基于两相流的涡轮增压器轴承油膜特性分析

李亚静; 丁水汀; 杜发荣; 毕金光; 王志宏; 周煜

doi:10.13224/j.cnki.jasp.2018.03.029

基于两相流的涡轮增压器轴承油膜特性分析

doi: 10.13224/j.cnki.jasp.2018.03.029

1.
北京航空航天大学能源与动力工程学院，北京 100091；宁波威孚天力增压技术股份有限公司，浙江宁波 315034
2.
北京航空航天大学能源与动力工程学院，北京 100091
3.
宁波威孚天力增压技术股份有限公司，浙江宁波 315034
4.
北京航空航天大学交通科学与工程学院，北京 100091

基金项目: 国家自然科学基金（51205015,51775025）; 国家实验室青年总师培育基金（YWF-16-GJSYS-24）

计量
- 文章访问数: 786
- HTML浏览量: 115
- PDF量: 470
- 被引次数: 0
出版历程
- 收稿日期: 2016-08-23
- 刊出日期: 2018-03-28

Analysis on oil film characteristics of turbocharger bearing based ontwo-phase flow

摘要

摘要: 利用计算流体动力学方法，分析了涡轮增压器半浮动轴承内油膜静力特性，考虑两相流油膜破裂和非牛顿流体润滑油模型，计算分析带轴向贯通油槽的油膜压力和汽化比率分布情况，以及转速、偏心率、润滑油温度和润滑油压力等因素对油膜承载力和摩擦功耗的影响规律。结果表明: 温度和转速是影响两相流油膜摩擦功耗的主要因素，分段楔形油膜的摩擦功耗与贯通轴向油槽的位置变化无关，油膜的气穴空化也不会引起摩擦功耗的明显变化；两相流油膜承载力随着偏心率的增加、油温的降低和油压增大而有不同程度的增大，但随转速的变化规律不一致；与此同时，小偏心率、高油压、低油温有利于减轻两相流油膜发生气穴空化的比率。
- 半浮动轴承内油膜 /
- 摩擦功耗 /
- 两相流 /
- 非牛顿流体 /
- 空化
Abstract: The static characteristics of inner oil film of turbocharger semi-floating ring bearing were calculated by CFD method. For the inner oil film with axial through grooves, the distribution of oil film pressure and air-phase volume fraction were predicted considering the influence of two-phase flow cavitation and non-Newton fluid. The change rules of oil film bearing capacity and friction power losses with the journal speeds, eccentricity ratio, oil temperature and pressure were also evaluated respectively. The results showed that the uppermost impact factors to friction power losses were oil temperature and journal speed, while the rare relationship with the position of through axial grooves and the cavitation at the negative pressure zone was also found. The oil film bearing capacity can be improved by increasing the eccentricity ratio and oil pressure, or cooling the oil temperature. However, the law of variation with speed up was not consistent. Simultaneously, it was beneficial for alleviating air-phase volume fraction to reduce the eccentricity ratio and oil temperature, or raise the oil pressure.
- semi-floating bearing inner oil film /
- friction power losses /
- two-phase flow /
- non-Newton fluid /
- cavitation

HTML

参考文献(21)

[1]	朱大鑫.涡轮增压与涡轮增压器［M］.北京：机械工业出版社,1992.
[2]	DOWSON A D,TAYLOR C M.Cavitation in bearings［J］.Annual Review of Fluid Mechanics,2003,11(1):35-65.
[3]	NGUYEN-SCHFER H.Rotordynamics of automotive turbochargers［M］.Berlin:Springer Berlin Heidelberg,2012.
[4]	SZERIi A Z.Fluid film lubrication［M］.Cambridge：Cambridge University Press,1980.
[5]	NAGARAJU T,SHARMA S C,JAIN S C.Study of orifice compensated hole-entry hybrid journal bearing considering surface roughness and flexibility effects［J］.Tribology International,2006,39(7):715-725.
[6]	ALMQVIST T,ALMQVIST A,LARSSON R.A comparison between computational fluid dynamic and Reynolds approaches for simulating transient EHL line contacts［J］.Tribology International,2004,37(1):61-69.
[7]	CHASALEVRIS A.Finite length floating ring bearings:operational characteristics using analytical methods［J］.Tribology International,2016,49(3):571-590.
[8]	ROY L.Thermo-hydrodynamic performance of grooved oil journal bearing［J］.Tribology International,2009,42(8):1187-1198.
[9]	LIANG Feng,ZHOU Ming,XU Quanyong.Effects of semi-floating ring bearing outer clearance on the subsynchronous oscillation of turbocharger rotor［J］.Chinese Journal of Mechanical Engineering,2016,29(5):901-910.
[10]	GUO Zenglin,HIRANO T,KIRK R.Application of CFD analysis for rotating machinery:Part Ⅰ hydrodynamic,hydrostatic bearings and squeeze film damper［J］.Journal of Engineering for Gas Turbines and Power,2005,127(2):445-451.
[11]	张楚.基于CFD方法的滑动轴承动特性分析［D］.南京：东南大学,2011.ZHANG Chu.Research on the dynamic characteristics of journal bearing based on CFD analysis［D］.Nanjing:Southeast University,2011.(in Chinese)
[12]	于桂昌.基于CFD的滑动轴承瞬态流场计算［D］.杭州：浙江大学,2010.
[13]	SOLGHAR A A,BRITO F P,ABDOLZADEH M,et al.Numerical study of twin groove journal bearings performance under steady-state condition［J］.Lubrication Science,2013,27(2):83-102.
[14]	YIN Song,GU Chunwei.Development and validation of a three-dimensional computational fluid dynamics analysis for journal bearings considering cavitation and conjugate heat transfer［J］.Journal of Engineering for Gas Turbines and Power,2015,137(12):122502.
[15]	LIN Qiyin,WEI Zhengying,WANG Ning,et al.Analysis on the lubrication performances of journal bearing system using computational fluid dynamics and fluid-structure interaction considering thermal influence and cavitation［J］.Tribology International,2013,46(3):8-15.
[16]	DELIGANT M,PODEVIN P,DESCOMBES G.CFD model for turbocharger journal bearing performances［J］.Applied Thermal Engineering,2011,31(5):811-819.
[17]	TAYLOR R I.The inclusion of lubricant shear thinning in the short bearing approximation［J］.Journal of Engineering Tribology,1999,213(1):35-46.
[18]	SINGHAL A K,ATHAVALE M M,LI Huiying,et al.Mathematical basis and validation of the full cavitation model［J］.Journal of Fluids Engineering,2002,124(3):617-624.
[19]	MERUANE V,PASCUAL R.Identification of nonlinear dynamic coefficients in plain journal bearings［J］.Tribology International,2008,41(8):743-754.
[20]	李强,许伟伟,赵月,等.基于瞬态流场计算的滑动轴承静平衡位置求解［J］.中国石油大学学报,2015,39（2）:105-110.LI Qiang,XU Weiwei,ZHAO Yue,et al.Solution of static equilibrium position of journal bearing based on transient flow calculation［J］.Journal of China University of Petroleum,2015,39(2):105-110.(in Chinese)
[21]	SJBERG E.Friction characterization of turbocharger bearing［D］.Stockholm:Kungliga Tekniska Hgskolan,2013.
