进气畸变下压气机过失速三维非定常模型探索

尹超; 金海良; 银越千

doi:10.13224/j.cnki.jasp.2018.06.013

进气畸变下压气机过失速三维非定常模型探索

doi: 10.13224/j.cnki.jasp.2018.06.013

中国航空发动机集团湖南动力机械研究所,湖南株洲 412002

基金项目: 航空基金（2015ZB08006）

计量
- 文章访问数: 983
- HTML浏览量: 229
- PDF量: 543
- 被引次数: 0
出版历程
- 收稿日期: 2017-07-05
- 刊出日期: 2018-06-28

Exploration of three-dimensional unsteady model for compressor post-stall under inlet distortion

摘要

摘要: 针对原压气机稳定性三维分析模型CSAC(compressor stability analysis code)加以改进,添加了轴对称左支特性。采用改进的CSAC+模型分析了NASA Rotor37在周向总压进气畸变下的稳态性能和失速起始特性,并与软件NUMECA模拟结果进行了对比,两者模拟的特性趋势一致,畸变进气下CSAC+近失速点压比与NUMECA的误差为1.05%。针对近失速点流场分析发现：随着流量的减小,在畸变区边缘的转子叶尖首先出现低速甚至逆流区,可认为该区域为失速起始位置。利用CSAC+模拟了该压气机过失速状态下的主要流动特征,分析得出进气畸变下该失速先兆为模态波,完全发展后为部分叶高失速,失速团占据约40%叶高,其传播频率约为转子转动频率的60%,并在传播过程中显示出周期性的剥离和融合过程。
- 进气畸变 /
- 压气机 /
- 过失速 /
- 三维模型 /
- 非定常 /
- 失速先兆
Abstract: The improved three-dimensional model called compressor stability analysis code plus (CSAC+) was developed by adding an axisymmetric left characteristic. The steady aerodynamic performances and stall inception characteristics of NASA Rotor 37 under total pressure distortion inlet condition were modeled and analyzed by CSAC+. And compared with NUMECA simulation results, both of the modeling characteristics were fitted well. The relative error of total pressure ratio near stall point for both CSAC+ and NUMECA results was 1.05%. For near stall flow field analysis, it was found that as the flow rate decreased, a low speed or even reverse flow region appeared at the tip of rotor which was located behind the edge of the distortion zone. The region could be considered as the stall inception position under total pressure distortion. The stall inception and the post-stall flow characteristics of the compressor under inlet distortion were also analyzed with CSAC+. At the stall inception, the modal wave turned into part blade height stall after full development. The stall occupied 40% blade height, and the propagation frequency of the stall group was about 60% of the rotor rotation frequency. The stall group showed periodic exfoliation and fusion during propagation.
- inlet distortion /
- compressor /
- post-stall /
- three-dimensional model /
- unsteady /
- stall inception

HTML

参考文献(23)

[1]	LONGLEY J P.Measured and predicted effects of inlet distortion on axial compressors［R］.ASME Paper 90-GT-0214,1990.
[2]	PETERS T,BURGENER T,FOTTNER L.Effects of rotating inlet distortion on a 5-stage HP-compressor［R］.ASME Paper 2001-GT-0300,2001.
[3]	VISWANATH K,GOVARDHAN M.Effect of circumferential inlet flow distortion and swirl on the flow field of an axial flow fan stage［R］.ASME Paper 96-GT-263,1996.
[4]	HYNES T P,GREITZER E M.A method for assessing effects of inlet flow distortion on compressor stability,in：stability,stall and surge in compressors and pumps［R］.New Orleans:ASME Winter Meeting,,1984.
[5]	DAY I J,GREITZER E M,CUMPSTY N A.Prediction of compressor performance in rotating stall［J］.Journal of Engineering for Power,1987,100(1):1-14.
[6]	朱俊强.多级轴流压气机旋转失速起始预测［D］.西安:西北工业大学,1990.ZHU Junqiang.The predication of rotating stall inception for multistage axial compressor［D］.Xian:Northwestern Polytechnical Unversity,1990.(in Chinese)
[7]	刘志伟.轴流压气机叶排的失速边界和裕度的预计方法［J］.工程热物理学报,1982,3(3):223-225.LIU Zhiwei.The predication method of stall margin for axial compressor blade rows［J］.Journal of Engineering Thermophysics,1982,3(3):223-225.(in Chinese)
[8]	陆亚钧,马恒儒.轴流压气机旋转失速预示研究［J］.工程热物理学报,1984,5(3):266-268.LU Yajun,MA Hengru.The predication research of rotating stall for axial compressor［J］.Journal of Engineering Thermophysics,1984,5(3):266-268.(in Chinese)
[9]	李景银,刘立军,李超俊,等.多级轴流压气机失速边界预测方法研究［J］.西安交通大学学报,1996,30(5):57-61.LI Jingyin,LIU Lijun,LI Chaojun,et al.The predication method research of stall boundary for multistage axial compressor［J］.Journal of Xian Jiaotong University,1996,30(5):57-61.(in Chinese)
[10]	李美林,林峰,陈静宜,等.周向进口畸变对压气机失速过程的影响［J］.工程热物理学报,2005,26(6):931-934.LI Meilin,LIN Feng,CHEN Jingyi,et al.Annular inlet distortions influence on a low speed axial compressor［J］.Journal of Engineering Thermophysics,2005,26(6):931-934.(in Chinese)
[11]	童志庭,张靖煊,李美林,等.不同进口畸变下低速压气机近失速状态非定常特征［J］.工程热物理学报,2006,27(1):51-53.TONG Zhiting,ZHANG Jingxuan,LI Meilin,et al.Unsteady flow behavior of near-stall states in low-speed compressor under different distortions［J］.Journal of Engineering Thermophysics,2006,27(1):51-53.(in Chinese)
[12]	WILLIAM T C,DAVIS M W,Jr.Evaluating complex inlet distortion with a parallel compressor model:Part 1 concepts,theory,extensions,and limitations［R］.ASME Paper GT 2011-45067,2011.
[13]	DAVIS M W,Jr,WILLIAM T C.Evaluating complex inlet distortion with a parallel compressor model:Part 2 applications to complex patterns［R］.ASME Paper GT 2011-45068,2011.
[14]	屠宝锋,胡骏.旋转总压畸变对压气机稳定性影响的三维非定常模型［J］.航空动力学报,2011,26(2):255-261.TU Baofeng,HU Jun,Three-dimensional unsteady model of effects of rotating inlet distortion on flow instability in compressor［J］.Journal of Aerospace Power,2011,26(2):255-261.(in Chinese)
[15]	GONG Y F.A computational model for short-wavelength stall inception and development in multistage compressors［R］.ASME Paper 1998-GT-476,1998.
[16]	CHIMA R V.A three-dimensional unsteady CFD model of compressor stability［R］.ASME Paper GT2006-90040,2006.
[17]	郑宁,邹正平,徐立平.风扇进气畸变三维非定常数值模拟技术研究［J］.航空动力学报,2007,22(1):60-65.ZHENG Ning,ZOU Zhengping,XU Liping.3-Dunsteady numerical simulation of fan/compressor with inlet distortion［J］.Journal of Aerospace Power,2007,22(1):60-65.(in Chinese)
[18]	尹超,胡骏,郭晋,等.进气畸变对压气机性能影响的三维彻体力模型［J］.航空动力学报,2015,30(9):2241-2250.YIN Chao,HU Jun,GUO Jin,et al.A three-dimensional body-force model for compressor performance analysis under inlet distortion［J］.Journal of Aerospace Power,2015,30(9):2241-2250.(in Chinese)
[19]	MOORE F K,GREITZER E M.A theory of post-stall transients in axial compression systems:Part 1-Part 2［J］.Journal of Engineering for Gas Turbine and Power,1986,108(1):68-75,231-239.
[20]	KOFF S G,GREITZER E M.Stalled flow performance for axial compressors:Part Ⅰ axisymmetric characteristics［R］.ASME Paper 84-GT-93,1984.
[21]	KOFF S G.Stalled flow performance for axial compressors:Part Ⅱ rotating stall characteristics［R］.ASME Paper 84-GT-120,1984.
[22]	REID L,MOORE R D.Design and overall performance of four highly load high speed for an advanced high-pressure-ratio compressor［R］.NASA-TP-1337,1978.
[23]	REID L,MOORE R D.Performance of a single stage axial-flow transonic compressor with rotor and stator aspect ratio of 1.19 and 1.26,respectively,and with design pressure ratio of 1.82［R］.NASA-TP-1338,1978.
