三旋流燃烧室点火阶段燃烧性能

莫妲; 万斌; 王新竹

doi:10.13224/j.cnki.jasp.2020.08.004

三旋流燃烧室点火阶段燃烧性能

doi: 10.13224/j.cnki.jasp.2020.08.004

计量
- 文章访问数: 627
- HTML浏览量: 98
- PDF量: 487
- 被引次数: 0
出版历程
- 收稿日期: 2019-12-29
- 刊出日期: 2020-08-28

Combustion performance of triple swirler combustor in ignition stage

Shenyang Engine Research Institute,Aero Engine Corporation of China,Shenyang 110015,China

摘要

摘要: 为研究三旋流燃烧室的点火熄火性能,对单头部燃烧室进行了地面和高空的点、熄火试验研究,测取了负温条件下的高空点火性能,借助高速摄像法录取了地面点火过程,采用燃气分析法对地面点火燃烧效率进行了测量,获得了单头部燃烧室的点、熄火性能和点火燃烧性能参数,以及火焰传播过程。结果表明:三旋流燃烧组织方式可在宽广的主燃区气流速度范围内,具有良好的点熄火性能,地面点火边界的燃烧充分性较高,燃烧效率约为80%,负温条件增加了点火难度,与常温点火边界相比,进气压力70 kPa时的负温点火的边界变窄了188%~375%,高空贫油熄火边界与点火边界接近,所获结果可为三旋流燃烧室设计提供参考。
- 高温升 /
- 三旋流燃烧室 /
- 点熄火性能 /
- 高速摄像 /
- 燃气分析法 /
- 燃烧效率
Abstract: In order to study the ignition and flameout performance of triple swirler combustor, experiments of single-head combustor were carried out on ground and high altitude. The high altitude ignition performance at negative temperature was measured. The ground ignition process was photographed by means of high-speed camera. Combustion efficiency of ground ignition was measured by gas analysis method. The ignition and flameout performance, the ignition combustion efficiency and the ignition process of single-head combustor were obtained. Results showed that the triple swirler combustion structure had good ignition and flameout performance over a wide range of flow velocity in the primary zone. The fuel burnt efficiently and the ground ignition combustion efficiency was about 80%. The negative temperature increased the difficulty of ignition. Compared with the normal temperature ignition boundary, the negative temperature ignition boundary narrowed by 188%-375% when the pressure was 70 kPa. High altitude flameout boundary was close to ignition boundary. The experimental results provide an important reference to the design of the triple swirler combustor.
- high temperature rise /
- triple swirler combustor /
- ,ignition and flameout performance /
- high speed photography /
- ,gas analysis method /
- combustion efficiency

HTML

参考文献(22)

[1]	BAHR D W.Design technology for future aircraft turbine engine combustion［R］.AIAA 79-1197,1979.
[2]	BAHR D W.Technology for the design of high temperature rise combustors［R］.AIAA 1985-1292,1985.
[3]	KRESS E J.Multiple swirler dome combustor for high temperature sise applications［R］.AIAA 1990-2159,1990.
[4]	LEFEBVRE A H,BALLAL D R.Gas turbine combustion alternative fuels and emissions［M］.3rd Edition.New York:Taylor and Francis Group,2010.
[5]	金如山.航空燃气轮机燃烧室［M］.北京:航空工业出版社,2016.
[6]	MANSOUR A, BENJAMIIN M.A new hybrid air blast nozzle for advanced gas turbine combustor［R］.ASME Paper 2000-GT-0117,2000.
[7]	LI Guoqiang,GUTMARK E J.Flow field measurements of triple swirler spray combustor［R］.AIAA 2002-4010,2002.
[8]	LI Gouqiang,ANGIER S,LAMBOLEZ O,et al.Experimental study of velocity flow field for a multiple swirl spray combustor［R］.AIAA-2002-0618,2002.
[9]	GRINSTEIN F F,YONG T R,MONGIA H C.Computational and experimental analysis of the flow dynamics in a muti-swirler combustor［R］.AIAA 2002-1006,2002.
[10]	吴振宇,王成军,王丹丹.三级旋流器的设计及其流场模拟［J］.沈阳航空工业学院学报,2010,27(5):38-41. WU Zhenyu,WANG Chengjun,WANG Dandan.Triple swirler design and fluid numerical simulation［J］.Journal of Shenyang Institute of Aeronautical Engineering,2010,27(5):38-41.(in Chinese)
[11]	袁怡祥,林宇震,刘高恩.旋流杯燃烧室头部流场与喷雾对贫油熄火的影响［J］.航空动力学报,2004,19(3):332-336. YUAN Yixiang,LIN Yuzhen,LIU Gaoen.The effect of flow field and fuel spray of combustor with swirl cup on lean blowout limit at idle condition［J］.Journal of Aerospace Power,2004,19(3):332-336.(in Chinese)
[12]	彭云晖,林宇震,刘高恩.三旋流器燃烧室出口温度分布的初步试验研究［J］.航空动力学报,2007,22(4):554-558. PENG Yunhui,LIN Yuzhen,LIU Gaoen.A preliminary experimental study of pattern factor for a triple swirler combustor［J］.Journal of Aerospace Power,2007,22(4):554-558.(in Chinese)
[13]	莫妲,程明,张成凯,等.三旋流器加装外套环对燃烧性能的影响［J］.航空动力学报,2016,31(7):1569-1574. MO Da,CHENG Ming,ZHANG Chengkai,et al.Effect of triple swirler with an outer ring on combustion performance［J］.Journal of Aerospace Power,2016,31(7):1569-1574.(in Chinese)
[14]	莫妲,程明,万斌,等.三旋流燃烧室的数值模拟与试验［J］.航空动力学报,2017,32(11):2569-2575. MO Da,CHENG Ming,WAN Bin,et al.Numerical simulation and experiment of triple swirler combustor［J］.Journal of Aerospace Power,2017,32(11):2569-2575.(in Chinese)
[15]	SUBBA RAO H N, LEFEBVRE A H.Ignition of kerosine fuel sprays in a flowing air stream［J］.Combustion Science and Technology,1973,8(1):95-100.
[16]	RAO K V L, LEFEBVRE A H.Minimum ignition energies in flowing kerosine-air mixtures［J］.Combustion and Flam,1976,27(1):1-20.
[17]	BALLAL D R, LEFEBVRE A H.Ignition and flame quenching of flowing heterogeneous fuel-air mixtures［J］.Combustion and Flame,1979,35(2):55-68.
[18]	BALLAL D R,LEFEBVRE A H.Ignition of liquid fuel sprays at subatmospheric pressures［J］.Combustion and Flame,1978,31(2):115-126.
[19]	BALLAL D R,LEFEBVRE A H.Weak extinction limits of turbulent flowing mixtures［J］.Journal of Engineering for Power,1979,101(3):343-348.
[20]	徐丽,孙丽艳.低污染燃烧室点火熄火特性试验研究［J］.沈阳航空航天大学学报,2018,35(2):35-40. XU Li,SUN Liyan.Experimental study on ignition and flameout performance of low-pollution combustion［J］.Journal of Shenyang Aerospace University,2018,35(2):35-40.(in Chinese)
[21]	徐丽,刘凯.三旋流燃烧室燃烧特性试验［J］.航空动力学报,2018,33(9):2067-2073. XU Li,LIU Kai.Experiment of combustion characteristic of triple swirler combustor［J］.Journal of Aerospace Power,2018,33(9):2067-2073.(in Chinese)
[22]	李亚娟,王明瑞,葛新,等.基于燃气分析法的航空发动机燃烧室性能研究［J］.航空发动机,2016,42(1):37-41.
