不同转速下跨声速轴流压气机内部流动失稳的机理

张皓光; 谭锋; 安康; 楚武利; 吴艳辉

doi:10.13224/j.cnki.jasp.2018.06.011

不同转速下跨声速轴流压气机内部流动失稳的机理

doi: 10.13224/j.cnki.jasp.2018.06.011

1.
西北工业大学动力与能源学院,西安 710072
2.
西北工业大学动力与能源学院,西安 710072；先进航空发动机协同创新中心,北京 100191

基金项目: 国家自然科学基金（51006084）; 国家自然科学基金重点项目（51536006）; 航空科学基金（2014ZB53014）; 陕西省自然科学基金（2015JM5202）

计量
- 文章访问数: 974
- HTML浏览量: 158
- PDF量: 602
- 被引次数: 0
出版历程
- 收稿日期: 2016-12-09
- 刊出日期: 2018-06-28

Mechanism of internal flow instability in transonic axial flow compressor at different rotating speeds

摘要

摘要: 以跨声速轴流压气机转子NASA Rotor 67为研究对象,采用数值模拟方法,开展100%、80%及60%转速下跨声速轴流压气机内部流动失稳触发机制的机理研究。数值结果与实验数据的对比分析表明：在3个转速下,数值总性能曲线的变化趋势与实验数据符合一致。通过压气机内部流场的详细分析,得出其基本流动机理。在3个转速下,随着压气机节流,叶顶泄漏涡(TLV)的起始位置逐渐向叶片前缘移动,叶顶泄漏涡也逐渐向相邻叶片压力面偏转,相比近峰值效率点,近失速点时在100%、80%以及60%转速下叶顶泄漏涡的偏转角度分别为3°、6°和9°。在100%和80%转速下,叶顶泄漏涡与激波相互作用所导致的堵塞是触发压气机内部流动失稳的机制,并且在80%转速下,叶顶泄漏涡发生破碎；而在60%转速下,泄漏涡在相邻叶片出现的叶顶前缘溢流(LESF)是触发压气机内部流动失稳的主要机制,叶片吸力面尾缘出现的小尺度附面层气流分离(BLFS)不是主要机制。
- 跨声速轴流压气机 /
- 非设计转速 /
- 泄漏流/涡 /
- 激波 /
- 前缘溢流
Abstract: A transonic axial flow compressor rotor, the NASA Rotor 67, was chosen to investigate the triggering mechanism of internal flow instability in transonic axial flow compressor at the 100%, 80% and 60% rotating speeds with the help of numerical method. The comparative analysis of numerical results and experimental data showed that the trends of experimental performance curves were finely repeated by numerical results under three design rotating speeds. The fundamental flow mechanism was obtained by the detailed analysis of internal flow field in compressor. As the mass flow rate of compressor reduced at three rotating speeds, the starting position of tip leakage vortex (TLV) moved to the blade leading edge gradually, and tip leakage vortex also turned towards the pressure surface of adjacent blade. The deviated degrees between tip leakage vortex trajectory and compressor rotating shaft for near stall point were 3 degree, 6 degree and 9 degree than that for near peak efficiency point at the 100%, 80% and 60% rotating speeds, respectively. The blockage resulted from the interaction between tip leakage vortex and shock wave led to the internal flow instability in compressor at the 100% and 80% rotating speeds, and tip leakage vortex broken occurred at the 80% rotating speed. While at the 60% rotating speed, the leading edge spilled flow(LESF) of blade tip caused by tip leakage vortex near adjacent blade was the primary cause of internal flow instability in compressor, while a small scope boundary layer flow separation(BLFS) near the trailing edge of blade suction surface was not the primary cause.
- transonic axial flow compressor /
- off-design speed /
- leakage flow/vortex /
- shock wave /
- leading edge spilled flow

HTML

参考文献(20)

[1]	石嵩,屠宝锋.轴流压气机近失速及旋转失速全通道数值模拟［J］.航空动力学报,2016,31（5）:1196-1204.SHI Song,TU Baofeng.Full-annulus numerical simulation of near stall and rotating stall in an axial flow compressor［J］.Journal of Aerospace Power,2016,31 (5):1196-1204.(in Chinese)
[2]	谢芳,楚武利,李相君,等.叶尖间隙对跨声速轴流压气机近失速的影响［J］.航空动力学报,2014,29（10）2417-2423.XIE Fang,CHU Wuli,LI Xiangjun,et al.Influence of blade tip clearance at near-stall condition on transonic axial-flow compressor［J］.Journal of Aerospace Power,2014,29 (10):2417-2423.(in Chinese)
[3]	王卓奇,袁巍,宋西镇,等.跨声速压气机转子失速过程的实验［J］.航空动力学报,2012,27（7）:1456-1463.WANG Zhuoqi,YUAN Wei,SONG Xizhen,et al.Experimental investigation on the stall process of a transonic compressor rotor［J］.Journal of Aerospace Power,2012,27 (7):1456-1463.(in Chinese)
[4]	李清鹏,吴艳辉,楚武利,等.轴流压气机转子近失速工况全通道数值模拟［J］.航空动力学报,2011,26（10）:2330-2338.LI Qingpeng,WU Yanhui,CHU Wuli,et al.Full-annulus simulations on axial compressor rotor at near stall condition［J］.Journal of Aerospace Power,2011,26 (10):2330-2338.(in Chinese)
[5]	傅文广,孙鹏,徐佳汇,等.端区流动对跨声速压气机失速影响的数值研究［J］.推进技术,2016,37（7）:1248-1255.FU Wenguang,SUN Peng,XU Jiahui,et al.Numerical study for effects of end wall behavior on transonic compressor stall［J］.Journal of Propulsion Technology,2016,37 (7):1248-1255.(in Chinese)
[6]	GREITZER E M,NIKKANEN J P,HADDAD D E,et al.A fundamental criterion for the application of rotor casing treatment［J］.Journal of Fluids Engineering,1979,10(1):237-243.
[7]	WILKE I.Compressor flow stabilization with casing treatment:a numerical analysis［D］.Munich,Germany:Technical University Munich,2006.
[8]	WILKE I,KAU H P,BRIGNOLE G,et al.Numerically aided design of a high-efficient casing treatment for transonic compressor［R］.ASME Paper,GT-2005-68933,2005.
[9]	卢新根.轴流压气机内部流动失稳及其被动控制研究［D］.西安:西北工业大学,2007.LU Xingen.Flow instability and its passive control strategies in axial-flow compressor［D］.Xian:Northwestern Polytechnical University,2007.(in Chinese)
[10]	VO H D,TAN C S,GREITZER E M,et al.Criteria for spike initiated rotating stall［R］.ASME Paper,2005-GT-68374,2005.
[11]	FURUKAWA M,SAIKI K,YAMADA K,et al.Unsteady flow behavior due to breakdown of tip leakage vortex in an axial compressor rotor at near-stall condition［J］.ASME Paper,2000-GT-0666,2000.
[12]	张燕峰.高载荷压气机端壁流动及控制策略研究［D］.西安:西北工业大学,2010.ZHANG Yanfeng.Investigation of endwall flow behaviour and its control strategies in highly-loaded compressor［D］.Xian:Northwestern Polytechnical University,2010.(in Chinese)
[13]	王沛.压气机叶顶泄漏流动的控制策略及其扩稳机理研究［D］.北京:中国科学院,2007.WANG Pei.The control strategies of the tip leakage flow and the mechanism of improving the compressor stability［D］.Beijing:Chinese Academy of Sciences,2007.(in Chinese)
[14]	伊卫林.风扇/压气机三维气动优化设计方法及其应用研究［D］.哈尔滨:哈尔滨工业大学,2006.YI Weilin.Study on aerodynamic optimization method and application for three dimentional design of fan/compressor［D］.Harbin:Harbin Institude of Technology,2006.(in Chinese)
[15]	杜娟.跨音压气机/风扇转子叶顶泄漏流动的非定常机制研究［D］.北京:中国科学院,2010.DU Juan.Investigation on the stability mechanism of tip leakage flow in transonic compressor/fan rotors［D］.Beijing:Chinese Academy of Sciences,2010.(in Chinese)
[16]	JI Luchen,TIAN Yong,LI Weiwei,et al.Numerical studies on improving performance of Rotor-67 by blended blade and end-wall technique［R］.ASME Paper GT2012-68535,2012.
[17]	CASTANEDA J,MEHDI A,CUGNO D,et al.A preliminary numerical CFD analysis of transonic compressor rotors when subjected to inlet swirl distortion［R］.ASME Paper GT2011-46560,2011.
[18]	ZHENG Rongye,XIANG Jianhua,SUN Jinju,et al.Blade geometry optimization for axial flow compressor［R］.ASME Paper GT2010-22229,2010.
[19]	FIDALGO V J,HALL C A,COLIN Y,et al.A study of fan-distortion interaction within the NASA rotor 67 transonic stage［R］.ASME Paper GT2010-22914,2010.
[20]	STRAZISAR A J,WOOD J R,HATHAWAY M D,et al.Laser anemometer measurements in a transonic axial flow fan rotor［R］.NASA TP-2879,1989.
