涡扇动力模拟短舱反推力校准试验技术

胡卜元; 黄勇; 章荣平; 曾维平; 顾艺

doi:10.13224/j.cnki.jasp.2019.09.023

涡扇动力模拟短舱反推力校准试验技术

doi: 10.13224/j.cnki.jasp.2019.09.023

中国空气动力研究与发展中心低速空气动力研究所,四川绵阳 621000

计量
- 文章访问数: 744
- HTML浏览量: 76
- PDF量: 517
- 被引次数: 0
出版历程
- 收稿日期: 2019-04-30
- 刊出日期: 2019-09-28

Reverse thrust calibration test technology of turbofan nacelle simulator

摘要

摘要: 为满足大飞机的反推力风洞试验需求,中国空气动力研究与发展中心发展了涡扇动力模拟短舱反推力校准试验技术。在FL-12风洞建立了反推力校准试验平台,利用推力天平测量反推力短舱实际推力,通过空气桥减少高压供气管路对天平测量影响,通过安装在短舱进口和喷口之间的隔板解决短舱进排气对风洞气流的诱导及反向喷流被短舱重新吸入的问题。发展了反推力校准试验方法和试验数据修正方法。为验证反推力校准试验技术可靠性,分别在FL-12风洞和FL-13风洞开展了某型号反推力校准试验和全机反推力风洞试验,试验结果表明:随排气压比增大,反推力短舱流量和速度的计算值与标定值之间的差异逐渐减小；校准试验精度优于0.5%,满足反推力风洞试验对校准试验的精度要求。
- 大飞机 /
- 涡扇动力模拟短舱 /
- 反推力校准试验 /
- 推/阻划分 /
- 反推力风洞试验
Abstract: To meet the demand of reverse thrust wind tunnel tests for large aircraft, a kind of reverse thrust calibration test technology of turbofan nacelle simulator was developed in China Aerodynamics Research and Development Center. The reverse thrust calibration test platform was constructed in FL-12 low speed wind tunnel. Thrust of the nacelle was measured by the thrust balance. Air-line bridges were used to reduce the impact of air-line tube on the balance. In order to eliminate effects of induction of inlet and exhaust flow of the nacelle on wind tunnel flow and prevent the potentially dangerous re-ingestion of reverse exhaust flow, the wind tunnel test section was blocked by a plate between the inlet and outlet of the nacelle. A reverse thrust calibration test method and a test result correcting method were developed. In ordered to verify reliability of the reverse thrust calibration test technology, a reverse thrust calibration test of a turbine simulator nacelle and a full model reverse thrust wind tunnel test were conducted in FL-12 and FL-13 low speed wind tunnel respectively. The test results indicated that, with the increase of nozzle pressure ratio, the differences between calculation and calibration of mass flow and velocity of the reverse thrust nacelle decreased gradually; the calibration test accuracy was better than 0.5%, which can meet the accuracy need of reverse thrust wind tunnel test.
- large aircraft /
- turbofan nacelle simulator /
- reverse thrust calibration test /
- thrust and drag bookkeeping /
- reverse thrust wind tunnel test

HTML

参考文献(19)

[1]	方宝瑞.飞机气动布局设计［M］.北京:航空工业出版社,1997.
[2]	MATZ R,SMITH G.Ejector-powered engine simulators for small-scale wind tunnel models of high performance aircraft［R］.AIAA 78-826,1978.
[3]	SMITH G D,MATZ R J,BAUER R C.Analytical and experimental investigation of ejector-powered engine simulators for wind tunnel models［R］.Manchester,US:Arnold Engineering Development Center,1977.
[4]	李真旭,王勋年,杨万富,等.引射式发动机模拟器的设计与校准试验研究［J］.流体力学实验与测量,2004,18(12):28-31.LI Zhenxu,WANG Xunnian,YANG Wanfu,et al.The design and calibration of ejected engine simulator［J］.Experiments and Measurements in Fluid Mechanics,2004,18(12):28-31.(in Chinese)
[5]	郝卫东,邓学蓥,曲芳亮.高速风洞发动机进排气动力模拟试验技术［J］.北京航空航天大学学报,2005,31(4):459-463.HAO Weidong,DENG Xueying,QU Fangliang.Simulated test technique for engine air intake and exhausting high speed wind tunnel［J］.Journal of Beijing University of Aeronautics and Astronautics,2005,31(4):459-463.(in Chinese)
[6]	FLAIG A.Results of wind tunnel ground effect measurements on airbus A320 using turbine power simulation and moving tunnel floor techniques［R］.AIAA 90-1427,1990.
[7]	MARK N L.Wind tunnel investigation of the AGM-130 turbojet-powered configurations［R］.AIAA 99-4257,1999.
[8]	KOOI J W,HAIJ L,HEGEN G H.Engine simulation with turbofan powered simulators in the German-Dutch wind tunnels［R］.AIAA-2002-2919,2002.
[9]	黄勇,胡卜元,张卫国,等.8米×6米风洞TPS反推力试验技术［J］.空气动力学学报,2016,34(3):346-353.HUANG Yong,HU Buyuan,ZHANG Weiguo,et al.Reverse thrust testing technique in the 8 m×6 m low speed wind tunnel of CARDC［J］.Acta Aerodynamica Sinica,2016,34(3):346-353.(in Chinese)
[10]	熊能,林俊.2.4 m跨声速风洞带TPS测力试验数据精度要求分析［J］.流体力学实验与测量,2004,18(3):42-46.XIONG Neng,LIN Jun.An analysis of data accuracy of force measurement testing with TPS in 2.4 m transonic wind tunnel［J］.Experiments and Measurements in Fluid Mechanics,2004,18(3):42-46.(in Chinese)
[11]	徐铁军,郝卫东,李聪,等.气动院校准箱工作原理分析及TPS校准目标量的获得方法［J］.流体力学实验与测量,2004,18(4):99-104.XU Tiejun,HAO Weidong,LI Cong,et al.Analysis of operative principles of calibration tank in CARIA and acquired methods of objective parameters in TPS calibration［J］.Experiments and Measurements in Fluid Mechanics,2004,18(4):99-104.(in Chinese)
[12]	BOUSQUET J M.Survey of engine integration testing in onera wind tunnels［R］.AIAA-2005-3705,2005.
[13]	HEGEN G H,KOOI J W.Investigation of aircraft performance with deployed thrust reversers in DNW［R］.AIAA-2005-3702,2005.
[14]	廉筱纯,吴虎.航空发动机原理［M］.西安:西北工业大学出版社,2005:13-16.
[15]	PHLIPSEN I,HOEIJMAKERS H.Improved air-supply line bridges for a DNW-LLF A380 model (RALD 2000)［R］.Darmstadt,Germany:3rd International Symposium on Strain Gauge Balances,2002.
[16]	PHLIPSEN I,HOEIJMAKERS H.A new balance and air-return line bridges for DNW-LLF models (B664/RALD 2001)［R］.San Diego,US:4th International Symposium on Strain Gauge Balances,2004.
[17]	章荣平,王勋年,黄勇.低速风洞全模TPS试验空气桥的设计与优化［J］.实验流体力学,2012,26(6):48-52.ZHANG Rongping,WANG Xunnian,HUANG Yong.Design and optimization of the air bridge for low speed full-span TPS test［J］.Journal of Experiments in Fluid Mechanics,2012,26(6):48-52.(in Chinese)
[18]	章荣平,王勋年,黄勇.发动机动力模拟风洞试验中的空气桥技术［J］.航空动力学报,2015,30(4):910-915.ZHANG Rongping,WANG Xunnian,HUANG Yong.Air bridge technology for engine power simulation test in wind tunnel［J］.Journal of Aerospace Power,2015,30(4):910-915.(in Chinese)
[19]	恽起麟,孙绍鹏,王发祥,等.高速风洞和低速风洞测力实验精度指标:GJB1061-91［S］.北京:国防科工委军标出版发行部,1992:3-4.
