低气压条件下多缝式等离子体合成射流激励器特性实验

张宇超; 谭慧俊; 程林; 何小明

doi:10.13224/j.cnki.jasp.2018.03.025

低气压条件下多缝式等离子体合成射流激励器特性实验

doi: 10.13224/j.cnki.jasp.2018.03.025

南京航空航天大学能源与动力学院江苏省航空动力系统重点实验室,南京 210016

基金项目: 国家自然科学基金重点项目（11532007）; 江苏高校优势学科建设工程资助项目

计量
- 文章访问数: 724
- HTML浏览量: 90
- PDF量: 525
- 被引次数: 0
出版历程
- 收稿日期: 2016-06-16
- 刊出日期: 2018-03-28

Experiment on characteristics of plasma synthetic jet actuator with multiple slots under low pressure condition

摘要

摘要: 设计了一种低气压条件下工作的大间距多缝式等离子体合成射流激励器,旨在应用于高空飞行器的内部流动控制。实验中利用气体放电电压在低气压条件下迅速降低的特性,将激励器放电电极间距设计为26mm,使激励器腔体和出气口均得到显著拉长,并通过电参数测量、高速纹影观察分别研究了其放电特性及瞬态流场特性。实验结果表明：激励器的初始射流锋面速度达到了761m/s,故在高速流动控制中具有较大的应用潜力。此外,激励器射流导致的压缩波和射流边界均接近半椭圆形,具有较大的流场均匀区,因此其流动干扰能力和动量交换能力较常规孔式射流要更强。
- 多缝式等离子体合成射流激励器 /
- 低气压 /
- 高空飞行器 /
- 流动控制 /
- 放电
Abstract: A large interval plasma synthetic jet actuator (PSJA) with multiple slots under low pressure condition was designed to control the flow-field for high-altitude vehicle.Since the breakdown voltage decreased rapidly under low pressure condition, the distance of cathode and anode can be extended to 26mm, much larger than that of traditional PSJA. This optimization also could make the cavity and output of actuator extend remarkably. The discharge characteristics and flow-field were researched by electric parameter measurement system and high-speed schlieren technology, respectively.The results showed that the initial jet velocity of the actuator reached 761m/s, indicating the actuator had excellent application prospect in high speed flow control.In addition, comparing with the normal perforated jet generated by the actuator, the compression wave and plasma jet appeared in an ellipse shape with a large flat portion, contributing to enhance the perturbation and momentum exchange capability.
- plasma synthetic jet actuator with multiple slots /
- low pressure /
- high-altitude vehicle /
- flow control /
- discharge

HTML

参考文献(18)

[1]	KRAL L D.Active flow control technology［R］.ASME Paper FEDSM 2001-18196,2000.
[2]	GADELHAK M.Flow control:the future［J］.Journal of Aircraft,2001,38(3):402-418.
[3]	GROSSMAN K R,CYBYK B Z,VANWIE D M.Sparkjet actuators for flow control［R］.AIAA-2003-57,2003.
[4]	李应红.航空等离子体动力学与技术的发展［J］.航空工程进展,2011,2(2):127-132.LI Yinghong.Development of aero-plasma dynamics and technology［J］.Advances in Aeronautical Science and Engineering,2011,2(2):127-132.(in Chinese)
[5]	CYBYK B Z,GROSSMAN K R,WILKERSON J T,et al.Single-pulse performance of the sparkjet flow control actuator［R］.AIAA-2005-401,2005.
[6]	CYBYK B Z,WILKERSON J T,GROSSMAN K R.Performance character-istics of the sparkjet flow control actuator［R］.AIAA-2004-2131,2004.
[7]	CYBYK B Z,SIMON D H,LAND H,et al.Experimental characterization of a supersonic flow control actuator［J］.AIAA-2006-478,2006.
[8]	BELINGER A,HARDY P,BARRICAU P,et al.Influence of the energy dissipation rate in the discharge of a plasma synthetic jet actuator［J］.Journal of Physics:D Applied Physics,2011,44(36):365201.1-365201.45.
[9]	NARAYANASWAMY V,RAJ L L,CLEMENS N T.Control of a shock/boundary-layer interaction by using a pulsed-plasma jet actuator［J］.AIAA Journal,2012,50(1)：246-249.
[10]	NARAYANASWAMY V,RAJA L L,CLEMENS N T.Control of unsteadiness of a shock wave/turbulent boundary layer inter-action by using a pulsed-plasma-jet actuator［J］.Physics of Fluids,2012,24(7):076101.1-076101.22.
[11]	WU Yun,LI Yinghong,LIANG Hua,et al.Nanosecond pulsed discharge plasma actuation:characteristics and flow control performance［R］.AIAA-2014-2118,2014.
[12]	梁华,李应红,吴云,等.等离子体气动激励的数值仿真［J］.高电压技术,2009,35(5):1071-1076.LIANG Hua,LI Yinghong,WU Yun,et al.Numerical simulation of plasma aerodynamic actuation［J］.High Voltage Engineering,2009,35(5):1071-1076.(in Chinese)
[13]	孙权,崔巍,程邦勤,等.等离子体气动激励控制超声速边界层分离的实验研究［J］.航空学报,2015,36(2):501-509.SUN Quan,CUI Wei,CHENG Bangqin,et al.Experimental investigation on supersonic boundary layer separation by plasma aerodynamic actuation［J］.Acta Aeronautica et Astronautica Sinica,2015,36(2):501-509.(in Chinese)
[14]	宋慧敏,李应红,魏沣亭,等.等离子体电流体动力激励器的建模与仿真［J］.高电压技术,2006,32(3):72-74.SONG Huimin,LI Yinghong,WEI Fengting,et al.Modeling and simulation of plasma electro hydro dynamic actuator［J］.High Voltage Engineering,2006,32(3):72-74 (in Chinese)
[15]	JIN D,CUI W,LI Y,et al.Characteristics of pulsed plasma synthetic jet and its control effect on supersonic flow［J］.Chinese Journal of Aeronautics,2015,28(1):66-76.
[16]	ZONG H,CUI W,WU Y,et al.Influence of capacitor energy on performance of a three-electrode plasma synthetic jet actuator［J］.Sensors and Actuators:A Physical,2015,222:114-121.
[17]	宗豪华,宋慧敏,梁华,等.纳秒脉冲等离子体合成射流特性实验研究［J］.推进技术,2015,36(10):1474-1478.ZONG Haohua,SONG Huimin,LIANG Hua,et al.Experimental study on characteristic of nanosecond pulsed plasma synthetic jet［J］.Journal of Propulsion Technology,2015,36(10):1474-1478.(in Chinese)
[18]	王林,罗振兵,夏智勋,等.等离子体合成射流能量效率及工作特性研究［J］.物理学报,2013,62(12):125207.1-125207.10.WANG Lin,LUO Zhenbing,XIA Zhixun,et al.Energy efficiency and performance characteristics of plasma synthetic jet［J］.Acta Physica Sinica,2013,62(12):125207.1-125207.10.(in Chinese)
