基于动力学分析的发动机测振截面选取

王俨剀; 张占升; 廖明夫; 余鹏

doi:10.13224/j.cnki.jasp.2018.06.018

基于动力学分析的发动机测振截面选取

doi: 10.13224/j.cnki.jasp.2018.06.018

西北工业大学动力与能源学院，西安 710072；西北工业大学动力与能源学院旋转机械与风能装置测控研究所，西安 710072

基金项目: 国家自然科学基金（51775436）；中央高校基本科研基金（3102017GX06005）

计量
- 文章访问数: 813
- HTML浏览量: 102
- PDF量: 547
- 被引次数: 0
出版历程
- 收稿日期: 2017-02-27
- 刊出日期: 2018-06-28

Section selecting for engine vibration measurement based on dynamic analysis

摘要

摘要: 研究了发动机测振截面选择的建模方法和优化算法。确定测振截面选择思路，建立转子-支承-机匣整机模型，计算正常和故障条件下转子动力学特性，并依据总体方案规定的传感器数目，确定测振物理量较大的转子截面或支承位置，完成振动传感器布置方案的初步确定。进一步提出测振方案优化方法，通过对实测数据进行分析，考虑实测信号的信噪比和信息冗余性，确定各测点振动数据有效信息量，判定测振方案是否合理，并选择机载测点。以某型发动机为例，设计监测点布置方案。结果表明：机载测点与该型发动机实际机载传感器测点位置相同，验证了测振方案的建立方法、优化方法和机载传感器选择方法正确可靠。单元敏感度越高，反映转子振动越明显。振动相似度越低，反映发动机整机振动特性越全面。研究结果为航空发动机测振截面布置提供重要依据。
- 发动机测振 /
- 动力学建模 /
- 数目优化 /
- 测点布置 /
- 截面选取
Abstract: Modeling method and optimization algorithm of vibration measurement sections selection of the engine was studied. The selection idea of vibration section was determined. The rotor-support-casing whole model was established .The rotordynamic characteristics were calculated under normal and fault conditions. And the section or bearing position of rotor in larger vibration was determined according to the number of sensors which the overall program requires. The initial layout of vibration sensor was completed. An optimization method for vibration measurement was proposed. The effective information of vibration data on each measuring point was determined by analyzing measured data and considering the signal-to-noise ratio and redundancy of measured signal. It was judged that whether the vibration measurement program was reasonable and the airborne measuring point was selected. A engine was taken as an example. The scheme of monitoring points was designed. The study showed that the airborne measuring point was the same as that of the real airborne sensor of the engine. It was verified that the establishment and optimization method and airborne sensor selection method were correct and reliable. The higher the elements sensitivity was, the more significantly the vibration of the rotor was reflected. The lower the vibration similarity was, the more completely the characteristics of engine vibration was reflected. The research result provides an important basis for the layout of vibration measurement of aero-engine.
- engine vibration measurement /
- dynamic modeling /
- number optimization /
- measuring point arrangement /
- section selecting

HTML

参考文献(16)

[1]	马建仓,石庆斌,程存虎,等.航空发动机转子振动信号的分离测试技术［J］.振动、测试与诊断,2009,29(1):1-4.MA Jiancang,SHI Qingbin,CHENG Cunhu,et al.Separation techniques of rotors vibration signal of aero-engine［J］.Journal of Vibration,Measurement and Diagnosis,2009,29(1):1-4.(in Chinese)
[2]	胡金海,余治国,翟旭升,等.基于改进D-S证据理论的航空发动机转子故障决策融合诊断研究［J］.航空学报,2014,35(2):436-443.HU Jinhai,YU Zhiguo,ZHAI Xusheng,et al.Research of decision fusion diagnosis of aero-engine rotor fault based on improved D-S theory［J］.Acta Aeronautica et Astronautica Sinica,2014,35(2):436-443.(in Chinese)
[3]	余鹏,王俨剀,廖明夫.离散时间传递矩阵法在燃气轮机动力学计算中的应用［J］.机械科学与技术,2016,35(3):346-350.YU Peng,WANG Yankai,LIAO Mingfu.Application of discrete-time transfer matrix method in gas-turbine dynamics calculation［J］.Mechanical Science and Technology for Aerospace Engineering,2016,35(3):346-350.(in Chinese)
[4]	US Air Force.Engine structural integrity program (ENSIP)：MIL-STD-1783［S］.Washington DC:US Air Force,1984:1-59.
[5]	张宝诚.航空发动机试验和测试技术［M］.北京:北京航空航天大学出版社,2005.
[6]	陈益林.航空发动机试车工艺［M］.北京：北京航空航天大学出版社,2010.
[7]	高雄兵,张俊杰,朱靖,等.振动传感器支座对整机振动测试的影响［J］.航空发动机,2007(增刊1):44-46.GAO Xiongbing,ZHANG Junjie,ZHU Jing,et al.The influence of vibration sensor support on engine vibration test［J］.Aeroengin,2007(Suppl.1):44-46.(in Chinese)
[8]	吴元东,范顺昌.航空发动机整机振动测点的选取与优化［C］∥航空试验测试技术学术交流会论文集.北京:中国航空学会,2015:135-138.
[9]	王俨剀,王理,廖明夫.航空发动机整机测振中的基本问题分析［J］.航空发动机,2012,38(3):49-53.WANG Yankai,WANG Li,LIAO Mingfu.Analysis of basic problems for aeroengine vibration measurement［J］.Aeroengine,2012,38(3):49-53.(in Chinese)
[10]	陈果,郝腾飞,程小勇,等.基于机匣测点信号的航空发动机滚动轴承故障诊断灵敏性分析［J］.航空动力学报,2014,29(12):2874-2884.CHEN Guo,HAO Tengfei,CHENG Xiaoyong,et al.Sensitivity analysis of fault diagnosis based on vibration signal of aero-engine rolling bearing measured on casing［J］.Journal of Aerospace Power,2014,29(12):2874-2884.(in Chinese)
[11]	秦海勤,徐可君,江龙平.某型航空发动机机载振动监测点选择［J］.推进技术,2007,28(6):697-702.QIN Haiqin,XU Kejun,JIANG Longping.Research on distribution of airborne vibration monitoring measuring points for the aeroengine［J］.Journal of Propulsion Technology,2007,28(6):697-702.(in Chinese)
[12]	PAPADIMITRIOU C.Optimal sensor placement methodology for parametric identification of structural systems［J］.Journal of Sound and Vibration,2004,278(4/5):923-947.
[13]	廖明夫,马振国,刘永泉,等.航空发动机中介轴承的故障特征与诊断方法［J］.航空动力学报,2013,28(12):2752-2758.LIAO Mingfu,MA Zhenguo,LIU Yongquan,et al.Fault characteristics and diagnosis method of intershaft bearing in aero-engine［J］.Journal of Aerospace Power,2013,28(12):2752-2758.(in Chinese)
[14]	《世界燃气轮机手册》编委会.世界燃气轮机手册［M］.北京:航空工业出版社,2011.
[15]	廖明夫.航空发动机转子动力学［M］.西安:西北工业大学出版社,2015.
[16]	师娇,唐胜景,高峰,等.基于离散时间传递矩阵法的伞-弹系统动力学模型［J］.宇航学报,2012,33(1):13-18.SHI Jiao,TANG Shengjing,GAO Feng,et al.Dynamics model for parachute-submissile system based on discrete time transfer matrix method［J］.Journal of Astronautics,2012,33(1):13-18.(in Chinese)
