不同几何结构对燃油喷嘴热防护特性的影响

刘天池; 范育新; 吴伟秋

doi:10.13224/j.cnki.jasp.2020.08.008

不同几何结构对燃油喷嘴热防护特性的影响

doi: 10.13224/j.cnki.jasp.2020.08.008

计量
- 文章访问数: 514
- HTML浏览量: 150
- PDF量: 443
- 被引次数: 0
出版历程
- 收稿日期: 2020-01-02
- 刊出日期: 2020-08-28

Influence of different geometric structures on thermal protection characteristics of fuel nozzle

College of Energy and Power Engineering,Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 试验研究了不同管路结构对燃油结焦性能的影响,结果表明,在1 000 K、150 m/s来流条件和400 K、05 m/s燃油条件下,减小弯管角度和突扩管路的突扩尺寸可以降低结焦附着,且在对管路加热的初始阶段中,结焦量随时间增加会出现波动,在加热15 min时管壁结焦量达到最大,壁面上部分结焦的脱落使结焦量降低。随后,采用试验与数值模拟相结合的方法研究了喷嘴和喷嘴帽罩结构对热防护特性的影响。结果表明,主、副油路同心布置的喷嘴具有最好的热防护效果,在所试验工况下最高可降低湿壁温度近50%,甚至优于带空气隔热层的模型。而喷嘴帽罩对喷嘴出口油温的降低有限,但减小帽罩与喷嘴体的接触或在接触面处填充低热导率的材料仍是有效的改进措施,可降低出口油温约5 K。研究结果对喷嘴的热防护设计具有指导作用。
- 几何结构 /
- 结焦 /
- 燃油喷嘴 /
- 帽罩 /
- 燃油温升 /
- 热防护
Abstract: The deposition performance of tubes with different structures was studied experimentally, And the results showed that when the inflow temperature, inflow velocity, fuel inlet temperature and velocity was 1 000 K, 150 m/s, 400 K and 05 m/s, the test pieces with smaller angles and expansion sizes had less deposition on the tube wall, and the amount of deposition fluctuated with the increase of time during the initial stage of heating. The amount of deposition on the tube wall reached the maximum when heating for 15 minutes, and then the removal of a part of deposition caused the reduction of deposition measured. The influence of fuel nozzle and nozzle cap with different geometric structures on thermal protection characteristics was studied by means of numerical simulation and experiment. Results showed that the fuel nozzle with concentric arrangement of primary and secondary fuel passages had the best thermal protection effect, which could reduce the maximum wetted wall temperature by nearly 50% under test conditions, even better than the model with air gap. Reducing the contact area between the nozzle cap and the nozzle body or filling the materials with low thermal conductivity were effective improvement measures, which could reduce the outlet oil temperature by about 5 K. The results of this study have guiding significance for the design of fuel nozzle thermal protection.
- geometric structure /
- deposition /
- fuel nozzle /
- nozzle cap /
- ,fuel temperature rise /
- thermal protection

HTML

参考文献(19)

[1]	朱锟,邓宏武,王英杰,等.超临界压力下航空煤油结焦换热综述及实验［J］.航空动力学报,2010,25(11):2472-2478. ZHU Kun,DENG Hongwu,WANG Yingjie,et al.Review and experimental study of the coke deposition and heat transfer characteristics of aviation kerosene at supercritical pressure［J］.Journal of Aerospace Power,2010,25(11):2472-2478.(in Chinese)
[2]	吴瀚,邓宏武,徐国强,等.流动方式对航空煤油RP-3结焦的影响［J］.航空动力学报,2011,26(6):1341-1345. WU Han,DENG Hongwu,XU Guoqiang,et al.Effects of flow orientations on the coking characteristic of jet fuel RP-3［J］.Journal of Aerospace Power,2011,26(6):1341-1345.(in Chinese)
[3]	HAZLETT R N.Thermal oxidation stability of aviation turbine fuels［M］.Philadelphia:American Society for Testing and Materials International,1991.
[4]	LIANG J J.Design and development of an experimental apparatus to study jet fuel coking in small gas turbine fuel nozzles［D］.Toronto:University of Toronto,2013.
[5]	王英杰,徐国强,邓宏武,等.进口温度影响航空煤油结焦特性实验［J］.航空动力学报,2009,24(9):1972-1976. WANG Yingjie,XU Guoqiang,DENG Hongwu,et al.Experimental study of influence of inlet temperature on aviation kerosene coking characteristics［J］.Journal of Aerospace Power,2009,24(9):1972-1976.(in Chinese)
[6]	袁立公,邓宏武,徐国强,等.超临界压力下航空煤油RP-3壁面结焦特性对换热的影响［J］.航空动力学报,2013,28(4):832-837. YUAN Ligong,DENG Hongwu,XU Guoqiang,et al.Effects of RP-3 coke deposition on heat transfer under supercritical pressure［J］.Journal of Aerospace Power,2013,28(4):832-837.(in Chinese)
[7]	万云霞,柴昕,窦义涛.火焰筒头部积碳对燃油雾化特性影响的试验研究［J］.航空发动机,2015,41(2):71-75. WAN Yunxia,CHAI Xin,DOU Yitao.Experimental investigation on effect of coking for liner dome on fuel spray characteristics［J］.Aeroengine,2015,41(2):71-75.(in Chinese)
[8]	RAWSON P.Evaluation of a jet fuel thermal stability rig［R］.Defence Science and Technology Organisation,DSTO-TR-1643,2004.
[9]	李帅.航空发动机燃油管路热防护研究［D］.南京:南京航空航天大学,2014. LI Shuai.Research on termal protection of aero-engine fuel supply line［D］.Nanjing:Nanjing University of Aeronautics and Astronautics,2017.(in Chinese)
[10]	STICKLES R W,DODDS W J,KOBLISH T R,et al.Innovative high temperature aircraft engine fuel nozzle design［J］.Journal of Engineering for Gas Turbines and Power,1993,115(3):439-446.
[11]	MYERS G D,ARMSTRONG J P,WHITE C D,et al.Development of an innovative high-temperature gas turbine fuel nozzle［J］.Journal of engineering for gas turbines and power,1992,114(2):401-408.
[12]	苗辉,王会汝,贾真,等.航空发动机燃烧室喷嘴内燃油传热特性的数值研究［J］.燃气涡轮试验与研究,2015,28(3):30-32. MIAO Hui,WANG Huiru,JIA Zhen,et al.Numerical investigation of heat transfer characteristics of aero-engine combustor injector［J］.Gas Turbine Experiment and Research,2015,28(3):30-32.(in Chinese)
[13]	高栋,李锋,尚守堂,等.航空发动机主燃烧室燃油总管流动换热特性研究［J］.航空发动机,2015,41(6):22-27. GAO Dong,LI Feng,SHANG Shoutang,et al.Investigation on flow and heat transfer characteristics of fuel manifold for aeroengine combustor［J］.Aeroengine,2015,41(6):22-27.(in Chinese)
[14]	黄义勇.航空发动机主燃油喷嘴热防护设计技术研究［D］.成都:电子科技大学,2011.
[15]	李建中,袁丽,尚伟,等.高温升燃烧室喷油杆热防护试验研究［J］.推进技术,2016,37(12):2336-2342. LI Jianzhong,YUAN Li,SHANG Wei,et al.Experimentalinvestigation on thermal protection for fuel injector pole of high temperature rise combustor［J］.Journal of Propulsion Technology,2016,37(12):2336-2342.(in Chinese)
[16]	CHIN J S,LEFEBVRE A H.Experimental techniques for the assessment of fuel thermal stability［R］.AIAA 92-0685,1992.
[17]	武禹.低排放燃烧室分区供油喷嘴热防护方案研究［D］.南京:南京航空航天大学,2017. WU Yu.Study on thermal peotection schenme for partiyion fuel supply system of low emission combustor［D］.Nanjing:Nanjing University of Aeronautics and Astronautics,2017.(in Chinese)
[18]	裴鑫岩.航空煤油超临界换热与氧化结焦理论与实验研究［D］.北京:清华大学,2016. PEI Xinyan.Numerical and experimental study of heat transfer characteristics and oxidation deposition of aviation kerosene at supercritical pressure［D］.Beijing:Tsinghua University.(in Chinese)
[19]	梁德旺.流体力学基础［M］.北京:航空工业出版社,1998.
