过冷大水滴条件下结冰相似准则

施红; 王均毅; 陈佳敏; 丁媛媛; 张彤

doi:10.13224/j.cnki.jasp.2019.05.016

过冷大水滴条件下结冰相似准则

doi: 10.13224/j.cnki.jasp.2019.05.016

1.
江苏科技大学能源与动力学院,江苏镇江 212003；2.中国商用飞机有限责任公司上海飞机设计研究院,上海 201210；3.南京航空航天大学航空宇航学院,南京 210016
2.
江苏科技大学能源与动力学院,江苏镇江 212003
3.
中国商用飞机有限责任公司上海飞机设计研究院,上海 201210
4.
南京航空航天大学航空宇航学院,南京 210016

计量
- 文章访问数: 973
- HTML浏览量: 154
- PDF量: 470
- 被引次数: 0
出版历程
- 收稿日期: 2018-08-25
- 刊出日期: 2019-05-28

Icing scaling law at supercooled large droplet conditions

摘要

摘要: 虑到中国现有结冰风洞在过冷大水滴(SLD)结冰条件模拟能力方面的局限,发展SLD结冰风洞及其相应的缩比方法迫在眉睫。研究了大水滴运动机理,并依据绕流流场相似、水滴运动和撞击特性相似、结冰过程热力学特性相似原理,提炼出SLD结冰条件下的6种相似缩比准则,利用结冰数值模拟软件FENSAP-ICE对所提相似缩比准则进行筛选与比较,从而基于结冰相似百分比量化判断准则找出给定条件下的最优准则法。结果表明:考虑SLD运动特性的撞击参数与ONERA法相耦合的方法以及撞击参数与Ruff法相耦合的方法的计算结果与实际成冰构型吻合良好；此外,撞击参数与ONERA法相耦合的方法在计算直径为171 μm的SLD时优于其他。
- 过冷大水滴 /
- 结冰相似准则 /
- 缩比方法 /
- 水滴收集系数 /
- 结冰风洞
Abstract: Considering the limits of icing wind tunnels in simulating the SLD(supercooled large droplet) conditions in China, a SLD icing wind tunnel is an urgent realistic problem and its scaled theory needs to be solved. According to the dynamic characteristics and icing mechanism of the supercooled large droplets, six SLD icing scaling laws were proposed with the similarity theory and dimensionless analysis method. Some typical SLD icing conditions were chosen for verifying the SLD scaling law. Based on the FENSAP-ICE software, the ice shapes and other icing parameters were obtained, and also compared for the reliability analysis. Results showed that the coupled approach of impact parameter and ONERA method and the coupled approach of impact parameter and Ruff method had certain superiority and were in good agreement with the reference ice shapes in the test. Besides, the coupled approach of impact parameter and ONERA method was superior to the other methods when the median volumetric diameter was 171 μm.
- supercooled large droplets /
- icing scaling law /
- scaling method /
- droplet collection coefficient /
- icing wind tunnel

HTML

参考文献(21)

[1]	桑为民,蔡旸,鲁天.变形破碎特性对SLD结冰过程影响［J］.航空动力学报,2017,32(7):1537-1544.SANG Weimin,CAI Yang,LU Tian.Effect of deformation and breakup characteristic on supercooled large droplet icing process［J］.Journal of Aerospace Power,2017,32(7):1537-1544.(in Chinese)
[2]	符澄,宋文萍,彭强,等.结冰风洞过冷大水滴结冰条件模拟能力综述［J］.实验流体力学,2017,31(4):1-7.FU Cheng,SONG Wenping,PENG Qiang,et al.An overview of supercooled large droplets icing condition simulation capability in icing wind tunnels［J］.Journal of Experiments in Fluid Mechanics,2017,31(4):1-7.(in Chinese)
[3]	张强,陈迎春,周涛,等.民用飞机机翼结冰试验与数值预测［J］.航空动力学报,2017,32(1):22-26.ZHANG Qiang,CHEN Yingchun,ZHOU Tao,et al.Test and numerical prediction of ice accretions on civil aircraft wing［J］.Journal of Aerospace Power,2017,32(1):22-26.(in Chinese)
[4]	丁媛媛,蒋彦龙,施红,等.国外运输类飞机最新结冰适航规章差异初步研究与分析［J］.民用飞机设计与研究,2016,123(4):35-39.DING Yuanyuan,JIANG Yanlong,SHI Hong,et al.Study and analysis of the latest foreign icing airworthiness regulation’s differences on the transport category airplanes［J］.Civil Aircraft Design and Research,2016,123(4):35-39.(in Chinese)
[5]	RUFF G A.Analysis and verification of the icing scaling equations［R］.Arnold Engineering Development Center,AEDC 96-0636,1985.
[6]	ARMAND C,CHARPIN F,FASSO G,et al.Aircraft icing techniques and facilities used at the ONERA modane centre for icing tests［R］.Advisory Group for Aeronautical Research and Development,AGARD-127,1997.
[7]	ANDERSON D.Effect of velocity in icing scaling tests［R］.AIAA-2000-236,2000.
[8]	周志宏,易贤,桂业伟,等.考虑水滴动力学效应的结冰试验相似准则［J］.实验流体力学,2016,30(2):20-25.ZHOU Zhihong,YI Xian,GUI Yewei,et al.Icing scaling law with the dynamic effects of water droplets［J］.Journal of Experiments in Fluid Mechanics,2016,30(2):20-25.(in Chinese)
[9]	桑为民,胡少华,鲁天.过冷大水滴动力学特性对结冰影响数值研究［J］.空气动力学学报,2016,34(5):549-555.SANG Weimin,HU Shaohua,LU Tian.Numerical investigation of ice accretion effects at supercooled large droplet conditions［J］.Acta Aerodynamica Sinica,2016,34(5):549-555.(in Chinese)
[10]	张辰,孔维梁,刘洪.大粒径过冷水滴结冰模拟破碎模型研究［J］.空气动力学学报,2013,31(2):144-150.ZHANG Chen,KONG Weiliang,LIU Hong.An investigation on the breakup model for icing simulation of supercooled large droplet［J］.Acta Aerodynamica Sinica,2013,31(2):144-150.(in Chinese)
[11]	KIND R J,POTAPCZUK M G.Experimental and computational simulation of in-flight icingphenomena［J］.Progress in Aerospace Science,1998,34(1):275-345.
[12]	TAN C,PAPADAKIS M.Droplet breakup,splashing and re-impingement on an iced airfoil［R］.Toranto:AIAA Theoretical Fluid Mechanics Meeting,2005.
[13]	ANDERSON D,TSAO J C.Additional results of ice-accretion scaling at SLD conditions［R］.AIAA-2003-390,2003.
[14]	BARTLETT C S.Icing scaling considerations for air craft engine testing［R］.AIAA 88-0202,1988.
[15]	BARTLETT C S.An analytical study of icing similitude for aircraft engine testing［R］.Arnold Engineering Development Center,AEDC TR-86-26,1986.
[16]	OLESKIW M M,FABRIZIO D G,BIAGIO E.The effect of altitude on icing tunnel airfoil icing simulation［R］.Washington:FAA International Conference on Aircraft Inflight Icing,1996.
[17]	BILANIN A J.Proposed modifications to ice accretion/icing scaling theory［J］.Journal of Aircraft,1988,28(6):353-359.
[18]	ANDERSON D N.A preliminary study of ice accretion scaling for SLD conditions［R］.AIAA-2002-0521,2002.
[19]	丁媛媛.运输类飞机结冰适航审定方法及SLD关键技术研究［D］.南京:南京航空航天大学,2018.DING Yuanyuan.Research on icing airworthiness certification methods and sld key technology for transport category airplanes［D］.Nanjing:Nanjing University of Aeronautics and Astronautics,2018.(in Chinese)
[20]	周志宏,易贤,郭龙,等.一种结冰外形相似度评估方法［J］.空气动力学学报,2016,34(5):556-561.ZHOU Zhihong,YI Xian,GUO Long,et al.Quantitative method for ice accretions comparison［J］.Acta Aerodynamica Sinica,2016,34(5):556-561.(in Chinese)
[21]	ROCCO E T,HAN Y,PALACIOS J,et al.Super-cooled large droplet ice accretion reproduction and scaling law validation［R］.AIAA-2016-3279,2016.
