宽裕度超声叶型气动优化设计

韩露; 周正贵; 陈劲帆

doi:10.13224/j.cnki.jasp.2020.06.015

宽裕度超声叶型气动优化设计

doi: 10.13224/j.cnki.jasp.2020.06.015

基金项目: 国家科技重大专项（2017-Ⅱ-0001-0013）

计量
- 文章访问数: 495
- HTML浏览量: 95
- PDF量: 388
- 被引次数: 0
出版历程
- 收稿日期: 2019-11-22
- 刊出日期: 2020-06-28

Wide stability margin aerodynamic optimization design of supersonic profile

College of Energy and Power Engineering,Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 通过与德国航天局设计的超声预压缩叶型PAV-15试验数据比对,确定高精度超声叶栅流场计算方法,研究表明:根据激波位置分段调整流管厚度可提高计算与试验结果的一致性。为提高超声叶栅稳定工作裕度并保证设计点性能,建立根据目标裕度估算喘点反压方法和优化设计方法。对两个超声叶型进行多目标优化,优化结果表明：优化叶栅可减小设计工况槽道激波入射角、减小激波及激波附面层干扰损失;气动喉道前移、结尾正激波后移,提高叶栅耐反压能力。两个优化叶型在保持总静压比不变的前提下,稳定裕度均达到设计目标,设计点损失也有所下降。
- 压气机叶栅 /
- 超声叶型 /
- 稳定工作裕度 /
- 多目标优化 /
- 耐反压能力
Abstract: By comparing with the experimental data of PAV-15 designed by German space agency, the calculation method of flow field in supersonic cascade with high accuracy was determined. The results showed that the consistency between the calculation and the experimental results can be improved by adjusting the thickness of the flow tube according to the position of shock wave. In order to improve the stability margin and ensure the performance at design point of supersonic cascade, the back pressure estimation method and optimization design method based on target margin were established. The multi-objective optimization of the two supersonic blades was carried out. The optimization results show that the optimal cascade can reduce the incident angle of the shock wave at design point, and cut down the shock wave and shock wave boundary layer interference loss. The aerodynamic throat moving forward and the terminal normal shock wave moving backward can improve the shock-holding capability. Under the premise of keeping the total and static pressure ratio unchanged, the stability margins of the two optimal blade profile reached the design goal, and the loss at design point also decreased.
- compressor cascade /
- supersonic profile /
- stability margin /
- ,multi-objective optimization /
- shock-holding capability

HTML

参考文献(19)

[1]	MERCHANT A,KERREBROCK J L,ADAMCZYK J J,et al.Experimental investigation of a high pressure ratio aspirated fan stage［J］.Journal of Turbomachinery,2005,127(1):43-51.
[2]	胡骏,吴铁鹰,曹人靖.航空叶片机原理［M］.北京：国防工业出版社,2005.
[3]	邱名.高级压比轴流压气机转子通道内激波组织研究［D］.南京:南京航空航天大学,2014. QIU Ming.Investigation of shock organization in axialcompressor passages of high pressure ratio［D］.Nanjing:Nanjing University of Aeronautics and Astronautics,2014.(in Chinese)
[4]	LEVINE P.Two-dimensional inflow conditions for a supersonic compressor with curved blades［J］.Journal of Applied Mechanics,1957,24(2):165-169.
[5]	SCHREIBER H A.Experimental investigations on shock losses of transonic and supersonic compressor cascades［R］.Advisory Group for Aerospace Research and Development,AGARD-CP-401/AD-A183996,1987.
[6]	SCHREIBER H A,STARKEN H.An investigation of a strong shock-wave turbulent boundary-layer interaction in a supersonic compressor cascade［J］.Journal of Turbomachinery,1992,114(3):494-503.
[7]	KUSTERS B,SCHREIBER H A.Compressor cascade flow with strong shock-wave/boundary-layer interaction［J］.AIAA Journal,1998,36(11):2072-2078.
[8]	肖敏,刘波,仲永兴.轴流压气机超音叶片叶型几何设计方法的研究［J］.航空动力学报,2000,15(3):237-240. XIAO Min,LIU Bo,ZHONG Yongxing.A study on geometric methods for designing supersonic aerofoil of axial flow compressor［J］.Journal of Aerospace Power,2000,15(3):237-240.(in Chinese)
[9]	肖敏,刘波,程荣辉.轴流压气机超音叶片新设计技术研究［J］.航空动力学报,2002,17(1):83-86. XIAO Min,LIU Bo,CHENG Ronghui.An investigation on a new technique for designing supersonic blade airfoil of axial flow compressor［J］.Journal of Aerospace Power,2002,17(1):83-86.(in Chinese)
[10]	CUI C,ZHOU Z G,ZHANG J H,et al.Influence of key geometric parameters on the aerodynamic performance of a supersonic compressor cascade［J］.Journal of Aerospace Engineering,2018,232(12):2338-2348.
[11]	邱名,周正贵,刘龙龙,等.超声压气机叶型设计方法［J］.航空学报,2014,35(4):975-985. QIU Ming,ZHOU Zhenggui,LIU Longlong,et al.Supersonic compressor blade profile design method.Acta Aeronautica et Astronautica Sinica,2014,35(4):975-985.(in Chinese)
[12]	SONODA T,OLHOFER M,ARIMA T,et al.A new concept of a two-dimensional supersonic relative inlet Mach number compressor cascade［C］∥Proceedings of ASME Turbo Expo:Power for Land,Sea and Air.Orlando,USA:American Society of Mechanical Engineers Digital Collection,2009:555-565.
[13]	SUN X L,YANG S H,ZHAO Q J.Shock loss model and blade profile optimization design of a supersonic cascade［J］.Journal of Aerospace Engineering,2015,229(7):1325-1329.
[14]	刘龙龙,周正贵,邱名.超音叶栅激波结构研究及叶型优化设计［J］.推进技术,2013,34(8):1050-1055. LIU Longlong,ZHOU Zhenggui,QIU Ming.Studies of shock structure in supersonic cascade and profile optimization design［J］.Journal of Propulsion Technology,2013,34(8):1050-1055.(in Chinese)
[15]	周正贵,汪光文.超声速风扇叶型设计研究［J］.航空动力学报,2009,24(1):127-131. ZHOU Zhenggui,WANG Guangwen.Design research of supersonic fan blade profile［J］.Journal of Aerospace Power,2009,24(1):127-131.(in Chinese)
[16]	WANG Z,CHANG J,ZHANG J,et al.Investigations on flowfield behavior and resistance backpressure characteristics of supersonic cascade with boundary layer suction［J］.Acta Astronautica,2018,152(1):588-601.
[17]	LIU B,SHI H,YU X.A new method for rapid shock loss evaluation and reduction for the optimization design of a supersonic compressor cascade［J］.Journal of Aerospace Engineering,2018,232(13):2458-2476.
[18]	周正贵,邱名,徐夏,等.压气机/风扇二维叶型自动优化设计［J］.航空学报,2011,32(11):1987-1997. ZHOU Zhenggui,QIU Ming,XU Xia,et al.Automatic optimization design of compressor/fan 2D blade profiles［J］.Acta Aeronautica et Astronautica Sinica,2011,32(11):1987-1997.(in Chinese)
[19]	周正贵.压气机叶片自动优化设计［J］.航空动力学报,2002,17(3):305-308.
