SiC/SiC mini复合材料拉伸性能分散性的数值仿真方法

石多奇; 沙景恬; 程震; 杨晓光

doi:10.13224/j.cnki.jasp.2019.05.002

SiC/SiC mini复合材料拉伸性能分散性的数值仿真方法

doi: 10.13224/j.cnki.jasp.2019.05.002

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 国家自然科学基金面上项目（51772009）

计量
- 文章访问数: 931
- HTML浏览量: 150
- PDF量: 473
- 被引次数: 0
出版历程
- 收稿日期: 2018-11-19
- 刊出日期: 2019-05-28

Numerical simulation method of the variability in tensile properties of SiC/SiC minicomposites

摘要

摘要: 建立了一种能够高效计算连续纤维增强SiC/SiC陶瓷基复合材料力学性能统计分布函数的数值仿真方法。建立SiC/SiC mini复合材料简化二维胞元模型,输入组分材料力学性能参数的概率分布函数,得到胞元的力学性能。将胞元作为mini复合材料二维模型的单元对模型进行网格划分,并赋予其材料性能参数,从而得到mini复合材料的拉伸应力-应变曲线。经多次重复计算得到了mini复合材料拉伸应力-应变曲线的概率分布函数。从结果中发现,SiC/SiC mini复合材料拉伸强度满足威布尔分布,且相比于纤维和基体强度的模数,复合材料拉伸强度的模数增大,即分散性减小,同时尺度参数降低,表明mini复合材料出现概率最大的拉伸强度值变小;随着纤维和基体强度概率分布威布尔模数的增大,mini复合材料拉伸强度的尺度参数有增大的趋势。
- 陶瓷基复合材料 /
- 力学性能 /
- mini复合材料 /
- 分散性 /
- 蒙特卡洛法
Abstract: An efficient numerical simulation method for calculating the statistical distribution function of mechanical properties of continuous fiber reinforced SiC/SiC ceramic matrix composites was established. The parameters of the probability distribution function of the constituents were assigned into a two-dimensional model of the representative unit cell and the corresponding mechanical properties of the unit cell were achieved. Afterwards, the attributes and material property parameters of the representative unit cell were homogenized into a two-dimensional model of minicomposites and macroscopic tensile stress-strain response of the minicomposites could be obtained. By conducting hundreds of computations in minicomposites with stochastic mechanical parameters in constituents, the probabilistic stress-strain curves were derived. It was found that the strength of SiC/SiC minicomposites satisfied the Weibull distribution well. In comparison with individual constituents as fibers and matrix, the Weibull modulus of the strength in the macroscopic minicomposites was much larger, indicating the decrease of the scatter in the strength. On the contrary, the scale parameter in the minicomposites was smaller than that of both constituents, implying the reduction of the strength with the highest probability density. Furthermore, with the increasing Weibull modulus of the strength in either fibers or matrix, the scale parameter of minicomposites strength increased simultaneously.
- ceramic matrix composites /
- mechanical property /
- minicomposites /
- variability /
- Monte Carlo method

HTML

参考文献(20)

[1]	方光武,宋迎东,高希光.层合陶瓷基复合材料多尺度应力-应变计算模型［J］.航空动力学报,2017,32(6):1375-1380.FANG Guangwu,SONG Yingdong,GAO Xiguang.Multi-scale stress-strain calculation model of laminated ceramic matrix composites［J］.Journal of Aerospace Power,2017,32(6):1375-1380.(in Chinese)
[2]	NASLAIN R.Design,preparation and properties of non-oxide CMCs for application in engines and nuclear reactors:an overview［J］.Composites Science and Technology,2004,64(2):155-170.
[3]	DICARLO J A,VAN ROODE M.Ceramic composite development for gas turbine engine hot section components［C］∥ASME Turbo Expo 2006:Power for Land,Sea,and Air.Bercelona,Spain:American Society of Mechanical Engineers,2006:221-231.
[4]	BANSAL N P,LAMON J.Ceramic matrix composites:materials,modeling and technology［M］.Hoboken,US:John Wiley & Sons,2014.
[5]	ALVIN M A,ANDERSON I,HEIDLOFF A,et al.Development of advanced material systems for future gas turbine applications［R］.ASME Paper GT 2015-43456,2015.
[6]	孟志新,成来飞,刘善华,等.PyC层对SiC纤维束及Mini SiC/SiC复合材料拉伸性能和强度分布的影响［J］.材料导报,2011,25(16):5-7.MENG Zhixin,CHENG Laifei,LIU Shanhua,et al.Effect of PyC layer on tensile properties and strength distribution of SiC fiber bundles and Mini SiC/SiC Composites［J］.Materials Review,2011,25(16):5-7.(in Chinese)
[7]	SAUDER C,BRUSSON A,LAMON J.Influence of interface characteristics on the mechanical properties of Hi-nicalon type-S or Tyranno-SA3 fiber-reinforced SiC/SiC minicomposites［J］.International Journal of Applied Ceramic Technology,2010,7(3):291-303.
[8]	JACQUES S,LOPEZ-MARURE A,VINCENT C,et al.SiC/SiC minicomposites with structure-graded BN interphases［J］.Journal of the European Ceramic Society,2000,20(12):1929-1938.
[9]	MORSCHER G N,MARTINEZ-FERNANDEZ J.Fiber effects on minicomposite mechanical properties for several silicon carbide fiber-chemically vapor-infiltrated silicon carbide matrix systems［J］.Journal of the American Ceramic Society,1999,82(1):145-155.
[10]	BERTRAND S,FORIO P,PAILLER R,et al.Hi-nicalon/SiC minicomposites with (pyrocarbon/SiC)n nanoscale multilayered interphases［J］.Journal of the American Ceramic Society,1999,82(9):2465-2473.
[11]	CURTIN W A.Multiple matrix cracking in brittle matrix composites［J］.Acta Metallurgica et Materialia,1993,41(5):1369-1377.
[12]	LISSART N,LAMON J.Damage and failure in ceramic matrix minicomposites:experimental study and model［J］.Acta Materialia,1997,45(3):1025-1044.
[13]	ZHANG Sheng,GAO Xiguang,SONG Yingdong.In situ strength model for continuous fibers and multi-scale modeling the fracture of C/SiC composites［EB/OL］.［2018-04-24］.https:∥doi.org/10.1007/s10443-018-9696-y.
[14]	ZHANG Sheng,GAO Xiguang,CHEN Jing,et al.Effects of micro-damage on the nonlinear constitutive behavior of SiC/SiC minicomposites［J］.Journal of Ceramic Science and Technology,2016,7(4):341-347.
[15]	OCHIAI S,OKUDA H,SCHULTE K,et al.Shear Lag-Monte Carlo simulation of tensile behavior of unidirectional ceramic matrix composites［M］.Westerville,US:The American Ceramic Society,2006:221-232.
[16]	LANDIS C M,BEYERLEIN I J,MCMEEKING R M.Micromechanical simulation of the failure of fiber reinforced composites［J］.Journal of the Mechanics and Physics of Solids,2000,48(3):621-648.
[17]	PHOENIX S L,BEYERLEIN I J.Statistical strength theory for fibrous composite materials［J］.Comprehensive Composite Materials,2000,1:559-639.
[18]	CHENG Tianle,QIAO Rui,XIA Yuanming.A Monte Carlo simulation of damage and failure process with crack saturation for unidirectional fiber reinforced ceramic composites［J］.Composites Science and Technology,2004,64(13/14):2251-2260.
[19]	GRUJICIC M,SNIPES J S,GALGALIKAR R,et al.Multi-length-scale derivation of the room-temperature material constitutive model for SiC/SiC ceramic-matrix composites［J］.Journal of Materials:Design and Applications,2017,231(5):443-462.
[20]	益小苏,杜善义,张立同.复合材料手册［M］.北京:化学工业出版社,2009.
