation and combustion oscillation［R］.Toronto,Canada:19th Annual Conference on Liquid Atomization and Spray Systems,2006.
[3]	张孝春,孙雨超,刘涛.先进加力燃烧室设计技术综述［J］.航空发动机,2014,40(2):24-30.ZHANG Xiaochun,SUN Yuchao,LIU Tao.Summary of advanced afterburner design technology［J］.Aeroengine,2014,40(2):24-30.(in Chinese)
[4]	金如山,索建秦.先进加力燃烧室技术发展［C］∥中国航空学会第七届动力年会论文摘要集.贵阳：中国航空学会，2010：45. [5］季鹤鸣,樊未军,杨茂林.新型内突扩加力燃烧室方案可行性分析［J］.航空发动机,2006,32(1):35-37.JI Heming,FAN Weijun,YANG Maolin.Feasibility analysis of a new inner dumped afterburner concept［J］.Aeroengine,2006,32(1):35-37.(in Chinese)
[5]	马梦颖,金捷,季鹤鸣.航空发动机加力燃烧室技术及新颖结构方案［J］.燃气涡轮试验与研究,2008，21(4)：55-59.MA Mengying,JIN Jie,JI Heming.Technology and new configuration of aero-engine afterburner［J］.Gas Turbine Experiment and Research,2008,21(4)：55-59.(in Chinese)
[6]	孙雨超,张志学,李江宁,等.一体化加力燃烧室方案设计及数值研究［J］.航空科学技术,2011(4):71-74.SUN Yuchao,ZHANG Zhixue,LI Jiangning,et al.Design and numerical research of integrated rear frame and afterburner［J］.Aeronautical Science and Technology,2011(4):71-74.(in Chinese)
[7]	吴迪,金捷,季鹤鸣.一种加力燃烧室凹腔支板火焰稳定方案研究［C］∥中国航空学会第七届动力年会论文摘要集.贵阳：中国航空学会，2010：49.
[8]	吴迪,金捷,季鹤鸣,等.凹腔支板尾缘涡脱落频率试验研究［J］.航空发动机,2011,37(4):48-50.WU Di,JIN Jie,JI Heming,et al.Experimental study of vortex shedding frequency at trailing edge of a cavity-based strut［J］.Aeroengine,2011,37(4):48-50.(in Chinese)
[9]	刘广海，刘玉英.翼型支板火焰稳定器结构参数的研究［J］.航空动力学报，2015，30(6):1350-1356.LIU Guanghai,LIU Yuying.Investigation on structural parameters of airfoil shaped struct flame stabilizer［J］.Journal of Aerospace Power,2015，30(6):1350-1356.(in Chinese)
[10]	刘玉英，谢奕，柳杨，等.支板火焰稳定器自燃点火性能初步试验研究［R］.北京：纪念航空科学基金30年暨中航工业青年科技论坛，2015.
[11]	张容珲，刘玉英，谢奕，等.燃油喷射方式对凹腔支板稳定器火焰传播性能的影响［J］.推进技术,2017,38(9):2046-2054.ZHANG Ronghui,LIU Yuying,XIE Yi,et al.Fuel Injection way effect on the flame propagation of the cavity-based struct flameholder［J］.Journal of Propulsion Technology,2017,38(9):2046-2054.(in Chinese)
[12]	黄勇,林宇震,樊未军.燃烧与燃烧室［M］.北京：北京航空航天大学出版社,2009.
[13]	FULLER R P,WU P K,KIRKENDALL K A,et al.Effects of injection angle on atomization of liquid jets in transverse airflow［J］.AIAA Journal,2000,38(1):64-72.
[14]	CHEN T H,SMITH C R,SCHOMMER D G,et al.Multi-zone behavior of transverse liquid jet in high-speed flow［R］.AIAA 93-453,1993.
[15]	LAKHAMRAJU R R.Liquid jet breakup studies in subsonic airstream at elevated temperatures［D］.Cincinnati,US：University of Cincinnati,2005.
[16]	ESLAMIAN M,AMIGHI A,ASHGRIZ N.Atomization of liquid jet in high-pressure and high-temperature subsonic crossflow［J］.AIAA Journal,2014,52(7):1374-1385.
[17]	SCHETZ J A,SITU M,HEWITT P W.Transverse jet breakup and atomization with rapid vaporization alongthe trajectory［J］.AIAA Journal,1985,23(4):596-603.
[18]	INAMURA T,TAKAHASHI M,KUMAKAWA A.Combustion characteristics of a liquid-fueled ramjet combustor［J］.Journal of Propulsion and Power,2001,17(4):860-868.
[19]	STENZLER J N,LEE J G,SANTAVICCA D A,et al.Penetration of liquid jets in a cross-flow［J］.Atomization and Sprays,2006,16(8):887-906.
[20]	BUNCE K,LEE J G,SANTAVICCA D A.Characterization of liquid jets-in-crossflow under high temperature,high velocity non-oscillating and oscillating flow conditions［R］.AIAA-2006-1225,2006.
[21]	金仁瀚,张铮,刘勇,等.横向加热气流中直射式喷嘴侧喷雾化特性研究［J］.推进技术,2013,34(5):658-663.JIN Renhan,ZHANG Zheng,LIU Yong,et al.Experimental study on atomization characteristics of simple nozzle in heating cross flow［J］.Journal of Propulsion Technology,2013,34(5):658-663.(in Chinese)
[22]	LOVETT J A,BROGAN T P,PHILIPPONA D S，et al.Development needs for advanced afterburner designs［R］.AIAA-2004-4192,2004.
[23]	罗莲军,刘玉英,张文龙,等.喷油杆与凹腔支板稳定器近距匹配雾化特性［J］.航空动力学报,2013,28(11):2462-2467.LUO Lianjun,LIU Yuying,ZHANG Wenlong,et al.Atomization characteristics of fuel injector and caviy-based strut flame stabilizer under close-range matching condition［J］.Journal of Aerospace Power,2013，28(11):2462-2467.(in Chinese)
[24]	KANOPOULOS N,VASANTHAVADA N,BAKER R L.Design of an image edge detection filter using the Sobel operator［J］.IEEE Journal of Solid-State Circuits,1988,23(2):358-367.
