超临界压力航空煤油RP-3在竖直微细管内的对流换热实验

赵伟; 闻洁; 付衍琛; 张楠; 黄浩然

doi:10.13224/j.cnki.jasp.2018.03.014

超临界压力航空煤油RP-3在竖直微细管内的对流换热实验

doi: 10.13224/j.cnki.jasp.2018.03.014

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室，北京 100191

基金项目: 国家自然科学基金（51606179）

计量
- 文章访问数: 858
- HTML浏览量: 107
- PDF量: 570
- 被引次数: 0
出版历程
- 收稿日期: 2016-08-05
- 刊出日期: 2018-03-28

Experiment on convective heat transfer of aviation keroseneRP-3 in vertical micro-tube at supercritical pressure

摘要

摘要: 以实验方式对超临界压力RP-3在内径为1.09mm微细管内的对流换热进行了研究，剖析了系统压力、加热热流密度、流动方向及浮升力这些因素对对流换热的影响。实验中热流密度控制为180~460kW/m2，系统进口压力变化范围为3~5MPa，进口雷诺数在3200~10200范围内变化。结果表明：对于向下流动，在实验段入口处浮升力对换热产生了恶化作用，热流密度越大，恶化作用越强；系统压力主要是通过影响流体热物性对对流换热产生影响；不同流动方向对对流换热的影响十分显著，整体上向下流动换热得到强化，向上流动换热得到恶化。
- 超临界 /
- 航空煤油 /
- 微细管 /
- 对流换热 /
- 浮升力
Abstract: Convective heat transfer of supercritical China aviation fuel RP-3 in vertical micro-tube (inner diameter of 1.09mm) was experimentally investigated. Influences of system pressure, heat flux, flow direction and buoyancy on heat transfer were analyzed. Wall heat fluxes (180-460kW/m2), system import pressure (3-5MPa) and inlet Reynolds number (3200-10200) were maintained in experiments. The result showed that the buoyancy force deteriorated the heat transfer of downward flow in the entrance of test section; system pressure affected the convective heat transfer mainly by the impact of fluid thermal properties; effects of different flow directions on convection heat transfer were very significant. Overall heat transfer was strengthened for downward flow and decreased for upward flow.
- supercritical /
- aviation kerosene /
- micro-tube /
- convective heat transfer /
- buoyancy

HTML

参考文献(19)

[1]	BRUENING G B,CHANG W S.Cooled cooling air systems for turbine thermal management［R］.ASME Paper 1999-GT-14,1999.
[2]	孙青梅,米镇涛,张香文.吸热型碳氢燃料RP-3仿JP-7临界性质(tc,pc)的测定［J］.燃料化学学报,2006,34(4):466-470.SUN Qingmei,MI Zhentao,ZHANG Xiangwen.Determination of critical properties (tc,pc) of endothermic hydrocarbon fuels：RP-3 and simulated JP-7［J］.Journal of Chemistry and Technology,2006,34(4):466-470.(in Chinese)
[3]	JACKSON J D,HALL W B.Influence of buoyancy on heat transfer to fluids flowing in vertical tubes under turbulent conditions［C］∥Proceedings of Turbulent Forced Convection in Channels and Bundles.Washington:Hemisphere Publ Corp,1979:613-640.
[4]	JACKSON J D,COTTON M A,AXCELL B P.Studies of mixed convection in vertical tubes［J］.International Journal of Heat and Fluid Flow,1989,10(1):2-15.
[5]	胡志宏,陈听宽,罗毓珊,等.超临界压力下煤油传热特性试验研究［J］.西安交通大学学报,1999,33(9):62-65.HU Zhihong,CHEN Tinkuan,LUO Yushan,et al.Heat transfer characteristics of kerosene at supercritical pressure［J］.Journal of Xian Jiaotong University,1999,33(9):62-65.(in Chinese)
[6]	JIANG P X,ZHANG Y,SHI R F.Experimental and numerical investigation of convection heat transfer of CO2 at supercritical pressures in a vertical mini-tube［J］.International Journal of Heat and Mass Transfer,2004,51(11/12):3052-3056.
[7]	JIANG P X,YU Z,ZHAO C R,et al.Convection heat transfer of CO2 at supercritical pressures in a vertical mini tube at relatively low reynolds numbers［J］.Experimental Thermal and Fluid Science,2008,32(8):1628-1637.
[8]	JIANG P X,SHI R F,ZHAO C R,et al.Experimental and numerical study of convection heat transfer of CO2 at supercritical pressures in vertical porous tubes［J］.International Journal of Heat and Mass Transfer,2008,51(25/26):6283-6293.
[9]	李志辉,姜培学,赵陈儒,等.超临界CO2在垂直圆管内对流换热实验研究［J］.工程热物理学报,2008,29(3):461-464.LI Zhihui,JIANG Peixue,ZHAO Chenru,et al.Experimental investigation of convection heat transfer of CO2 at supertical pressures in vertical circular tube［J］.Journal of Engineering Thermophysics,2008,29(3):461-464.(in Chinese)
[10]	LIAO S M,ZHAO T S.Measurements of heat transfer Coefficients from supercritical carbon dioxide flowing in horizontal mini/micro channels［J］.Journal of Heat Transfer,2002,124(3):413-420.
[11]	LIAO S M,ZHAO T S.An experimental investigation of convection heat transfer to supercritical carbon dioxide in miniature tubes［J］.International Journal of Heat and Mass Transfer,2002,45(25):5025-5034.
[12]	TANIMIZU K,SADR R.Experimental investigation of buoyancy effects on convection heat transfer of supercritical CO2 flow in a horizontal tube［J］.Heat and Mass Transfer,2015,52(4):1-14.
[13]	DONG E K,KIM M H.Experimental investigation of heat transfer in vertical upward and downward supercritical CO2 flow in a circular tube［J］.International Journal of Heat and Fluid Flow,2011,32(1):176-191.
[14]	张春本,邓宏武,徐国强,等.超临界压力下航空煤油RP-3焓值的测量及换热研究［J］.航空动力学报,2010,25(2):331-335.ZHANG Chunben,DENG Hongwu,XU Guoqiang,et al.Enthalpy measurement and heat transfer investigation of RP-3 kerosene at supercritical pressure［J］.Journal of Aerospace Power,2010,25(2):331-335.(in Chinese)
[15]	王夕,刘波,祝银海,等.超临界压力下RP-3在细圆管内对流换热实验研究［J］.工程热物理学报,2015,36(2):360-365.WANG Xi,LIU Bo,ZHU Yinhai,et al.Experimental investigation on convection heat transfer of supercritical pressure RP-3 in a small pipe［J］.Journal of Engineering Thermophysics,2015,36(2):360-365.(in Chinese)
[16]	李勋锋,仲峰泉,范学军,等.超临界压力下航空煤油水平管内对流换热特性数值研究［J］.航空动力学报,2010,25(8):1690-1697.LI Xunfeng,ZHONG Fengquan,FAN Xueju,et al.Numerical study of convective heat transfer characteristics of kerosene flowing in a horizontal pipe at supercritical pressure［J］.Journal of Aerospace Power,2010,25(8):1690-1697.(in Chinese)
[17]	张斌,张春本,邓宏武,等.超临界压力下碳氢燃料在竖直圆管内换热特性［J］.航空动力学报,2012,27(3):595-603.ZHANG Bin,ZHANG Chunben,DENG Hongwu,et al.Heat transfer characteristics of hydrocarbon fuel at supercritical pressure in vertical circular tubes［J］.Journal of Aerospace Power,2012,27(3):595-603.(in Chinese)
[18]	朱锟,徐国强,贾洲侠,等.压力对水平管内超临界碳氢燃料流动换热影响实验［J］.航空动力学报,2016,31(6):1289-1296.ZHU Kun,XU Guoqiang,JIA Zhouxia,et al.Pressure effect on the heat transfer chcracteristics of hydrocarbon fuel in the horizontal circular tube at supercritical pressures［J］.Journal of Aerospace Power,2016,31(6):1289-1296.(in Chinese)
[19]	JACKSON J D,EVAMS-LUTTERODT K O.Impairment of turbulent forced convection heat transfer to superc rit-ical pressure CO2 caused by buoyancy forces ［D］.Manchest:University of Manchest,1968.
