航空发动机异型推力轴承轴向力测试方法

欧阳运芳

doi:10.13224/j.cnki.jasp.2020.06.004

航空发动机异型推力轴承轴向力测试方法

doi: 10.13224/j.cnki.jasp.2020.06.004

欧阳运芳

计量
- 文章访问数: 702
- HTML浏览量: 149
- PDF量: 587
- 被引次数: 0
出版历程
- 收稿日期: 2020-02-06
- 刊出日期: 2020-06-28

Measurement method for axial force of aero-engine special-shaped thrust bearing

OUYANG Yunfang

摘要

摘要: 某型航空发动机推力轴承外环与鼠笼弹支集成一体式,为满足该轴承轴向力测试要求,提出了一种新型轴向力测试改装设计和双向轴向力测试方法,给出了轴向力测试改装原则、等弯矩测力环结构设计方法及力学模型、强度计算对比分析、贴片引线设计、测试结果分析,并与现场测试结果进行了对比。理论计算与现场标定试验结果误差小于5%;现场试车中,双向测力环同步准确判断出轴向力换向转捩点,由此验证提出的轴向力测试方法具有很高的工程应用价值。
- 推力轴承 /
- 轴向力测试 /
- 改装设计 /
- 等弯矩 /
- 测力环
Abstract: Thrust bearings of an aero-engine integrate outer ring of bearing and squirrel-cage as one part. For this special-shaped bearing, a new method for thrust bearing structure modification design and measurement method of bidirectional axial force was given. The modification principle of axial force measurement, equal bending moment structural design idea, structural mechanical model, strength calculation contrast analysis, strain gauge and full-bridge leading wire adhesion were introduced, and test result analysis of force-measuring ring was made. Results proved that the error between theoretical calculations and calibration test was less than 5%. In the field test run, bidirectional force-measuring rings could accurately identify the turning point for direction change of axial force simultaneously. This means the proposed axial force measurement method based on force-measuring ring has high value of engineering practicability.
- thrust bearing /
- axial force measurement /
- modification design /
- ,equal bending moment /
- force-measuring ring

HTML

参考文献(22)

[1]	LIU F,SIRIGNANO W A.Turbojet and turbofan engine performance increases through turbine burners［J］.Journal of Propulsion and Power,2001,17(3):695-705.
[2]	SIRIGNANO W A,DELPLANQUE J P,LIU F.Selected challenges in jet and rocket engine combustion research［R］.AIAA 97-2701,1997.
[3]	SIRIGNANO W A,LIU F.Performance increases for gas turbine engines through combustion inside the turbine［J］.Journal of Propulsion and Power,1999,15(1):111-118.
[4]	HAI P M,BONELLO P.An impulsive receptance technique for the time domain computation of the vibration of a whole aero-engine model with nonlinear bearings［J］.Journal of Sound and Vibration,2008,318(3):592-605.
[5]	刘长福,邓明.航空发动机结构分析［M］.西安:西北工业大学出版社,2006.
[6]	LACARBONARA W,ARENA A,ANTRMAN S S.Flexural vibrations of nonlinearly elastic circular rings［J］.Meccanica,2015,50(3):689-705.
[7]	张春月,边杰.航空发动机轴向力测量传感器设计及应用［J］.仪表技术与传感器,2014(6):13-15. ZHANG Chunyue,BIAN Jie.Design and application of sensor for rotor axial force measurement of aeroengine［J］.Instrument Technique and Sensor,2014(6):13-15.(in Chinese)
[8]	卢艳辉,张春月,边杰.弹性环法在测量航空涡轴发动机角接触球轴承轴向力中的应用［J］.轴承,2013(11):48-50. LU Yanhui,ZHANG Chunyue,BIAN Jie.Application of elastic ring method in measurement of axial load of angular contact ball bearings in turboshaft engine［J］.Bearing,2013(11):48-50.(in Chinese)
[9]	母红梅,张亚,张浩.航空发动机轴向力测试技术研究［C］∥中国航空学会动力分会试验与测试专业委员会第八届学术交流会论文集.北京:中国航空学会,2006:203-211.
[10]	LADEVEZE P,SIMMONDS J.New concepts for linear beam theory with arbitrary geometry and loading［J］.European Journal of Mechanical:A Solids,1998,17(3):377-402.
[11]	CHEN W Q,LIU C F,BIAN Z G.A semi-analytical method for free vibration of straight orthotropic beams with rectangular cross-sections［J］.Mechanics Research Communications,2004,31(6):725-734.
[12]	MOHYEDDIN A,FEREIDOON A.An analytical solution for the large deflection problem of Timoshenko beams under three-point bending［J］.International Journal of Mechanical Sciences,2014,78:135-139.
[13]	ATANACKOVIC T M,SPASIC D T.A model for plane elastica with simple shear deformation pattern［J］.Acta Mechanica,1994,104(3):241-253.
[14]	GAO Y,WANG M Z,ZHAO B S.The refined theory of rectangular curved beams［J］.Acta Mechanica,2007,189(3/4):141-150.
[15]	DARILMAZ K.A hybrid 8 node hexahedral element for static and free vibration analysis［J］.Structural Engineering and Mechanics,2005,21(5):571-590.
[16]	SEO H,HUNDLEY J,HAHN H T,et al.Numerical simulation of glass-fiber reinforced aluminium laminates with diverse impact damage［J］.AIAA Journal,2010,48(3):676-687.
[17]	ZHANG C,WANG S.Structure mechanical modeling of thin walled closed section composite beams:Part 1 single cell cross section［J］.Composite Structures,2014,113(1):12-22.
[18]	HWU C,LIANG Y C.Evaluation of stress concentration factors and stress intensity factors from remote boundary data［J］.International Journal of Solids and Structures,2000,37(41):5957-5972.
[19]	HILL R.The mathematical theory of plasticity［M］.Oxford,UK:Oxford University Press,1950.
[20]	SLATER R A C.Engineer plasticity theory and application to metal forming processes［M］.London:Macmillan Press Limited,1977.
[21]	ANDREWS J P.The variation of Young’s modulus at high temperatures［J］.Proceedings of the Physical Society of London,2002,37(1):169-177.
[22]	DODGE H L.Young’s modulus of drawn tungsten and its variation with change of temperature,including a determination of the coefficient of expansion［J］.Physical Review,1918,11(4):311-315.
