高超声速再入飞行器的多孔流动控制

金亮; 谢攀; 黄伟; 柳军

doi:10.13224/j.cnki.jasp.2018.03.023

高超声速再入飞行器的多孔流动控制

doi: 10.13224/j.cnki.jasp.2018.03.023

金亮¹,
谢攀²,
黄伟¹,
柳军¹

1.
国防科技大学航天科学与工程学院,长沙 410073
2.
上海技术研究院上海卫星工程研究所,上海 200240

基金项目: 上海航天科技创新基金（SAST201419）

计量
- 文章访问数: 1128
- HTML浏览量: 272
- PDF量: 592
- 被引次数: 0
出版历程
- 收稿日期: 2016-08-24
- 刊出日期: 2018-03-28

Flow control of hypersonic reentry vehicle based on multi-jets interaction

摘要

摘要: 针对高超声速再入飞行器流动控制问题,提出一种头部进气、尾部排气的多孔流动控制概念。采用Fluent软件针对高超声速再入飞行器无孔模型、排气孔模型在马赫数为6,高度为25km状态下开展了三维雷诺平均N-S方程(RANS)数值模拟研究。结果表明:排气孔模型阻力系数略有增加,下排气孔(SH-DB)模型产生正的升力系数增量和低头力矩增量,上排气孔(SH-UB)模型产生负的升力系数增量和抬头力矩增量,实现了无活动气动面产生控制力矩的目的,为高超声速再入飞行器复合控制提供了参考。
- 高超声速 /
- 再入飞行器 /
- 流动控制 /
- 多孔喷流 /
- 喷流干扰
Abstract: A concept of multi-jets flow control was proposed for a hypersonic reentry vehicle. The high pressure air behind the bow shock flowed into the tunnel through the multihole head, and then sprayed out through the downstream multi-jets arrays. The 3-D Reynold-averaged Navier-Stokes (RANS) simulations based on Fluent software were conducted to study the effect of multi-jets configuration at Mach number of 6,height of 25km. The results showed that the multi-jets flow induced a drag coefficient increment for both the side-hole down-bottom (SH-DB) case and the side-hole upper-bottom (SH-UB) case. The increment of lift coefficient and head-down moment was observed for the SH-DB case, and the decrement of lift coefficient and head-up moment was observed for the SH-UB case. This study provides a method of using non-movement aerodynamic control surface to produce control moment, and also a reference for combination control of hypersonic reentry vehicle.
- hypersonic /
- reentry vehicle /
- flow control /
- multi-jets /
- jet interaction

HTML

参考文献(19)

[1]	李素循.近空间飞行器的气动复合控制原理及研究进展［J］.力学进展,2009,39(6):740-755.LI Suxun.Progress in aerodynamics of combination control for vehicles at high speed［J］.Advances in Mechanics,2009,39(6):740-755.(in Chinese)
[2]	ALKANDRY H,BOYD I D,REED E M,et al.Aerodynamic interactions of reaction-control-system jets for atmospheric entry aeroshells［J］.AIAA Journal,2013,51(5):1105-1118.
[3]	DYAKONOV A A,GLASS C E,DESAI P N,et al.Analysis of effectiveness of phoenix entry reaction control system［J］.Journal of Spacecraft and Rockets,2011,48(5):746-755.
[4]	JOHANSEN C T,DANEHY P M,ASHCRAFT S W,et al.Planar laser-induced fluorescence of mars science laboratory reaction control system jets［J］.Journal of Spacecraft and Rockets,2013,50(4):781-792.
[5]	GROVER M R,CICHY B D.Overview of the phoenix entry,descent,and landing system architecture［J］.Journal of Spacecraft and Rockets,2011,48(5):706-712.
[6]	杨希祥,费阳,江振宇,等.超声速/高超声速来流中侧向喷流干扰流场数值模拟［J］.航空动力学报,2010,25(11):2437-2442.YANG Xixiang,FEI Yang,JIANG Zhenyu,et al.Numerical simulatio of lateral jet interaction flow field in supersonic/hypersonic flow［J］.Journal of Aerospace Power,2010,25(11):2437-2442.(in Chinese)
[7]	杨磊,叶正寅.超声速飞行器侧向喷流干扰流场传统数值模拟方法的误差分析［J］.航空动力学报,2015,30(10):2508-2515.YANG Lei,YE Zhengyin.Error analysis of lateral jet interaction flow field of supersonic vehicle with traditional numerical method［J］.Journal of Aerospace Power,2015,30(10):2508-2515.(in Chinese)
[8]	赵法明,王江峰.带舵旋成体侧向喷流流场特性分析［J］.航空动力学报,2016,31(3):726-732.ZHAO Faming,WANG Jiangfeng.Analysis on flow field characteristics of lateral jet on slender body［J］.Journal of Aerospace Power,2016,31(3):726-732.(in Chinese)
[9]	SRIVASTAVA B.Computational analysis and validation for lateral jet controlled missiles［J］.Journal of Spacecraft and Rockets,1997,34(5):584-592.
[10]	JACOBSEN L S,SCHETZ J A,NG W F.The flowfield near a multiport injector array in a supersonic flow［R］.AIAA 98-3019,1998.
[11]	王军旗,李素循.超声速多喷流干扰流场特性研究［J］.力学学报,2009,41(4):575-583.WANG Junqi,LI Suxun.Study on the characteristics of interaction flowfields induced by supersonic multi-jets［J］.Chinese Journal of Theoretical and Applied Mechanics,2009,41(4):575-583.(in Chinese)
[12]	徐筠,徐翔,王志坚,等.多喷口喷流对侧向喷流流场影响的风洞试验研究［J］.实验流体力学,2012,26(5):13-16.XU Yun,XU Xiang,WANG Zhijian,et al.Experimental investigation on multi-jet interference［J］.Journal of Experiments in Fluid Mechanics,2012,26(5):13-16.(in Chinese)
[13]	RUFFIN S M,GUPTA A,MARSHALL D.Supersonic channel airfoils for reduced drag［J］.AIAA Journal,2000,38(3):480-486.
[14]	GUPTA A,RUFFIN S M,NEWFIELD M E,et al.Aerothermodynamic performance enhancement of sphere-cones using the artificially blunted leading-edge concept［J］.Journal of Spacecraft and Rockets,2000,37(2):235-241.
[15]	王江峰,伍贻兆.非结构网格高超声速绕流数值模拟及涵道构型减阻特性分析［J］.南京航空航天大学学报,2004,36(6):671-676.WANG Jiangfeng,WU Yizhao.Numerical simulation for hypersonic flow on unstructured grid and analysis of drag induction effects on channel-configuration［J］.Journal of Nanjing University of Aeronautics and Astronautics,2004,36(6):671-676.(in Chinese)
[16]	耿云飞,阎超.曲形槽道ABLE概念在超声速翼型减阻中的应用［J］.空气动力学学报,2010,28(1):70-75. GENG Yunfei,YAN Chao.Application of curved channel ABLE conception to supersonic airfoil drag reduction［J］.Acta Aerodynamica Sinica,2010,28(1):70-75.(in Chinese)
[17]	黄礼铿,高正红.翼尖喷流引流管道内流数值模拟［J］.航空动力学报,2009,24(9):2101-2106.HUANG Likeng,GAO Zhenghong.Numerical simulation of conductive pipes inner flow［J］.Journal of Aerospace Power,2009,24(9):2101-2106.(in Chinese)
[18]	KUMAR R,ALI M Y,ALVI F S,et al.Generation and control of oblique shocks using microjets［J］.AIAA Journal,2011,49(12):2751-2759.
[19]	AHMED K A,ALI M Y,ALVI F S.Mixing characteristics of active microjet-based actuators in a supersonic backward-facing-step flow［J］.AIAA Journal,2014,52(12):2855-2866.
