悬停状态剪刀式尾桨气动/噪声特性优化分析

陈丝雨; 招启军; 范俊; 朱正

doi:10.13224/j.cnki.jasp.2019.05.010

悬停状态剪刀式尾桨气动/噪声特性优化分析

doi: 10.13224/j.cnki.jasp.2019.05.010

1.
南京航空航天大学直升机旋翼动力学国家级重点实验室,南京 210016)；2.中国人民解放军陆军航空兵研究所,北京 101121
2.
南京航空航天大学直升机旋翼动力学国家级重点实验室,南京 210016
3.
中国人民解放军陆军航空兵研究所,北京 101121

基金项目: 国家自然科学基金(11272150,11572156)；江苏省普通高校研究生科研创新计划项目(KYLX15_0250)

计量
- 文章访问数: 836
- HTML浏览量: 103
- PDF量: 428
- 被引次数: 0
出版历程
- 收稿日期: 2018-07-31
- 刊出日期: 2019-05-28

Optimization analysis for aerodynamic noise characteristics ofscissors tail rotor in hover

摘要

摘要: 建立了一套基于CFD(computational fluid dynamics)方法和FW-H(Ffowcs Williams-Hawkings)方程的剪刀式尾桨气动噪声预估技术和组合优化算法的尾桨外形参数设计方法。基于嵌套网格方法采用雷诺平均Navier-Stokes(RANS)方程作为尾桨流场求解控制方程,采用了一套适用于剪刀式尾桨悬停气动特性模拟的高效CFD方法。在流场分析的基础上,采用FW-H方程预测剪刀式尾桨在典型观察位置处的气动噪声。分别在控制总距以及控制拉力系数不变的情况下,以提高尾桨悬停效率同时降低气动噪声为目标,对剪刀式尾桨的剪刀角和轴间距两个主要外形参数进行优化设计。将基于拉丁超立方(LHS)方法和径向基函数(RBF)的代理模型方法与遗传算法过程相结合,建立了一种有效的组合优化算法。结果表明:剪刀角和轴间距的不同组合可以通过削弱桨-涡干扰现象从而实现降低旋翼桨-涡干扰噪声的目的。在当前的计算状态下,优化得到的剪刀式尾桨的悬停效率比常规尾桨高16%,其平均声压级比常规尾桨降低了2.3 dB。
- 尾桨 /
- Navier-Stokes方程 /
- FW-H方程 /
- 气动噪声 /
- 代理模型 /
- 遗传算法
Abstract: A structure parametric design method of scissors tail rotor was established, in combination with areodynamic noise prediction technique based on CFD(computational fluid dynamics)/FW-H(Ffowcs Williams-Hawkings) equations and combinatorial optimization algorithm. The embedded grid method was developed to predict the flowfield of scissor tail rotor in steady flow. Based on the Navier-Stokes (RANS) equations, a high-effciency CFD simulation method was adopted for aerodynamic characteristics prediction of scissor tail rotor in hover. Based on the previous flowfield calculations, FW-H equations was established to predict the aerodynamic noise of scissor tail rotors. Then, to improve the hover efficiency and reduce the aerodynamic noise, optimization design for structural parameters of scissor tail rotor (scissors angle and shaft spacing) with constant thrust coefficient and constant pitch was conducted respectively. The genetic algorithm and surrogated model based on latin hypercube sampling (LHS) design and radial basis function (RBF) were combined as a hybrid optimization technique. The noise reduction mechanism of the tail rotor was obtained by these results. And the results show that, different combinations of scissors angle and shaft spacing can reduce the blade-vortex interaction phenomenon to cut down rotor blade-vortex interaction noise. Under the current calculation state, compared with conventional rail rotor, the hover efficiency of the optimized tail rotor increased by 16%, and the average sound pressure level decreased by 2.3 dB.
- tail rotor /
- Navier-Stokes equation /
- FW-H equation /
- aerodynamic noise /
- surrogated model /
- genetic algorithm

HTML

参考文献(20)

[1]	SONNEBORN W G O,DREES J M.The scissors rotor［J］.Journal of the American Helicopter Society,1975,20(3):18-27.
[2]	XU Guohua,ZHAO Qijun,PENG Yanhui.Study on the induced velocity and noise characteristics of a scissors rotor［J］.Journal of Aircraft,2007,44(3):806-811.
[3]	ROZHDESTENSKY M G.Scissors rotor concept:new results obtained［C］∥Proceedings of American Helicopter Society 52nd Annual Forum.Washington:American Helicopter Society,1996:1231-1241.
[4]	EDWARDS B D.Psychoacoustic testing of modulated blade spacing for main rotors［R］.NACA CR-2002-211651,2002.
[5]	XU Guohua,WANG Shicun,ZHAO Jinggen.Experimental and analytical investigation on aerodynamic characteristics of helicopter scissors tail rotor［J］.Chinese Journal of Aeronautics,2001,14(4):193-199.
[6]	BRENTNER K S,EDWARDS B D,RILEY R.Predicted noise for a main rotor with modulated blade spacing［J］.Journal of the American Helicopter Society,2005,50(1):18-25.
[7]	ZHU Zheng,ZHAO Qijun.Numerical analyses for aerody-namic and noise characteristics of helicopter scissors tail rotor［C］∥Proceedings of the 70th Annual Forum of the American Helicopter Society.Montreal,Canada:American Helicopter Society,2014:1186-1198.
[8]	樊枫,史勇杰,徐国华.剪刀式尾桨悬停状态气动力及噪声特性计算研究［J］.航空学报,2013,34(9):2100-2109.FAN Feng,SHI Yongjie,XU Guohua.Computational research on aerodynamic and aeroacoustic characteristics of scissors tail-rotor in hover［J］.Acta Aeronautica et Astronautica Sinica,2013,34(9):2100-2109.(in Chinese)
[9]	朱正,招启军,王博.剪刀式尾桨涡流干扰机理和气动特性研究［J］.力学学报,2016,48(4):886-896.ZHU Zheng,ZHAO Qijun,WANG Bo.Studies on vortex interaction mechanism and aerodynamic［J］.Theoretical and Applied Mechanics,2016,48(4):886-896.(in Chinese)
[10]	ZHAO Qijun,XU Guohua,ZHAO Jinggen.New hybrid method for predicting the flowfields of helicopter rotors［J］.Journal of Aircraft,2006,43(2):372-380.
[11]	ZHAO Qijun,ZHAO Guoqing,WANG Bo,et al.Robust Navier-Stokes method for predicting unsteady flowfield and aerodynamic characteristics of helicopter rotor［J］.Chinese Journal of Aeronautics,2018,31(2):214-224.
[12]	ZHAO Qijun,XU Guohua,ZHAO Jinggen.Numerical simulations of the unsteady flowfield of helicopter rotors on moving embedded grids［J］.Aerospace Science and Technology,2005,9(2):117-124.
[13]	ROE P L.Approximate riemann solvers,parameter vectors and difference schemes［J］.Journal of Computational Physics,1981,43(2):357-372.
[14]	VAN LEER B.Towards the ultimate conservative difference scheme:a second-order sequel to Godunov’s method［J］.Journal of Computational Physics,1979,32(1):101-136.
[15]	HARTEN A,HYMAN J M.Self adjusting grid methods for one-dimensional hyperbolic conservation laws［J］.Journal of Computational Physics,1983,50(2):235-269.
[16]	LUO H,BAUM J D,LHNER R.A fast,matrix-free implicit method for compressible flows on unstructured grids［J］.Journal of Computational Physics,1998,146(2):664-690.
[17]	FARASSAT F.Linear acoustic formulas for calculation of rotating blade noise［J］.AIAA Journal,1981,19(9):1122-1130.
[18]	POMIN H,WAGNER S.Navier-Stokes analysis of helicopter rotor aerodynamics in hover and forward flight［J］.Journal of Aircraft,2002,39(5):813-821.
[19]	PURCELL T W.CFD and transonic helicopter sound［R］.Milan Italy:Fourteenth European Rotorcraft Forum,1988.
[20]	QUEIPO N V,HAFTKA R T,SHYY W.Surrogate-based analysis and optimization［J］.Progress in Aerospace Sciences,2005,41(1):1-28.
