基于综合模糊聚类算法的液体火箭发动机故障诊断

董周杰; 郭迎清

doi:10.13224/j.cnki.jasp.2020.06.023

基于综合模糊聚类算法的液体火箭发动机故障诊断

doi: 10.13224/j.cnki.jasp.2020.06.023

计量
- 文章访问数: 667
- HTML浏览量: 268
- PDF量: 396
- 被引次数: 0
出版历程
- 收稿日期: 2019-11-09
- 刊出日期: 2020-06-28

Fault diagnosis of liquid rocket engine based on comprehensive fuzzy clustering algorithm

School of Power and Energy,Northwestern Polytechnical University,Xi’an 710072,China

摘要

摘要: 基于液体火箭发动机正常及故障状况数据的完备程度和数据质量的不断提高,提出一种基于数据驱动的综合模糊聚类算法用于故障诊断。采用模糊c均值(FCM)算法对已知正常样本数据进行聚类得到最优的聚类中心,将所得到的聚类中心作为先验样本数据用于传递闭包法最优分类结果的选择从而得到故障检测结果,该算法只需要少量的正常先验样本数据就能快速、准确的检测出故障;随后采用FCM算法进行故障分类,可以根据现有的故障数据库进行聚类得到对应的故障类型,并且可以给出故障幅值范围。模型仿真结果表明:该算法对故障的检测率可达968%,故障隔离率达到94%。某型液体火箭发动机实际试车数据结果表明:该故障诊断算法能够准确及时的检测并隔离出故障。
- 液体火箭发动机 /
- 故障诊断 /
- 模糊聚类 /
- 模糊c均值(FCM) /
- 模糊传递闭包法
Abstract: Based on the completeness of the normal and fault condition data of liquid rocket engine and the improvement of data quality, a data-driven comprehensive fuzzy clustering algorithm was proposed for fault diagnosis. The fuzzy c-means (FCM) algorithm was used to cluster the known normal sample data to obtain the optimal clustering center, and the obtained cluster center was used as a-priori sample data to select the optimal classification result of the closure method to obtain the fault detection result. Only a small amount of normal prior sample data were required to quickly and accurately detect the fault; then the FCM algorithm was used to classify the fault, and the corresponding fault type can be clustered according to the existing fault database, and the range of fault amplitudes can be given. The simulation results showed that the detection rate of the algorithm was up to 968% and the fault isolation rate was 94%. The actual test data of a liquid rocket engine show that the fault diagnosis algorithm can detect and isolate faults accurately and timely.
- liquid rocket engine /
- fault diagnosis /
- fuzzy clustering /
- ,fuzzy c-means(FCM) /
- fuzzy transfer closure

HTML

参考文献(17)

[1]	耿辉,张翔,张素明,等.一种基于聚类分析的液体火箭发动机稳态过程故障诊断方法［J］.火箭推进,2014,40(5):86-91. GENG Hui,ZHANG Xiang,ZHANG Suming,et al.Cluster analysis based diagnosis method for fault in steady process of liquid propellant rocket engine［J］.Journal of Rocket Propulsion,2014,40(5):86-91.(in Chinese)
[2]	陈水利,李敬功,王向公.模糊集理论及其应用［M］.北京:科学出版社,2005.
[3]	高新波.模糊聚类分析及其应用［M］.西安:西安电子科技大学出版社,2004.
[4]	李鸿吉.模糊数学基础及实用算法［M］.北京:科学出版社,2005.
[5]	雷涛,张肖,加小红,等.基于模糊聚类的图像分割研究进展［J］.电子学报,2019,47(8):1776-1791. LEI Tao,ZHANG Xiao,JIA Xiaohong et al.Research progress on image segmentation based on fuzzy clustering［J］.Acta Electronica Sinica,2019,47(8):1776-1791.(in Chinese)
[6]	王冰,王微,胡雄,等.基于GG模糊聚类的退化状态识别方法［J］.仪器仪表学报,2018,39(3):21-28. WANG Bing,WANG Wei,HU Xiong,at el.Degradation recognition method based on GG fuzzy clustering［J］.Journal of Instrumentation,2018,39(3):21-28.(in Chinese)
[7]	何勇,项利国.基于模糊聚类的BP神经网络模型研究及应用［J］.系统工程理论与实践,2004,24(2):79-82. HE Yong,XIANG Liguo.Research and application of BP neural network model based on fuzzy clustering［J］.System Engineering Theory and Practice,2004,24(2):79-82.(in Chinese)
[8]	李艳军.新一代大推力液体火箭发动机故障检测与诊断关键技术研究［D］.长沙:国防科学技术大学,2014. LI Yanjun..Research on key technologies for fault detection and diagnosis of new generation high thrust liquid rocket engine［D］.Changsha:National University of Defense Technology,2014.(in Chinese)
[9]	LEE K,CHA J,KO S,et al.Fault detection and diagnosis algorithms for an open-cycle liquid propellant rocket engine using the Kalman filter and fault factor methods［J］.Acta Astronautica,2018,150(1):15-27.
[10]	ZHOU Y,ZUO H F,HE J.Aero-engine fault diagnosis using a feature weighting fuzzy clustering algorithm［J］.International Journal of Control and Automation,2017,10(5):161-168.
[11]	BEZDEK J C.Pattern recognition with fuzzy objective function algorithms［J］.Advanced Application in Pattern Recognition,1983,25(3):442.
[12]	DUNN J C.A graph theoretic analysis of pattern classification via Tamura’s fuzzy relation［J］.IEEE Transactions on Systems Man and Cybernetics,1974,4(3):310-313.
[13]	RUSPINI E H.A new approach to clustering［J］.Information and Control,1969,15(1):22-32.
[14]	高新波,谢维信.模糊c均值聚类算法中加权指数m的研究［J］.电子学报,2000,28(4):80-84. GAO Xinbo,XIE Weixin.A study of weighting exponent m in a fuzzy c-means algorithm［J］.Acta Electronica Sinica,2000,28(4):80-84.(in Chinese)
[15]	王新洲,舒海翅.模糊相似矩阵的构造［J］.吉首大学学报,2003,24(3):37-41. WANG Xinzhou,SHU Haichi.Construction of fuzzy similarity matrix［J］.Journal of Jishou University,2003,24(3):37-41.(in Chinese)
[16]	王攀,陈雪娇.基于堆栈式自动编码器的加密流量识别方法［J］.计算机工程,2018,44(11):140-147. WANG Pan,CHEN Xuejiao.ASE-based encrypted traffic identification method［J］.Computer Engineering,2018,44(11):140-147.(in Chinese)
[17]	王修岩,李萃芳,高铭阳,等.基于SVM和SNN的航空发动机气路故障诊断［J］.航空动力学报,2014,29(10):2493-2498.
