不同轴承壁面沟槽诱导油液穿透机理

刘红彬; 刘公平; 郝金华; 杨梦科

doi:10.13224/j.cnki.jasp.2019.05.019

不同轴承壁面沟槽诱导油液穿透机理

doi: 10.13224/j.cnki.jasp.2019.05.019

1.
河南科技大学机电工程学院,河南洛阳 471003
2.
中国机械工业集团有限公司洛阳轴承研究所有限公司,河南洛阳 471039

基金项目: 国家自然科学基金(U1404517)；工信部智能制造综合标准化项目(2017ZHZX04)

计量
- 文章访问数: 692
- HTML浏览量: 65
- PDF量: 442
- 被引次数: 0
出版历程
- 收稿日期: 2018-11-23
- 刊出日期: 2019-05-28

Oil penetration mechanism induced by different bearing wall grooves

摘要

摘要: 以高速角接触球轴承为研究对象,在轴承外圈内壁开设沟槽,采用流体动力学对高速轴承壁面沟槽模型进行气液两相流数值模拟。利用VOF(volume of fluid)模型对轴承环间气液两相流界面进行动态捕捉,分析油液在沟槽诱导作用下的运动过程和分布特点,探究阻碍油液进入腔内的影响机理。分别研究了沟槽形状、深度、方向以及喷油参数等因素对高速轴承腔内和滚道润滑油体积分数的影响规律。研究结果表明：在高速轴承喷油润滑阶段,通过对沟槽形状、深度、方向的分析,得到圆弧形沟槽适用于高速轴承,沟槽深度为0.8 mm,沟槽方向为60°有利于油液进入轴承环间,腔内有效润滑油和外滚道油液体积分数最高。通过试验测得壁面有沟槽和无沟槽轴承腔内油液体积分数并与仿真结果对比,发现在轴承高速阶段开设壁面沟槽有利于润滑油进入轴承腔,为高速轴承的润滑设计提供了新的方法。
- 轴承腔 /
- 气液两相流 /
- VOF模型 /
- 壁面沟槽 /
- 油液体积分数
Abstract: High-speed angular contact ball bearing was used as the research object, and the groove was built on the inner wall of the bearing outer ring. The fluid and dynamics was used to analyze the gas-liquid two-phase flow of high-speed bearing wall groove model. The volume of fluid (VOF) model was applied to dynamically capture gas-liquid two-phase flow between the bearing rings. The movement process and distribution characteristics of lubricating oil under groove induction were analyzed, and the factors influencing the entry of lubricating oil were explored. The influences of groove shape, depth, direction and oil injection parameters on the volume fraction of lubricating oil in the cavity and raceway of high-speed bearings were studied. The research results show that during high-speed bearing injecting, through analysis of groove shape, depth and direction, the circular groove is suitable for high-speed bearings. When the groove depth is 0.8 mm, and the groove direction is 60 degrees, it is beneficial for lubricating oil to enter the bearing ring. The volume fraction of the effective lubricating oil and raceway oil in the cavity is the highest. Finally, the volume fraction of oil between grooved and non-grooved bearing chamber was measured and compared with the simulation results. It was found that the opening of wall grooves in the high-speed stage of bearing was conducive to the entry of lubricating oil, providing a new method for the lubrication design of high-speed bearing.
- bearing chamber /
- gas-liquid two-phase flow /
- VOF model /
- wall groove /
- oil volume fraction

HTML

参考文献(19)

[1]	PINEL S I,SIGNER H R,ZARETSKY E V.Comparison between oil-mist and oil-jet lubrication of high-speed,small-bore,angular-contact ball bearings［J］.Tribology Transactions,2001,44(3):327-338.
[2]	PANG B T,LI J S,LIU H B,et al.A simulation study on optimal oil spraying mode for high-speed rolling bearing［J］.Journal of Achievements in Materials and Manufacturing Engineering,2008,31(2):553-557.
[3]	方龙,陈国定,刘登.喷射油滴沉积油膜的流动铺展特性研究［J］.机械工程学报,2016,52(23):160-167.FANG Long,CHEN Guoding,LIU Deng.Study on flow characteristics of deposited oil film formed by sprayed oil droplets［J］.Journal of Mechanical Engineering,2016,52(23):160-167.(in Chinese)
[4]	GLAHN A,WITTIG S.Two-phase air/oil flow in aero-engine bearing chambers:characterization of oil film flows［J］.Journal of Engineering for Gas and Turbines Power,1996,118(7):578-583.
[5]	吴昊天,陈国定.航空发动机轴承腔润滑的气液两相均匀流研究［J］.摩擦学学报,2007,27(1):78-82.WU Haotian,CHEN Guoding.Homogeneous flow of two phase gas/liquid flow in aero-engine bearing chamber［J］.Tribology,2007,27(1):78-82.(in Chinese)
[6]	陈国定,刘曼利,刘亚军,等.不同流型下轴承腔中油气介质的流动特征参数［J］.航空学报,2010,31(12):2400-2406.CHEN Guoding,LIU Manli,LIU Yajun,et al.Characteristic flow parameters of oil/air lubricants in bearing chamber under different flow patterns［J］.Acta Aeronautica et Astronautica Sinica,2010,31(12):2400-2406.(in Chinese)
[7]	WALSH M J,WEINSTEIN L M.Drag and heat transfer on surfaces with small longitudinal fins［R］.AIAA 78-1161,1978.
[8]	BECHERT D W,BRUSE M,HAGE W,et al.Experiments on drag-reducing surfaces and their,optimization with an adjustable geometry［J］.Journal of Fluid Mechanics,1997,338(1):59-87.
[9]	APHALE C R,CHO J,SCHULTZ W W,et al.Modeling and parametric study of torque in open clutch plates［J］.Journal of Tribology,2006,128(2):422-430.
[10]	常跃峰,姜楠.沟槽壁湍流多尺度相干结构试验研究［J］.航空动力学报,2008,23(5):788-795.CHANG Yuefeng,JIANG Nan.Experimental study on coherent structure passive control and drag reduction in turbulent boundary layer with grooved surface［J］.Journal of Aerospace Power,2008,23(5):788-795.(in Chinese)
[11]	ZHU J,LIU D,WANG Y Z,et al.Slit wall aspect ratio effect on the stability and heat transfer characteristics of Taylor-Couette flow［J］.Results in Physics,2017,7:4241-4246.
[12]	熊钊,苑士华,吴维,等.湿式离合器对偶片间油气两相流动的数值模拟［J］.机械工程学报,2016,52(16):117-123.XIONG Zhao,YUAN Shihua,WU Wei,et al.Numerical investigation of the air-oil two-phase flow inside a wet clutch［J］.Journal of Mechanical Engineering,2016,52(16):117-123.(in Chinese)
[13]	车得福,李会雄.多相流及其应用［M］.西安:西安交通大学出版社,2007.
[14]	YIN Z,GUO Y,SUNDEN B,et al.Numerical simulation of laminar film condensation in a horizontal minitube with and without non-condensable gas by the VOF method［J］.Numerical Heat Transfer Part A： Applications,2015,68(9):958-977.
[15]	王福军.计算流体力学分析［M］.北京:清华大学出版社,2004.
[16]	BATCHELOR G K.An introduction to fluid dynamics［M］.Cambridge,UK:Cambridge University Press,2000.
[17]	刘红彬,张磊,史永生,等.高速滚动轴承环间气流特性数值模拟［J］.机械设计,2016,33(6):61-66.LIU Hongbin,ZHANG Lei,SHI Yongsheng,et al.Numerical simulation of airflow characteristics between rings of the high-speed rolling bearing［J］.Journal of Machine Design of China,2016,33(6):61-66.(in Chinese)
[18]	HARRIS T A,KOTZALAS M N.Rolling bearing analysis［M］.5th ed.Boca Raton,USA:CRC Press,2006.
[19]	COE H H,ZARETSKY E V.Predicted and experimental performance of jet-lubricated 120-millimeter-bore ball bearings operating to 2.5 million DN［R］.Washington DC:NASA TP-1196,1978.
