液氮抽真空制冷的理论及试验

陈振华; 张伟; 高荣; 陈万华; 赖欢; 宋远佳

doi:10.13224/j.cnki.jasp.2019.09.014

液氮抽真空制冷的理论及试验

doi: 10.13224/j.cnki.jasp.2019.09.014

中国空气动力研究与发展中心设备设计及测试技术研究所,四川绵阳 621000

基金项目: 国家自然科学青年基金（51806234）

计量
- 文章访问数: 976
- HTML浏览量: 91
- PDF量: 603
- 被引次数: 0
出版历程
- 收稿日期: 2019-03-22
- 刊出日期: 2019-09-28

Theoretical and experimental studies of vacuum cooling of liquid nitrogen

摘要

摘要: 在考虑液氮总质量变化、储罐罐体热容的前提下,基于化学势温差,传热系数和传质系数等参数,详细建立了液氮降压制备过冷液氮的数学模型。理论计算的液氮温度及质量变化和制取过冷液氮试验值吻合较好,结果表明:该数学模型能准确描述液氮相变过程,且获得了液氮抽真空制冷中相变传热的化学势温差为1.21 K、传热系数为2 942.37 W/(m2·K)及传质系数为0.004 4 m/s。
- 抽真空制冷 /
- 过冷液氮 /
- 化学势温差 /
- 传热系数 /
- 传质系数
Abstract: Considering the total mass change of liquid nitrogen and heat capacity of tank, the mathematical model of vacuum cooling of liquid nitrogen based on the physico-chemical depression, heat transfer coefficient and mass transfer coefficient approach was built. The theoretical results were in satisfactory agreement with the experimental data of making subcooled liquid nitrogen, which indicated the mathematical model could well predict the phase change of liquid nitrogen. The physico-chemical depression of 1.21 K, heat transfer coefficient of 2 942.37 W/(m2·K) and mass transfer coefficient of 0.004 4 m/s respectively were also obtained.
- vacuum cooling /
- subcooled liquid nitrogen /
- physico-chemical depression /
- heat transfer coefficient /
- mass transfer coefficient

HTML

参考文献(18)

[1]	ZHANG Z,NIU L.Current status and key technologies of cryogenic wind tunnel［J］.Cryogenics,2015,204(2):57-62.
[2]	廖达雄,黄知龙,陈振华,等.大型低温高雷诺数风洞及其关键技术综述［J］.实验流体力学,2014,28(2):1-6.LIAO Daxiong,HUANG Zhilong,CHEN Zhenhua,et al.Review on large-scale cryogenic wind tunnel and key technologies［J］.Journal of Experiments in Fluid Mechanics,2014,28(2):1-6.(in Chinese)
[3]	MATTHIAS S,QUEST J.New techniques for operation in cryogenic windtunnels［R］.AIAA-2007-0749,2007.
[4]	QUEST J.High quality test performance in cryogenic environment［R］.AIAA-2000-2206,2000.
[5]	BOUIS X,PRIEUR J,TIZARD J A.ETW aerodynamic design:a case study［R］.Moscow,Russia:Symposium on Aerodynamics of Wind Tunnel Circuits and Their Components,1996.
[6]	WAHLS P A.Cryogenic balance technology at the national transonic facility［R］.AIAA-2001-0754,2001.
[7]	VENKI S,OWEN W,BISSETT R,et al.Reactivation of the NTF 3000 ton liquid nitrogen tank from ambient condition［R］.AIAA-2015-3009,2015.
[8]	周廷波,高超,张正科,等.NF-6风洞喷液氮降温系统研制［J］.航空动力学报,2018,33(2):327-337.ZHOU Tingbo,GAO Chao,ZHANG Zhengke,et al.Development of liquid nitrogen injection cooling system of NF-6 wind tunnel［J］.Journal of Aerospace Power,2018,33(2):327-337.(in Chinese)
[9]	BAI F F,ZHANG Z X.Integration of low-level waste heat recovery and liquefied nature gas cold energy utilization［J］.Chinese Journal of Chemical Engineering,2008,16(1):95-99.
[10]	BIAN H J,XU W D,LI X X,et al.A novel process for natural gas liquids recovery from oil field associated gas with liquefied natural gas cryogenic energy utilization［J］.Chinese Journal of Chemical Engineering,2011,19(3):452-461.
[11]	仇阳,潘振,李萍,等.一种发电和天然气再液化相结合的LNG冷能利用系统［J］.化工学报,2017,68(9):3580-3591.QIU Yang,PAN Zhen,LI Ping,et al.An LNG cold energy utilization system combined with power generation and natural gas re-liquefaction［J］.Chinese Journal of Chemical Engineering,2017,68(9):3580-3591.(in Chinese)
[12]	赖欢,陈振华,高荣,等.大型高速低温风洞冷量回收的方法研究［J］.西安交通大学学报,2016,50(6):136-142.LAI Huan,CHEN Zhenhua,GAO Rong,et al.Cold energy recycle from cryogenic wind tunnel exhaust system［J］.Journal of Xi'an Jiaotong University,2016,50(6):136-142.(in Chinese)
[13]	高荣,张伟,陈万华,等.蓄冷氮浆回收低温风洞排气原理及实验研究［J］.低温工程,2016(3):23-29.GAO Rong,ZHANG Wei,CHEN Wanhua,et al.Theoretical and experimental studies of nitrogen recycling by slush nitrogen［J］.Cryogenics,2016(3):23-29.(in Chinese)
[14]	SUN D W,HU Z H.CFD simulation of coupled heat and mass transfer through porous foods during vacuum cooling process［J］.International Journal of Refrigeration,2003,26 (1):19-27.
[15]	谢福寿,厉彦忠,王磊,等.低温推进剂过冷技术研究［J］.航空动力学报,2017,32(3):762-768.XIE Fushou,LI Yanzhong,WANG Lei,et al.Study on subcooled technology for cryogenic propellants［J］.Journal of Aerospace Power,2017,32(3):762-768.(in Chinese)
[16]	江芋叶,张鹏,王如竹.浆氮制备及其管内流动特性的实验研究［J］.工程热物理学报,2012,33(8):1403-1406. JIANG Yuye,ZHANG Peng,WANG Ruzhu.Experimental study of production and flow characteristics of slush nitrogen［J］.Journal of Engineering Thermophysics,2012,33(8):1403-1406.(in Chinese)
[17]	DOSTAL M,PETERA K.Vacuum cooling of liquids:mathematical model［J］.Journal of Food Engineering,2004,61(4):533-539.
[18]	KARL M,SUN D W.Vacuum cooling technology for the food processing industry:a review［J］.Journal of Food Engineering,2000,45(2):55-65.
