燃烧室进口流场对某回流燃烧室性能影响的数值计算

王梅娟; 成胜军; 宋双文; 陈延庚

doi:10.13224/j.cnki.jasp.2018.06.001

燃烧室进口流场对某回流燃烧室性能影响的数值计算

doi: 10.13224/j.cnki.jasp.2018.06.001

中国航空发动机集团湖南动力机械研究所，湖南株洲 412002

计量
- 文章访问数: 1021
- HTML浏览量: 196
- PDF量: 807
- 被引次数: 0
出版历程
- 收稿日期: 2018-03-01
- 刊出日期: 2018-06-28

Numerical simulation on influence of flow field of combustor inlet on a certain reversed-flow combustor performance

摘要

摘要: 为了获得燃烧室进口流场对某回流燃烧室性能的影响规律，通过在轴向扩压器上安装带偏转角度的导向叶片，获得不均匀的燃烧室进口流场。在试验验证的基础上，对均匀进气、导向叶片偏转角度25°及导向叶片偏转角度35°共计三种方案的燃烧室性能进行了数值模拟研究。结果表明：带偏转角度的导向叶片使燃烧室进口流场变得不均匀，燃烧室进口截面的气流具有一定的偏转角度和切向分速度；带偏转角度的导向叶片使主燃孔和掺混孔的进气存在一定的偏转角度，随着导向叶片偏转角度的加大，主燃孔和掺混孔的轴向速度小幅增加，主燃孔和掺混孔的切向速度逐渐加大且增幅较大；随着导向叶片偏转角度的加大，燃烧室总压恢复系数逐渐降低；带偏转角度的导向叶片对燃烧室的燃烧效率影响不大；随着导向叶片偏转角度的加大，燃烧室出口温度分布系数（OTDF）逐渐降低且降低幅度较大；在同一径向高度，随着导向叶片偏转角度的加大，燃烧室出口周向温度分布不均匀度逐渐降低。
- 回流燃烧室 /
- 轴向扩压器 /
- 导向叶片 /
- 进口流场 /
- 燃烧室性能
Abstract: The asymmetrical flow field of combustor inlet was obtained by which the oriented vane was installed in the axial diffuser of a reverse-flow combustor test piece, and how the combustor performance was affected by the variety of the combustor inlet flow field was simulated based on experiments verification, and the scheme included no vane, vane deflexion angle of 25° and vane deflexion angle of 35°. The results indicate that the unevenness of the flow field of the combustor inlet is caused by the oriented vane with deflection angle. The flow of combustor inlet takes on a certain deflexion angle and tangential velocity. The airflow direction of the primary holes and dilution holes has a deflexion angle. When the deflexion angle of the oriented vane increases, the axial velocity of the primary holes and dilution holes increases to a certain extent, and the tangential velocity of the primary holes and dilution holes increases greatly. The total pressure recovery coefficient decreases when the deflexion angle of the oriented vane increases. With the increase of deflection angle of the oriented vane, the combustion efficiency is invariable basically. The outlet temperature distribution factor(OTDF) decreases greatly, and the temperature circumferential distribution unevenness decreases at the same radial height.
- reversed-flow combustor /
- axial diffuser /
- oriented vane /
- inlet flow field /
- combustor performance

HTML

参考文献(18)

[1]	金如山.航空燃气轮机燃烧室［M］.北京：宇航出版社，1985.
[2]	金如山.燃烧室进口流场的几个问题［R］.北京航空学院科学研究报告 BH-C 241,1977.
[3]	CLARKE J S,JACKSON S R.General consideration in the design of combustion chambers for aircraft and industrial gas turbines［R］.SAE Technical Paper 640009,1962.
[4]	CARROTTE J F,MCGUIRK J J.Enhanced external aerodynamic performance of a generic combustor using an integrated OGV/pre-diffuser design technique［R］.ASME Paper GT2006-90184,2006.
[5]	WALKER A D,CARROTTE J F,MCGUIRK J J.Compressor-diffuser-combustor aerodynamic interactions in lean module combustors［R］.ASME Paper GT2007-27872,2007.
[6]	SHADOWEN J H,EGAN W J J.Evaluation of circumferental airflow uniformity entering combustors from compressors［R］.NASA CR-121009,1972.
[7]	赵硕，黄章芳，成胜军.进气对某回流燃烧室性能影响的试验［J］.航空动力学报,2015,30(6):1293-1297.ZHAO Shuo,HUANG Zhangfang,CHENG Shengjun.Experiment on effect of inlet airflow on performance of a reverse-flow combusor［J］.Journal of Aerospace Power,2015,30(6):1293-1297.(in Chinese)
[8]	李继保，金如山.燃烧室出口径向温度分布试验及分析模型［J］.航空动力学报,1989,4(1):37-40.LI Jibao,JIN Rushan.Test and model for analyzing theradial temperature distribution at the outlet of a combustor［J］.Journal of Aerospace Power,1989,4(1):37-40.(in Chinese)
[9]	SCHULTZ D F,PARKINS P J.Effects of radial and circumferential inlet velocity profile distortions on performance of a short-length double-annular ram induction combustor［R］.NASA TND-6706,1972.
[10]	HUMENIK F M.Performance of short length turbojet combustor insensitive to radial distortion of inlet airflow［R］.NASA TND-5570,1970.
[11]	莫礼孝.燃烧室进口流场对流量分配和总压损失的影响［J］.燃气涡轮试验与研究，1991,4(1)：223-229.MO Lixiao.Influences of the combustor inlet field on the flux distribution and total pressure loss［J］.Gas Turbine Experiment and Research，1991,4(1)：223-229.(in Chinese)
[12]	顾铭企.燃烧室进口流场畸变对出口温度场品质影响的试验研究［J］.航空发动机，1994(2)：1-11.GU Mingqi.Experiment study on influences of the combustor inlet field distortion on outlet temperature distribution factor［J］.Aeroengine,1994(2)：1-11.(in Chinese)
[13]	杨锐.进口流场畸变对燃烧室性能的影响［J］.航空发动机，1994(3)：28-33.YANG Rui.Influences of the combustor inlet field distortion on combustor performance［J］.Aeroengine,1994(3)：28-33.(in Chinese)
[14]	雷雨冰，赵坚行.进口速度分布对短突扩压器性能的影响［J］.南京航空航天大学学报,1999,3(2)：209-213.LEI Yubing,ZHAO Jianxing.Influence of inlet velocity distribution on dump-diffuser performance［J］.Journal of Nanjing University of Aeronautics and Astronautics,1999,3(2)：209-213.(in Chinese)
[15]	王枫，张贵田，黄日鑫.入口非均匀流对亚燃燃烧室性能影响数值研究［J］.航空工程进展，2012,3(2)：223-228.WANG Feng,ZHANG Guitian,HUANG Rixin.Numerical investigation on performance of a ramjet combustion chamber with nonuniform inlet flows［J］.Advances in Aeronautical Science and Engineering,2012,3(2)：223-228.(in Chinese)
[16]	JANUS M C，RICHARDS G A，YIP M J，et al.Effects of ambient conditions and fuel composition on combustion stability［J］.ASME Paper 1997-GT-266,1997.
[17]	STRAUB D,RICHARDS G,YIP M J.Importance of axial swirl vane location on combustion dynamics for lean premix fuel injectors［J］.AIAA 98-3909,1998.
[18]	吴鹏龙.进气畸变和燃油脉动对燃烧室内燃烧流场的影响研究［D］.南京:南京航空航天大学,2012.WU Penglong.Research on influences of inlet distortion and fuel injection pulse on combustor combustion flow field［D］.Nanjing:Nanjing University of Aeronautics and Astronautics,2012.(in Chinese)
