EEMD与NRS在涡桨发动机转子故障诊断中的应用

丁锋; 栗祥; 韩帅

doi:10.13224/j.cnki.jasp.2018.06.016

EEMD与NRS在涡桨发动机转子故障诊断中的应用

doi: 10.13224/j.cnki.jasp.2018.06.016

西安工业大学机电工程学院，西安 710021

基金项目: 国家自然科学基金（51275374）

计量
- 文章访问数: 800
- HTML浏览量: 75
- PDF量: 474
- 被引次数: 0
出版历程
- 收稿日期: 2016-12-20
- 刊出日期: 2018-06-28

Application of EEMD and NRS in turboprop engine rotor fault diagnosis

摘要

摘要: 针对涡桨发动机转子系统振动信号的非平稳特征，提出一种基于集成经验模态分解(EEMD)与邻域粗糙集(NRS)的涡桨发动机转子故障诊断方法。该方法先对转子振动信号进行EEMD，提取原始信号的时域特征和多尺度排列熵(MPE)特征，转子系统的大部分故障信息隐藏在前几个高频本征模态函数（IMFs）中，分别计算它们的时域指标、能量特征和奇异值分解(SVD)特征；利用NRS评估各个特征的属性重要度，进而选出敏感特征；将其作为支持向量机(SVM)的输入向量来对转子进行故障诊断。实验结果表明:该方法利用敏感特征集对涡桨发动机转子进行故障诊断的准确率达到了97.5%，同时剔除了大量冗余特征，具有较强的鲁棒性。
- 涡桨发动机 /
- 转子 /
- 故障诊断 /
- 集成经验模态分解(EEMD) /
- 邻域粗糙集(NRS)
Abstract: According to the nonstationary characteristics of vibration signals of turboprop engine rotor system, a rotor fault diagnosis method based on ensemble empirical mode decomposition (EEMD) and neighborhood rough set (NRS) was proposed. EEMD was used to decompose vibration signals. Then the time domain features and multiscale permutation entropies (MPE) of original vibration signals were calculated. Most of the fault information of rotor system was contained in the first several intrinsic mode functions (IMFs). Their time domain indicators, energy features and singular value decomposition (SVD) features were also separately calculated. NRS was applied to evaluate the attribute importance of different features, and sensitive features were selected. The sensitive feature set was fed into support vector machine (SVM) for recognizing different rotor fault states. Experimental results demonstrated that the fault diagnosis accuracy of the method reached 97.5%, and a large number of redundant features were eliminated, indicating that the method had stronger robustness.
- turboprop engine /
- rotor /
- fault diagnosis /
- ensemble empirical mode decomposition (EEMD) /
- neighborhood rough set (NRS)

HTML

参考文献(20)

[1]	程礼,屈轲,陈卫,等.某型涡桨发动机减速器整机振动监控阀值研究［J］.振动与冲击,2015,34(18):136-141.CHENG Li,QU Ke,CHEN Wei,et al.Vibration monitoring threshold of turboprop engine reducer［J］.Journal of Vibration and Shock,2015,34(18):136-141.(in Chinese)
[2]	尚柏林,谢紫龙,程礼,等.EMD与ICA相结合的复杂转子系统早期故障诊断［J］.科学技术与工程,2014,14(2):265-271.SHANG Bolin,XIE Zilong,CHENG Li,et al.Early fault diagnosis of complex rotor systems by EMD-ICA［J］.Science Technology and Engineering,2014,14(2):265-271.(in Chinese)
[3]	ZHANG Han,CHEN Xuefeng,DU Zhaohui,et al.Nonlocal sparse model with adaptive structural clustering for feature extraction of aero-engine bearings［J］.Journal of Sound and Vibration,2016,368:223-248.
[4]	WANG Zhongsheng,JIANG Hongkai.Robust incipient fault identification of aircraft engine rotor based on wavelet and fraction［J］.Aerospace Science and Technology,2010,14(4):221-224.
[5]	WU Zhaohua,HUANG N E.Ensemble empirical mode decomposition:a noise-assisted data analysis method［J］.Advances in Adaptive Data Analysis,2009,1(1):1-41.
[6]	FLANDRIN P,RILLING G,GONCALVES P.Empirical mode decomposition as a filter bank［J］.Signal Processing Letters,2004,11(2):112-114.
[7]	GOVIND K S,ANISH K,JAYAKUMAR T,et al.Ensemble empirical mode decomposition based methodology for ultrasonic testing of coarse grain austenitic stainless steels［J］.Ultrasonics,2015,57:167-178.
[8]	AIED H,GONZALEZ A,CANTERO D.Identification of sudden stiffness changes in the acceleration response of a bridge to moving loads using ensemble empirical mode decomposition［J］.Mechanical Systems and Signal Processing,2016,66/67:314-338.
[9]	朱宁辉,白晓民,董伟杰.基于EEMD的谐波检测方法［J］.中国电机工程学报,2013,33(7):92-98.ZHU Ninghui,BAI Xiaomin,DONG Weijie,et al.Harmonic detection method based on EEMD［J］.Proceedings of the CSEE (Chinese Society for Electrical Engineering),2013,33(7):92-98.(in Chinese)
[10]	PAWLAK Z.Rough sets-theoretical aspects of reasoning about data［M］.Dordrecht:Kluwer Academic,1991.
[11]	PAWLAK Z.Rough sets［J］.International of Computer and Information Science,1982,11(5):341-356.
[12]	胡清华,于达仁,谢宗霞.基于邻域粒化和粗糙逼近的数值属性约简［J］.软件学报,2008,19(3):640-649.HU Qinghua,YU Daren,XIE Zongxia.Numerical attribute reduction based on neighborhood granulation and rough approximation［J］.Journal of Software,2008,19(3):640-649.(in Chinese)
[13]	HU Qinghua,YU Daren,XIE Zongxia.Neighborhood classifiers［J］.Expert Systems with Applications,2008,34(2):866-876.
[14]	LEI Yaguo,HE Zhengjia,ZI Yanyang.A new approach to intelligent fault diagnosis of rotating machinery［J］.Expert Systems with Applications,2008,35(4):1593-1600.
[15]	郝腾飞,陈果,廖仲坤,等.基于正则化多核判别分析的航空发动机滚动轴承早期故障融合诊断方法［J］.航空动力学报,2013,28(12):2759-2770.HAO Tengfei,CHEN Guo,LIAO Zhongkun,et al.Approach for incipient fusion diagnosis of rolling bearing of aero-engine based on regularized multiple kernel discriminant analysis［J］.Journal of Aerospace Power,2013,28(12):2759-2770.(in Chinese)
[16]	AZIZ W,ARIF M.Multiscale permutation entropy of physiological time series［R］.Karachi,Pakista:Pakistan Section Multitopic Conference,2005.
[17]	郑近德,程君圣,杨宇.多尺度排列熵及其在滚动轴承故障诊断中的应用［J］.中国机械工程,2013,24(19):2641-2646.ZHENG Jinde,CHENG Junsheng,YANG Yu.Multi-scale permutation entropy and its application to rolling bearing fault diagnosis［J］.China Mechanical Engineering,2013,24(19):2641-2646.(in Chinese)
[18]	LI Yongbo,XU Minqiang,WEI Yu,et al.A new rolling bearing fault diagnosis method based on multiscale permutation entropy and improved support vector machine based binary tree［J］.Measurement,2016,77:80-94.
[19]	TIAN Ye,MA Jian,LU Chen,et al.Rolling bearing fault diagnosis under variable conditions using LMD-SVD and extreme learning machine［J］.Mechanism and Machine Theory,2015,90:175-186.
[20]	艾延廷,陈潮龙,田晶,等.基于融合信息的转子振动故障SVM诊断方法［J］.航空动力学报,2014,29(10):2464-2470.AI Yanting,CHEN Chaolong,TIAN Jing,et al.SVM diagnosis method of rotor vibration faults based on integration of information exergy［J］.Journal of Aerospace Power,2014,29(10):2464-2470.(in Chinese)
