预测平纹编织C/SiC复合材料等效导热系数的三维纤维随机模型

左可军; 闻洁

doi:10.13224/j.cnki.jasp.2018.06.006

预测平纹编织C/SiC复合材料等效导热系数的三维纤维随机模型

doi: 10.13224/j.cnki.jasp.2018.06.006

左可军,
闻洁

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

计量
- 文章访问数: 941
- HTML浏览量: 154
- PDF量: 599
- 被引次数: 0
出版历程
- 收稿日期: 2016-12-14
- 刊出日期: 2018-06-28

Three-dimensional fiber random model to predict effective thermal conductivity of plain braided C/SiC composites

摘要

摘要: 提出了一种能够刻画平纹编织C/SiC复合材料编织结构的三维纤维随机模型，探讨了微观结构影响宏观等效导热系数的机理。采用蒙特卡罗法模拟纤维位置的随机分布，用有限元法计算等效导热系数，通过数理统计方法分析在不同纤维体积分数下等效导热系数的随机分布规律；并且比较了相同纤维体积分数下，纤维随机模型平均等效导热系数与纤维周期排列模型等效导热系数的差别。结果表明：在不同体积分数下，纤维位置随机等效导热系数都呈高斯分布；纤维随机模型中纤维会出现聚集现象，形成局部“导热热障”，所以纤维随机模型平均等效导热系数小于纤维周期排列模型，这种差异在中等纤维体积分数下最明显。
- 平纹编织C/SiC复合材料 /
- 蒙特卡罗法 /
- 等效导热系数 /
- 有限元法 /
- 三维(3D)纤维随机模型
Abstract: A random microstructure cell model was developed to predict the effective thermal conductivity of plain braided C/SiC composites material, so as to describe the real distribution of fibers and the braiding-structure. Then, the influence mechanism of microstructures on macroscopic effective thermal conductivity was discussed. The random distribution of fibers was simulated by Monte Carlo method, and the effective thermal conductivity was calculated based on finite element method, and the results were presented in statistical forms. It was shown that, the Gaussian distribution function described the distribution of effective thermal conductivity accurately. For a random fiber distribution, fibers segregated in a microscopic level; Portions of the fibers came into contact and formed some local “heat flow obstacles”, which led to a smaller effective thermal conductivity than that of the general cell model.
- plain braided C/SiC composites material /
- Monte Carlo method /
- effective thermal conductivity /
- finite element method /
- three-dimensional (3D) fiber random model

HTML

参考文献(18)

[1]	BOYLE R J,NAGPAL V K,DICARLO J A,et al.Geramic matrix composites for high pressure turbine vanes［R］.ASME Paper GT2014-27136,2014.
[2]	VEDULA V,SHI J,JARMON D,et al.Ceramic matrix composite turbine vanes for gas turbine engines［R］.ASME Paper GT2005-68229,2005.
[3]	BOYLE R J,HALBIG M C,NAGPAL V K,et al.Design considerations for ceramic matrix composite vanes for high pressure turbine applications［R］.ASME Paper GT2013-95104,2013.
[4]	邵将,温卫东,崔海涛.纺织陶瓷基复合材料力学性能研究［J］.硅酸盐学报,2007,35(1):114-122.SHAO Jiang,WEN Weidong,CUI Haitao.Research progress on mechanical properties of ceramic matrix textile composite［J］.Journal of the Chinese Ceramic Society,2007,35(1):114-122.(in Chinese)
[5]	陈则韶,钱军,叶一火.复合材料等效导热系数的理论推算［J］.中国科学技术大学学报,1992,22(4):416-424.CHEN Zeshao,QIAN Jun,YE Yihuo.Predicting theory of effective thermal conductivity of complex material［J］.Journal of China University of Science and Technology,1992,22(4):416-124.(in Chinese)
[6]	聂荣华,娇桂琼,王波.二维编织C/SiC陶瓷基复合材料的热传导系数预测［J］.复合材料学报,2009,26(3):169-174.NIE Ronghua,JIAO Guiqiong,WANG Bo.Prediction on coefficient of thermal conductivity for 2D braided C/SiC composites［J］.Acta Materiae Compositae Sinica,2009,26(3):169-174.(in Chinese)
[7]	陆思达,高希光,宋迎东.基于有限元法的平纹编织C/SiC复合材料等效导热系数预测方法［J］.航空动力学报,2014,29(7):1574-1582.LU Sida,GAO Xiguang,SONG Yingdong.Prediction method on equivalent thermal conductivity coefficient of plain braided C/SiC composites material based on finite element method［J］.Journal of Aerospace Power,2014,29(7):1574-1582.(in Chinese)
[8]	CHEN Xiaoming,PAPATHANASIOU T D.On the variability of the Kozeny constant for saturated flow across unidirectional disordered fiber arrays［J］.Composites:Part A Apllied Science and Manufacturing,2006,37(6):836-846.
[9]	XU Yibin,YAGI K.Automatic FEM model generation for evaluating thermal conductivity of composite with random materials arrangement［J］.Computational Materials Science,2004,30(5):242-250.
[10]	YI Y B.The role of interparticle contact in conductive properties of random particulate materials［J］.Acta Materialia,2008,56(12):2810-2818.
[11]	康博奇,严鹏,蒋持平.预报纤维增强复合材料有效热导率的随机微结构胞元模型［J］.复合材料学报,2012,29(5):140-145.KANG Boqi,YAN Peng,JIANG Chiping.A random microstructure cell model to predict the effective thermal conductivity of fiber reinforced composites［J］.Acta Materiae Compositae Sinica,2012,29(5):140-145.(in Chinese)
[12]	高希光,宋迎东,孙志刚.纤维尺寸随机引起的复合材料性能分散性研究［J］.材料科学与工程学报,2005,23(3):335-339.GAO Xiguang,SONG Yingdong,SUN Zhigang.Research on variation of effective performance of composites induced by the stochastic fiber size［J］.Journal of Materials Science and Engineering,2005,23(3):335-339.(in Chinese)
[13]	高希光,宋迎东,孙志刚.纤维位置随机引起的复合材料性能分散性研究［J］.航空动力学报,2005,20(4):584-589.GAO Xiguang,SONG Yingdong,SUN Zhigang.Research on the discrepancy of composite effective properties induced by the stochastic fiber location［J］.Journal of Aerospace Power,2005,20(4):584-589.(in Chinese)
[14]	宋迎东,孙志刚,高希光.纤维增强复合材料有效性能分散性［J］.航空动力学报,2005,20(2):230-235.SONG Yingdong,SUN Zhigang,GAO Xiguang.Research on discrepancy of fiber reinforced composite effective performance［J］.Journal of Aerospace Power,2005,20(2):230-235.(in Chinese)
[15]	高希光,宋迎东,孙志刚.陶瓷基复合材料高精度宏细观统一本构模型研究［J］.航空动力学报,2008,23(9):1617-1622.GAO Xiguang,SONG Yingdong,SUN Zhigang.Multi-scale constitute model for ceramic matrix composite by high fidelity generalized method of cell［J］.Journal of Aerospace Power,2008,23(9):1617-1622.(in Chinese)
[16]	WONGSTO A,LI S.Micromechanical FE analysis of UD fibre-reinforced composites with fibres distributed at random over the tansverse cross-section［J］.Composites:Part A Applied Science and Manufacturing,2005,36(9):1246-1266.
[17]	YAN Dongfan,WEN Jie,XU Guoqiang.A Monte Carlo simulation and effective thermal conductivity calculation for unidirectional fiber reinforced CMC［J］.Applied Thermal Engineering,2016,94(8):827-835.
[18]	ZHANG H,ONN D G,BOLT J D,Ceramic fiber composites for electronic packaging［J］.Thermal Transport Properties,1989,167(6):187-192.
