不同孔型对高超声速逆喷流气膜冷却影响

商圣飞; 向树红; 姜利祥

doi:10.13224/j.cnki.jasp.2020.08.006

不同孔型对高超声速逆喷流气膜冷却影响

doi: 10.13224/j.cnki.jasp.2020.08.006

商圣飞^1,2,
向树红^1,2,
姜利祥^1,2

计量
- 文章访问数: 546
- HTML浏览量: 111
- PDF量: 453
- 被引次数: 0
出版历程
- 收稿日期: 2020-01-09
- 刊出日期: 2020-08-28

Effect of different hole shapes on hypersonic counter-jet film cooling

1.
Beijing Institute of Spacecraft Environment Engineering,China Academy of Space Technology,China Aerospace Science and Technology Corporation，Beijing 100094,China
2.
National Key Laboratory of Science and Technology on ,Reliability and Environmental Engineering，,Beijing Institute of Spacecraft Environment Engineering,Beijing 100094,China

摘要

摘要: 主要对不同孔型在不同质量流量下对高超声速逆喷流气膜冷却影响规律开展研究,得到不同孔型对气膜冷却效果的影响规律。采用CFD计算方法,对飞行高度为50 km，飞行马赫数为15条件下圆柱孔、收缩孔、扩张孔、收缩-扩张孔4种孔型开展研究。研究显示:小流量供气时,收缩孔和圆柱孔会出现长穿透模态(LPM)工作状态,扩张孔和收缩-扩张孔则不会出现;随着喷流流量的增大,喷流会从LPM转向短穿透模态(SPM),此时继续增大气膜喷流流量,并不会显著增大冷却收益。综合整个流域的变化,扩张孔在高超声速飞行器头部逆流喷流气膜冷却中是比较稳定可靠的气膜冷却孔。
- 高超声速飞行器 /
- 气膜冷却 /
- 气膜孔形状 /
- 热流密度 /
- 逆喷流
Abstract: The influences of different cooling holes at different mass flow rates on film cooling effect were studied by researching the relationship between the film cooling hole shape and counter jet flowing. The CFD method was used to study 4 kinds of working conditions of the cylindrical hole, the shrinkage hole, the expansion hole and the shrinkage-expansion hole under flight height 50 km, flight Mach number 15 condition. Results show that: under the small mass flow rate, long penetration model (LPM) will occur in the shrinkage hole and the cylindrical hole, unlike the case of the expansion hole and the shrinkage-expansion hole. With the increase of the jet mass flow rate, the jet will change from LPM mode to short penetration model (SPM) mode, and the cooling benefit will not appreciably increase with the increasing jet mass flow rate. Considering the changes of the whole working states, the expansion hole is a relatively stable and reliable film cooling hole in the counter-jet film cooling.
- hypersonic vehicle /
- film cooling /
- film cooling hole shape /
- heat flux /
- ,counter-jet

HTML

参考文献(20)

[1]	向树红,荣克林,黄讯,等.航天产品环境试验技术体系现状分析与发展建议［J］.航天器环境工程,2013,30(3):269-274. XIANG Shuhong,RONG Kelin,HUANG Xun,et al.The technical system of environmental tests for spacecraft products［J］.Spacecraft Environment Engineering,2013,30(3):269-274.(in Chinese)
[2]	童靖宇,向树红.临近空间环境及环境试验［J］.装备环境工程,2012,9(3):1-4. TONG Jingyu,XIANG Shuhong.Near space environment and environment tests［J］.Equipment Environmental Engineering,2012,9(3):1-4.(in Chinese)
[3]	刘存良,朱惠人,白江涛.收缩-扩张形气膜孔提高气膜冷却效率的机理研究［J］.航空动力学报,2008,23(4):598-604. LIU Cunliang,ZHU Huiren,BAI Jiangtao.Study on the physics of filmcooling effectiveness enhancement by the converging-expanding hole［J］.Journal of Aerospace Power,2008,23(4):598-604.(in Chinese)
[4]	张魏,邓明春,李广超,等.扇形孔出口宽度对气膜冷却效率影响［J］.热能动力工程,2012,27(4):416-419. ZHANG Wei,DENG Mingchun,LI Guangchao,et al.The effect of fan-shaped hole width on film cooling efficiency［J］.Journal of Engineering for Thermal Energy and Power,2012,27(4):416-419.(in Chinese)
[5]	杨晓军,张骁峰,刘智刚.扇形孔气膜冷却效果的数值模拟［J］.机械工程与自动化,2017(2):26-28. YANG Xiaojun,ZHANG Xiaofeng,LIU Zhigang.A numerical study of fan-shape hole film cooling efficiency［J］.Mechanical Engineering and Automation,2017(2):26-28.(in Chinese)
[6]	SARGISON J E,GUO S M,OLDFIELD M L G,et al.A converging slot-hole film-cooling geometry:Part Ⅰ low-speed flat-plate heat transfer and loss［J］.Journal of Turbomachinery,2002,124(3):453-460.
[7]	BUNKER R S.A review of shaped hole turbine film-cooling technology［J］.Journal of Heat Transfer,2005,127(4):441-453.
[8]	PUDSEY A S,BOYCE R R,WHEATLEY V.Hypersonic viscous drag reduction via multiporthole injector arrays［J］.Journal of Propulsion and Power,2013,29(5):1087-1096.
[9]	HEUFER K A,OLIVIER H.Experimental and numerical study of cooling gas injection in laminar supersonic flow［J］.AIAA Journal,2008,46(11):2741-2751.
[10]	HAYASHI K,ASO S.Effect of pressure ratio on aerodynamic heating reduction due to opposing jet［R］.AIAA-2003-4041,2003.
[11]	DASO E,PRITCHETT V,WANG T S,et al.The dynamics of shock dispersion and interactions in supersonic freestreams with counterflowing jets［R］.AIAA-2007-1423,2007.
[12]	VENKATACHARI B S,CHENG G,CHANG C L,et al.Long penetration mode counterflowing jets for supersonic slender configurations:a numerical study［R］.AIAA-2013-2662,2013.
[13]	向树红,张敏捷,童靖宇,等.高超声速飞行器主动式气膜冷却防热技术研究［J］.装备环境工程,2015,12(3):1-7. XIANG Shuhong,ZHANG Minjie,TONG Jingyu,et al.Research on active film cooling and heat-proof scheme for hypersonic vehicles［J］.Equipment Environmental Engineering,2015,12(3):1-7.(in Chinese)
[14]	郭春海,张文武,向树红,等.高超声速飞行器主动气膜冷却热防护数值仿真研究［J］.航天器环境工程,2017,34(2):132-137. GUO Chunhai,ZHANG Wenwu,XIANG Shuhong,et al.Numerical simulation of hypersonic vehicle thermal protection with active film cooling［J］.Spacecraft Environment Engineering,2017,34(2):132-137.(in Chinese)
[15]	商圣飞,向树红,杨艳静,等.高超声速飞行器异型气膜孔无喷流热增量研究［J］.装备环境工程,2018,15(11):12-16. SHANG Shengfei,XIANG Shuhong,YANG Yanjing,et al.Thermal increment of hypersonic flight vehicles with non-jet heterotypic film cooling hole［J］.Equipment Environmental Engineering,2018,15(11):12-16.(in Chinese)
[16]	柳军.热化学非平衡流及其辐射现象的实验和数值计算研究［D］.长沙:国防科学技术大学,2004. LIU Jun.Experimental and numerical research on thermo-chemical nonequilibrium flow with radiation phenomenon［D］.Changsha:National University of Defense Technology,2004.(in Chinese)
[17]	ANDERSON J D.Hypersonic and high-temperature gas dynamics［M］.2nd.ed.Blacksburg,Virginia，US：AIAA,2006.
[18]	MARINI M,SCHETTINO A.MSTP Workshop 1996:reentry aerothermodynamics and ground-to-flight extrapolation contributions to hyperboloid flare test-cases Ⅰ.c and Ⅲ.b［R］.Capua,Italy:Centro Italiano Ricerche Aerospaziali,1996.
[19]	GOLDBERG U.Hypersonic flow heat transfer prediction with wall-distance-free turbulence models［J］.Transactions on Modelling and Simulation,1999,21:261-270.
[20]	GOLDBERG U.Turbulence closure with a topography-parameter-free single equation model［J］.International Journal of Computational Fluid Dynamics,2003,17(1):27-38.
