兼顾两种模式核心机驱动风扇级气动优化设计

曹晖; 周正贵; 胡骏; 彭国峰; 屠宝锋

doi:10.13224/j.cnki.jasp.2018.03.026

兼顾两种模式核心机驱动风扇级气动优化设计

doi: 10.13224/j.cnki.jasp.2018.03.026

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 900
- HTML浏览量: 158
- PDF量: 533
- 被引次数: 0
出版历程
- 收稿日期: 2016-09-14
- 刊出日期: 2018-03-28

Aerodynamic optimization design of core driven fan stage on balance of two modes

摘要

摘要: 提出兼顾两种模式核心机驱动风扇级气动设计方法。将S2流面通流计算与遗传算法相结合,寻找最优进口导叶（IGV）出口气流角、关闭角度、单双外涵压比沿叶高分布；实现在转子气动设计时兼顾两种模式。根据IGV基础叶型弯度、安装角对单双外涵流动损失影响研究,确定可调IGV关键参数,实现在IGV气动设计时兼顾两种模式。采用多点优化进行静子叶型优化设计,实现在静子气动设计时兼顾两种模式。对所设计的核心机驱动风扇级进行三维流场计算,结果表明：两种模式在满足总压比和质量流量前提下,单、双外涵模式等熵效率分别达到88.05%和87.17%,且稳定裕度分别达到15.65%和16.28%。
- 核心机驱动风扇级 /
- 变循环发动机 /
- 优化设计 /
- S2流面 /
- 流场数值模拟
Abstract: An aerodynamic design method was proposed for core driven fan stages on balances of the single and double bypass modes. Combining the S2 stream surface through-flow calculation with a genetic algorithm, the optimal inlet guide vane (IGV) outlet angle, closed angle and pressure ratio distributions in the two modes along the blade spans were found, achieving the balance on the rotor aerodynamic design. The key geometric parameters of the variable IGV were determined according to the study on the influences of the IGV profile camber and installation angle on flow losses in the two modes, achieving the balance on the IGV design. The stator blade design was conducted by using multi-point optimization method, achieving the balance on the stator aerodynamic design. Three-dimensional flow fields of a designed core driven fan stage were numerically simulated, and the results showed that the isentropy efficiency at the design point reached 88.05% and 87.17% in single and double bypass mode, respectively under the premise of satisfying the total pressure ratio and mass flow rate in two modes, and the stability margins in the two modes reached 15.65% and 16.28%, respectively.
- core driven fan stage /
- variable cycle engine /
- optimization design /
- S2 stream surface /
- numerical simulation of flow field

HTML

参考文献(18)

[1]	林雪平.变几何发动机稳态性能计算研究［D］.西安:西北工业大学,2004.LIN Xueping.Research on calculation of steady-state performance of variable geometry engine［D］.Xi’an:Northwestern Polytechnical University,2004.(in Chinese)
[2]	方昌德.变循环发动机［J］.燃气涡轮试验与研究,2004,17(3):1-5.FANG Changde.Variable cycle engine［J］.Gas Turbine Experiment and Research,2004,17(3):1-5.(in Chinese)
[3]	HOWLETTE R A,SABATELLA J,JOHNSON J,et al.Advanced supersonic propulsion study［R］.NASA CR-134904,1975.
[4]	ALLAN R D.Advanced supersonic propulsion system technology study［R］.NASA CR-134913,1975.
[5]	NASCIMENTO M A R.The selective bleed variable cycle engine［D］.Bedfordshire,UK：Cranfield Institute of Technology,1992.
[6]	HABRARD A.The variable-cycle engine-a solution to the economical and environmental challenge of the future supersonic transport［C］∥European Symposium on the Future of High Speed Air Transport Proceedings.Strasbourg,France:［s.n.］,1990:211-218.
[7]	MIYAGI H,KIMURA H,CABE J,et al.Combined cycle engine research in Japanese HYPR program［R］.AIAA 95-2751,1995.
[8]	刘红霞.GE公司变循环发动机的发展［J］.航空发动机,2015,41(2):93-98.LIU Hongxia．The development of variable cycle engine at GE［J］.Aeroengine,2015,41(2):93-98.(in Chinese)
[9]	FRENCH M,ALLEN C.NASA VCE test bed engine aerodynamic performance characteristics and results［R］.AIAA 81-1594,1981.
[10]	VDOVIAK J W,KNOTT P R,EBACKER J J.Aerodynamic/acoustic performance of YJ101/double bypass VCE with coannualr plug nozzle［R］.NASA CR-159869,1981.
[11]	张鑫,刘宝杰.核心机驱动风扇级的气动设计特点分析［J］.航空动力学报,2010,25(2):434-442.ZHANG Xin,LIU Baojie.Analysis of aerodynamic design characteristics of core driven fan stage［J］.Journal of Aerospace Power,2010,25(2):434-442.(in Chinese)
[12]	张鑫,刘宝杰.核心机驱动风扇级匹配特性分析［J］.航空学报,2015,36(9):2850-2858.ZHANG Xin,LIU Baojie.Matching characteristics of core driven fan stage［J］.Acta Aeronautica et Astronautica Sinica,2015,36(9):2850-2858.(in Chinese)
[13]	赖安卿,胡骏,屠宝锋.核心机驱动风扇级气动设计方案［J］.航空动力学报,2014,29(9):2229-2238.LAI Anqing,HU Jun,TU Baofeng.Scheme on aerodynamic design of core driven fan stage［J］.Journal of Aerospace Power,2014,29(9):2229-2238.(in Chinese)
[14]	周正贵,邱名,徐夏,等.压气机/风扇二维叶型自动优化设计［J］.航空学报,2011,32(11):1987-1997.ZHOU Zhenggui,QIU Ming,XU Xia,et al.Automatic optimization design of compressor/fan 2D blade profiles［J］.Acta Aeronautica et Astronautica Sinica,2011,32(11):1987-1997.(in Chinese)
[15]	周正贵.混合遗传算法及其在叶片自动优化设计中的应用［J］.航空学报,2002,23(6):571-574.ZHOU Zhenggui.Composite genetic algorithm and its application to automatic optimization of turbomachinery blade［J］.Acta Aeronautica et Astronautica Sinica,2002,23(6):571-574.(in Chinese)
[16]	周正贵.压气机/风扇叶片自动优化设计［M］.北京:国防工业出版社,2013:149-163.
[17]	徐国华,周正贵.任意回转面叶型优化设计研究［J］.机械制造,2013,51(4):30-33.XU Guohua,ZHOU Zhenggui.Research on optimization design of arbitrary rotating surface［J］.Machinery,2013,51(4):30-33.(in Chinese)
[18]	刘龙龙,周正贵,陶胜.基于遗传算法的2维叶型优化设计［J］.航空发动机,2014,40(5):50-56.LIU Longlong,ZHOU Zhenggui,TAO Sheng.Optimization design on 2D blade profiles based on genetic algorithm［J］.Aeroengine,2014,40(5):50-56.(in Chinese)
