离心压缩机密封及空腔流动的一维/三维耦合建模研究

唐永洪; 席光; 金志宏; 王志恒

doi:10.13224/j.cnki.jasp.2019.09.021

离心压缩机密封及空腔流动的一维/三维耦合建模研究

doi: 10.13224/j.cnki.jasp.2019.09.021

西安交通大学能源与动力工程学院,西安 710049

基金项目: 国家重点研发计划(2018YFB0606102)

计量
- 文章访问数: 737
- HTML浏览量: 94
- PDF量: 463
- 被引次数: 0
出版历程
- 收稿日期: 2019-03-09
- 刊出日期: 2019-09-28

Research on one-dimensional/three-dimensional coupled modeling for seal and cavity flow of centrifugal compressor

摘要

摘要: 为了在保证数值预测精度的同时降低离心压缩机的建模复杂度,以一维密封泄漏计算替代完整的密封及空腔建模,开展了离心压缩机盖盘密封及空腔流动的源项建模方法研究。结果表明:基于源项方法的密封及空腔简化建模仅需在主流道建模基础上施加泄漏质量流量、总温和摩擦损失源项边界条件,即可较高精度地还原完整的盖盘密封及空腔建模的性能和关键流动细节。与完整建模相比,在全工况下源项建模预测的等熵效率的绝对偏差小于0.65%,总压比和等熵效率的相对性能偏差小于1%。该方法可在满足下游部件匹配设计精度需求的同时,减少50%以上的网格数量,并显著提高计算的经济性和收敛性。泄漏流量的计算精确度是影响源项建模法性能预测准确性的最关键因素,耦合建模可以采用一维计算中推荐的密封泄漏系数值。
- 性能预测 /
- 离心压缩机 /
- 密封 /
- 空腔流动 /
- 简化建模
Abstract: In order to reduce the modeling complexity of the centrifugal compressor while ensuring the numerical prediction accuracy, a source term modeling method for the seal and cavity flow of the centrifugal compressor was studied based on the one-dimensional seal leakage calculation instead of the complete seal-cavity modeling. The results showed that the simplified seal and cavity modeling based on source term method could accurately reproduce the overall performance and key flow details obtained by calculation of full seal and cavity modeling, allowing only to impose the boundary conditions of leakage mass flow, total temperature and friction loss source term on the mainstream channel modeling. Compared with the complete modeling, the absolute deviation of the isentropic efficiency predicted by the source term modeling at full operating conditions was less than 0.65%, and the relative performance deviation of the total pressure ratio and the isentropic efficiency was less than 1%. The method could reduce the number of meshes by more than 50% while meeting the accuracy requirement of matching design for downstream components, and also significantly improve the economy and convergence of the calculation. The calculation accuracy of the leakage flow was the most critical factor affecting the accuracy of the performance prediction for the source term modeling method. The coupling modeling could adopt the recommended seal leakage coefficient value of the one-dimensional calculation.
- performance prediction /
- centrifugal compressor /
- seal /
- cavity flow /
- simplified modeling

HTML

参考文献(20)

[1]	SUN Zhigang,TAN Chunqing,ZHANG Dongyang.Flow field structures of the impeller backside cavity and its influences on the centrifugal compressor［R］.ASME Paper GT2009-59879,2009.
[2]	MISCHO B,RIBI B,SEEBASS-LINGGI C,et al.Influence of labyrinth seal leakage on centrifugal compressor performance［R］.ASME Paper GT2009-59524,2009.
[3]	王晟旻,琚亚平,张楚华.离心压缩机级通流与盘盖侧泄漏流的耦合分析［J］.西安交通大学学报,2017,51(7):73-77.WANG Shengmin,JU Yaping,ZHANG Chuhua.Coupling analysis between through flow and hub-shroud side leakage flow of a centrifugal compressor stage［J］.Journal of Xi'an Jiaotong University,2017,51(7):73-77.(in Chinese)
[4]	秦瑞鸿,孙一颉,王晟旻,等.轮盘侧空腔流动结构及其对离心压缩机气动性能的影响［J］.工程热物理学报,2016,37(11):2349-2354.QIN Ruihong,SUN Yijie,WANG Shengmin,et al.Flow structure in impeller backside cavity and its effect on aerodynamic performance of a centrifugal compressor［J］.Journal of Engineering Thermophysics,2016,37(11):2349-2354.(in Chinese)
[5]	唐永洪,田玉宝,王志恒,等.闭式离心压缩机几何建模对数值预测结果的影响［J］.中国科学:技术科学,2017,47(6):618-631.TANG Yonghong,TIAN Yubao,WANG Zhiheng,et al.Influence of geometrical modeling on the results of numerical prediction for the centrifugal compressor with shrouded impeller［J］.Scientia Sinica Technologica,2017,47(6):618-631.(in Chinese)
[6]	SOLDATOVA K.CFD study of leakage flows in shroud cavities of a compressor impeller［R］.Bristol,UK:the 10th International Conference on Compressors and Their Systems,2017.
[7]	TONG Fei,WANG Yehao,ZHU Hongtao.Numerical investigation on the leakage characteristics of stepped labyrinth seal［R］.Piscataway,New Jersey:IEEE International Conference on Aircraft Utility Systems (AUS),2016.
[8]	MARECHALE R,MIN J I,CAVE M.Experimental and numerical investigation of labyrinth seal clearance impact on centrifugal impeller performance［R］.ASME Paper GT2015-43778,2015.
[9]	WANG Zhiheng,XU Liqun,XI Guang.Numerical investigation on the labyrinth seal design for a low flow coefficient centrifugal compressor［R］.ASME Paper GT2010-23096,2010.
[10]	WANG Zhiheng,XI Guang.Influences of cavity leakage on the design of low flow coefficient centrifugal impeller［J］.Science China Technological Sciences,2011,54(2):311-317.
[11]	GAMAL A J,VANCE J M.Labyrinth seal leakage tests:tooth profile,tooth thickness,and eccentricity effects［J］.Journal of Engineering for Gas Turbines and Power,2008,130(1):012510.1-012510.11.
[12]	赵鹏飞,刘艳,王晓放,等.简化间隙泄漏结构对离心压缩机性能影响研究［J］.风机技术,2017,59(1):1-6.ZHAO Pengfei,LIU Yan,WANG Xiaofang,et al.Investigation of the influence of a simplified clearance leakage model on the aerodynamic performance of a centrifugal compressor［J］.Compressor Blower and Fan Technology,2017,59(1):1-6.(in Chinese)
[13]	GUIDOTTI E,RUBINO D T,TAPINASSI L,et al.Accuracy of centrifugal compressor stages performance prediction by means of high fidelity CFD and validation using advanced aerodynamic probe［R］.ASME Paper GT2013-95618,2013.
[14]	GUIDOTTI E,TONI L,RUBINO D T,et al.Influence of cavity flows modeling on centrifugal compressor stages performance prediction across different flow coefficient impellers［R］.ASME Paper GT2014-25830,2014.
[15]	GUIDOTTI E,NALDI G,TAPINASSI L,et al.Cavity flow modeling in an industrial centrifugal compressor stage at design and off-design conditions［R］.ASME Paper GT2012-68288,2012.
[16]	GUIDOTTI E,TAPINASSI L,TONI L,et al.Experimental and numerical analysis of the flow field in the impeller of a centrifugal compressor stage at design point［R］.ASME Paper GT2011-45036,2011.
[17]	徐立群,王志恒,席光.迷宫密封泄漏对小流量离心叶轮气动性能影响的研究［J］.西安交通大学学报,2010,44(11):23-27.XU Liqun,WANG Zhiheng,XI Guang.Numerical study on effect of seal leakage on performance of centrifugal impeller with low flow coefficient［J］.Journal of Xi'an Jiaotong University,2010,44(11):23-27.(in Chinese)
[18]	谭佳健,姜大任,伊洪丽,等.大流量系数离心压缩机模型级数值模拟精度研究［J］.风机技术,2014,56(3):26-31.TAN Jiajian,JIANG Daren,YIN Hongli,et al.Study on numerical simulation precision of large flow coefficient centrifugal compressor model stage［J］.Compressor Blower and Fan Technology,2014,56(3):26-31.(in Chinese)
[19]	祁大同.离心式压缩机原理［M］.北京:机械工业出版社,2018.
[20]	DAILY J W,NECE R E.Chamber dimension effects on induced flow and frictional resistance of enclosed rotating disks［J］.Journal of Basic Engineering,1960,82(1):217-230.
