凹腔支板火焰稳定器自燃点火性能初步试验

刘玉英; 谢奕; 柳杨; 金捷

doi:10.13224/j.cnki.jasp.2018.06.003

凹腔支板火焰稳定器自燃点火性能初步试验

doi: 10.13224/j.cnki.jasp.2018.06.003

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 航空科学基金（2013ZB51014）

计量
- 文章访问数: 1106
- HTML浏览量: 310
- PDF量: 552
- 被引次数: 0
出版历程
- 收稿日期: 2016-12-09
- 刊出日期: 2018-06-28

Preliminary experiment on spontaneous ignition performances of cavity-based strut flameholder

摘要

摘要: 以凹腔支板火焰稳定器为研究对象,在进口温度为750~900℃、马赫数为0.20~0.28、氧气体积分数为13.4%~15.8%、喷嘴距支板前缘5~50mm及常压的条件下,开展自燃点火性能的试验研究。试验表明：凹腔支板火焰稳定器在进口温度为850℃以上可成功实现自燃点火。自燃点火性能随进口温度的升高而提高；随着进口马赫数的提高,火焰稳定器自燃点火成功的温度范围越窄；随着燃油喷射距离的增大,稳定器自燃点火性能有所提高。稳定器的凹腔结构能够稳定火焰。
- 自燃 /
- 点火 /
- 支板火焰稳定器 /
- 钝体 /
- 凹腔
Abstract: The spontaneous ignition performances of a cavity-based strut flameholder were preliminarily investigated with spray distances of 5－50mm at atmospheric pressure, the air temperature and oxygen volume fraction were within the range of 750－900℃ and 13.4%－15.8%, Mach number ranged from 0.20－0.28. Results showed that the flameholder could be autoignited when the inlet temperature was above 850℃. As the inlet temperature increased, the performances of spontaneous ignition improved. When the inlet Mach number became larger, the temperature range for successful spontaneous ignition became narrower. With the increase of fuel injection distance, the autoignition performances of the stabilizer were improved. The cavity structure of the stabilizer could stabilize the flame.
- spontaneous combustion /
- ignition /
- strut flameholder /
- bluff body /
- cavity

HTML

参考文献(21)

[1]	LOVETT J,BROGAN T,PHILIPPONA D,et al.Development needs for advanced afterburner designs［R］.Fort Lauderdale:American Institute of Aeronautics and Astronautics,2004.
[2]	CLEMENTS T R,GRAVES C B.Augmentor burner:US 5385015［P］.1995-01-31.
[3]	KOSHOFFER J M.Method and apparatus for gas turbine engines:US6983601B2［P］.2006-01-10.
[4]	季鹤鸣,樊于军,杨茂林.新型内突扩加力燃烧室方案可行性分析［J］.航空发动机,2006,32(1):35-37.JI Heming,FAN Yujun,YANG Maolin.Feasibility analysis of a new inner dumped afterburner concept［J］.Aeroengine,2006,32(1):35-37.(in Chinese)
[5]	金捷,吴迪,季鹤鸣,等.带凹腔的支板火焰稳定装置及火焰稳定方法:CN102200292A［P］.2011-09-28.
[6]	吴迪,金捷,季鹤鸣.一种加力燃烧室凹腔支板火焰稳定方案研究［R］.贵阳:中国航空学会年第7届动力年会,2010.
[7]	吴迪,金捷,季鹤鸣,等.凹腔支板尾缘涡脱落频率试验研究［J］.航空发动机,2011,37(4):48-50.WU Di,JIN Jie,JI Heming,et al.Experimental study of vortex shedding frequency at trailing edge of a cavity-based strut［J］.Aeroengine,2011,37(4):48-50.(in Chinese)
[8]	刘雯佳,金捷,季鹤鸣.带凹腔支板的数值模拟［J］.燃气涡轮试验与研究,2010,23(4):35-38.LIU Wenjia,JIN Jie,JI Heming.Numerical simulation on strut with cavity［J］.Gas Turbine Experiment and Research,2010,23(4):35-38.(in Chinese)
[9]	刘广海,刘玉英.翼型支板火焰稳定器结构参数的研究［J］.航空动力学报,2015,30(6):1350-1356.LIU Guanghai,LIU Yuying.Investigation on structural parameters of airfoil shaped strut flame stabilizer［J］.Journal of Aerospace Power,2015,30(6):1350-1356.(in Chinese)
[10]	罗莲军,刘玉英,张文龙,等.喷油杆与凹腔支板稳定器近距匹配雾化特性［J］.航空动力学报,2013,28(11):2462-2467.LUO Lianjun,LIU Yuying,ZHANG Wenlong,et al.Atomization characteristics of fuel injector and cavity-based strut flame stabilizer under close-range matching condition［J］.Journal of Aerospace Power,2013,28(11):2462-2467.(in Chinese)
[11]	刘玉英,周弘毅,谢奕,等.喷油杆和凹腔支板稳定器近距匹配的液雾分布可视化研究［J］.航空动力学报,2018,33（3）：549-556.LIU Yuying,ZHOU Hongyi,XIE Yi,et al.Visualized investigation on spray distribution of close-couple fuel injector and strut with cavity flameholder system［J］.Journal of Aerospace Power,2018,33（3）：549-556.(in Chinese)
[12]	SCHULTZ D F,BRANSTETTER J R.Spontaneous ignition in afterburner segment tests at an inlet temperature of 1240 K and a pressure of 1 atmosphere with astm jet-a fuel［R］.NASA TM X-2952,1973.
[13]	BRANSTETTER J R,RECK G M.Afterburner performance of film-vaporizing V-gutters for inlet temperatures up to 1255 K［R］.NASA TM X-2855,1973.
[14]	郭成富,王勇,曹康.钝体火焰稳定器后方高温油气混合物的自燃燃烧［R］.江西九江:中国航空学会第11届燃烧与传热传质学术会议,1998.
[15]	徐兴平,张孝春,李江宁,等.燃油在高温高速气流中自燃规律的研究［R］.沈阳:中国航空学会第14届燃烧与传热传质学术交流会,2007.
[16]	周冠宇,柳杨,金捷,等.采用值班火焰稳定器作小型加温器的试验研究［R］.贵阳:中国航空学会第7届动力年会,2010.
[17]	柳杨.支板稳焰一体化新型火焰稳定器流动与燃烧性能研究［D］.北京:北京航空航天大学,2013.LIU Yang.Research on flow and combustion characters of novel strut flame-holder［D］.Beijing:Beijing University of Aeronautics and Astronautics,2013.(in Chinese)
[18]	GOKULAKRISHNAN P,FULLER C C,KLASSEN M S,et al.Ignition characteristics of alternative JP-8 and surrogate fuels under vitiated conditions［R］.Cleveland:American Institute of Aeronautics and Astronautics Incorporation,2014.
[19]	FULLER C C,GOKULAKRISHNAN P,KLASSEN M S,et al.Investigation of the effects of vitiated conditions on the autoignition of JP-8［R］.Denver:American Institute of Aeronautics and Astronautics,2009.
[20]	AGGARWAL S K.A review of spray ignition phenomena:present status and future research［J］.Progress in Energy and Combustion Science,1998,24(6):565-600.
[21]	WILLIAMS A,SHCHERBIK D,BIBIK O,et al.Autoignition of a jet-a fuel spray in a high temperature vitiated air flow［R］.Montréal:American Society of Mechanical Engineers,2015.
