油气比对燃气分析法燃烧效率、气态污染物测试精度的影响

李亚娟; 王明瑞; 张宝华; 韩冰; 马征

doi:10.13224/j.cnki.jasp.2018.03.006

油气比对燃气分析法燃烧效率、气态污染物测试精度的影响

doi: 10.13224/j.cnki.jasp.2018.03.006

中国航空发动机集团有限公司沈阳发动机研究所，沈阳 110015

计量
- 文章访问数: 1432
- HTML浏览量: 342
- PDF量: 744
- 被引次数: 0
出版历程
- 收稿日期: 2016-08-22
- 刊出日期: 2018-03-28

Influence of air-fuel ratio on accuracy of combustion efficiency and exhaust emission under gas analysis method

摘要

摘要: 在燃气分析单点测试偏差的基础上，针对燃气轮机、主燃烧室及加力燃烧室目前采用的取样方式的现状，建立了燃气分析法和流量法的油气比偏差对燃烧效率和气态污染物测试精度的影响规律。结果表明:对于采用移位机构进行测量的主燃烧室，流量法和燃气分析法油气比相差在5.1%以内时，说明有足够的测点密度，数据有效，此时的燃烧效率精度优于0.5%；对于加力燃烧室和整机测试，由于取样点不足，油气比偏差较大，燃烧效率的精度还取决于油气比和CO的体积分数。保证足够的取样点密度是燃气分析测试结果具有较高精度的前提。
- 燃气分析 /
- 燃烧效率 /
- 气态污染物 /
- 油气比 /
- 偏差分析
Abstract: Based on the gas analysis error of a single position, the influence law of the fuel-air ratio error between gas analysis and flow measurement on the testing precision of combustion efficiency and exhaust emission was founded for the current sampling mode of primary combustor, afterburner and gas turbine engine. The data were valid for primary combustor test by swing mode when fuel-air ratio error was less than 5.1% between flow measurement and gas analysis; meanwhile, the error of combustion efficiency was less than 0.5% and sampling density was considered enough. The error of fuel-air ratio of flow measurement to gas analysis was large due to less sampling density in afterburner and gas turbine engine, the precision of combustion efficiency was also affected by fuel-air ratio and the volume fraction of CO. It indicates that enough sampling density for gas analysis is necessary for high test precision.
- gas analysis /
- combustion efficiency /
- exhaust emission /
- fuel-air /
- error analysis

HTML

参考文献(18)

[1]	PENG Yunhui,LIN Yuzhen,XU Quanhong.Experimental investigation of the pattern factor and LBO of high temperature rise combustor［R］.International Symposium on Air Breathing Engines，ISABE 2007-1185,2007.
[2]	HE Yongpan,HAN Lei,LI Lihan.Analysis of the error in liquid-fuel ramjet combustion efficiency calculation［R］.AIAA-2012-5831,2012.
[3]	JAMES D.Research on miniature gas analysis systems［R］.Cleveland:Lewis Research Center,1974.
[4]	BAHR D W.Technology for the design of high temperature rise combustors［R］.AIAA 85-1292,1985.
[5]	王华芳,吴寿生.航空燃气涡轮发动机气态污染物的连续取样及测量程序规范:HB6117-1987［S］.北京：北京航空学院，1987：3-21.
[6]	Society of Automotive Engineers.Gas turbine emission probe factors:SAE AIR 4068B-2012［S］.Wasington：Society of Automotive Engineers (SAE) International,2012.
[7]	MARCHIONNA N R.Effect of inlet-air humidity on the formation of oxides of nitrogen in a gas-turbine combustor［R］.Cleveland:Lewis Research Center,1973.
[8]	GREBMAN J,ROBERT D.Forecast of jet engine exhaust emissions for future high altitude commercial aircraft［R］.Cleveland:Lewis Research Center,1974.
[9]	DENG A M,YU S Z,CHENG X R.Analysis of the error of ramjet combustion performance test［R］.Urumchi:the 2nd Ramjet Academic Communication Conference,2007.
[10]	MELLOR A M.Design of modern turbine combustor［M］.New York:Academic Press,1990.
[11]	金如山.航空燃气轮机燃烧室［M］.北京:宇航出版社,1988.
[12]	LI Guoqiang,GUTMARK E J.Combustion characteristics of a multiple swirl spray combustor［R］.AIAA-2003-0489,2003.
[13]	WILLAMSON R C,STANFORTH C M.Measurement of jet engine combustion temperature by the use of thermocouples and gas analysis［J］.Society of Automotive Engineers (SAE) Technical Paper 690433,1969.
[14]	胡正义，江义军，赵清杰，等.航空发动机设计手册:第9册主燃烧室［M］.北京:航空工业出版社,2000.
[15]	张洪飚，李志广，陈浚,等.航空发动机设计手册:第11册加力燃烧室［M］.北京:航空工业出版社,2001.
[16]	TURNS S R.燃烧学导论：概念与应用［M］.2版.姚强，李水清，王宇，译.北京：清华大学出版社,2009.
[17]	王明瑞,肖阳,韩冰,等.航空燃气涡轮发动机燃气分析测试及计算方法［J］.航空动力学报,2015,30(11):2568-2574.WANG Mingrui,XIAO Yang,HAN Bing,et al.Gas analysis test and calculation method of aeroengine［J］.Journal of Aerospace Power,2015,30(11):2568-2574.(in Chinese)
[18]	李亚娟,王明瑞,韩冰，等.燃气分析法测试燃气涡轮发动机主燃烧室燃烧效率、气态污染物误差分析［J］.航空动力学报,2017,32(5):1051-1057.LI Yajuan,WANG Mingrui,HAN Bing,et al.Research on aeroengine primary combustor error analysis of combustion efficiency and exhaust emission using gas analysis method［J］.Journal of Aerospace Power,2017,32(5):1051-1057.(in Chinese)
