Z-pin增强树脂基复合材料单搭接接头抗冲击性能

许爱华; 李勇; 还大军; 褚奇奕; 周煦洁

doi:10.13224/j.cnki.jasp.2018.03.021

Z-pin增强树脂基复合材料单搭接接头抗冲击性能

doi: 10.13224/j.cnki.jasp.2018.03.021

南京航空航天大学材料科学与技术学院，南京 210016

基金项目: 航空科学基金（2015ZE52049）；江苏高校优势学科建设工程资助项目

计量
- 文章访问数: 949
- HTML浏览量: 123
- PDF量: 606
- 被引次数: 0
出版历程
- 收稿日期: 2016-09-14
- 刊出日期: 2018-03-28

Impact resistance performances of resin matrix composite single lap joints reinforced by Z-pin

摘要

摘要: 为了研究Z-pin增强树脂基复合材料接头的抗冲击性能，制备了Z-pin增强单搭接接头冲击试样。对比不同树脂体系Z-pin/层合板界面裂纹扩展，分别通过Z-pin拔脱试验和接头剪切试验研究Z-pin冲击后拔脱强度和单搭接接头冲击后剪切强度；结合有限元模拟和超声C扫描研究搭接面分层损伤情况。结果表明，相同冲击能量下，环氧Z-pin/环氧层合板界面抗冲击性更强，冲击能量越大，裂纹扩展越显著；Z-pin增强树脂基复合材料显著减小分层损伤面积，提高冲击后剪切强度，体积分数为1.5%、直径为0.5mm的Z-pin增强层合板分层损伤面积仅为40%，冲击后剪切强度的下降率仅为24.89%。随着Z-pin体积分数增加，搭接面损伤面积逐渐减小，冲击后剪切强度先增加后降低；随着Z-pin直径增加，层间损伤面积增加，冲击后剪切强度逐渐降低。Z-pin增强接头分层损伤模型模拟结果与试验结果基本吻合。
- Z-pin增强树脂基 /
- 复合材料 /
- 单搭接接头 /
- 低速冲击 /
- 有限元模拟 /
- 冲击后强度
Abstract: To study the impact resistance performances of resin matrix composite joints reinforced by Z-pin, single lap joint specimens reinforced by Z-pin were prepared. The crack propagation along Z-pin/laminates interface was compared with different resins matrix of Z-pin. Z-pin pullout and lap shear tests were carried out to study the after-impact pullout strength of Z-pin and after-impact shear strength of single lap joint, respectively. The ultrasonic C-scan method combined with finite element simulation was utilized to explore the delamination damage area of joint interface. The results showed that compared with the BMI resin matrix Z-pin, the resistance performance between epoxy Z-pin/epoxy laminates was stronger at the same impact energy. With the increase of impact energy, the crack propagation was more significant. Z-pin reinforced resin matrix composites remarkably reduced delamination damage area and improved the after-inpact shear strength. The delamination damage area of joint reinforced by Z-pin was 40%, and its reduction of after-impact shear strength was 24.89% when Z-pins volume fraction was 1.5% and diameter was 0.5mm.With the increase of Z-pin volume fraction, the delamination damage area decreased gradually, while the after-impact shear strength increased firstly and then decreased. The damage area of lap surface increased as the increment of Z-pin diameter while the after-impact shear strength decreased. The results of finite element modeling were consistent with the test results.
- Z-pin reinforced resin matrix /
- composites /
- single lap joints /
- low velocity impact /
- finite element simulation /
- after-impact shear strength
