计及齿面摩擦的弧齿锥齿轮动态特性

李飞; 袁茹; 朱慧玲

doi:10.13224/j.cnki.jasp.2020.08.013

计及齿面摩擦的弧齿锥齿轮动态特性

doi: 10.13224/j.cnki.jasp.2020.08.013

计量
- 文章访问数: 500
- HTML浏览量: 184
- PDF量: 270
- 被引次数: 0
出版历程
- 收稿日期: 2019-10-25
- 刊出日期: 2020-08-28

Dynamic characteristics of spiral bevel gear considering tooth surface friction

School of Mechanical Engineering,Northwestern Polytechnical University,Xi’an 710072,China

摘要

摘要: 基于集中参数法建立斜交弧齿锥齿轮8自由度动力学模型和动力学方程,综合考虑静态传动误差、齿面摩擦、齿侧间隙等激励,采用变步长Runge-Kutta法求解传动系统的动态响应,分析了摩擦因数、重合度对传动系统振动幅值的影响。结果表明:不同工况下的摩擦因数不同,随着润滑油的减少,摩擦因数增大,系统的振动位移和法向啮合力增大;随着接触迹线与根锥之间的夹角增大,重合度减小,振动幅值增大,法向啮合力增大。
- 弧齿锥齿轮 /
- 集中参数法 /
- 齿面摩擦 /
- 传动误差 /
- 动态响应
Abstract: Based on the centralized parameter method, an 8 degrees of freedom dynamic model and dynamic equations of spiral beveled bevel gears were established. Considering the static transmission error, tooth surface friction and tooth clearance comprehensively, the dynamic responses of transmission system were solved by Runge-Kutta algorithm with variable step lengths, and the effects of friction coefficient and coincidence degree on the vibration amplitude of the transmission system were studied. The results showed that the friction coefficient was different under different working conditions. With the decrease of lubricating oil, the friction coefficient, the system’s vibration displacement and normal meshing force increased; coincidence degree was reduced, but vibration amplitude and normal meshing force increased while the angle between the contact trace and the root cone increased.
- spiral bevel gear /
- centralized parameter method /
- tooth surface friction /
- ,transmission error /
- dynamic responses

HTML

参考文献(17)

[1]	赵宁,康士朋,郭辉,等.基于遗传算法的弧齿锥齿轮动态特性优化设计［J］.航空动力学报,2010,25(10):2396-2402. ZHAO Ning,KANG Shipeng,GUO Hui,et al.Optimization design of spiral bevel gear’s dynamic characteristics based on genetic algorithm［J］.Journal of Aerospace Power,2010,25(10):2396-2402.(in Chinese)
[2]	杨宏斌,高建平,邓效忠,等.弧齿锥齿轮和准双曲面齿轮非线性动力学研究［J］.航空动力学报,2004,19(1):54-57. YANG Hongbin,GAO Jianping,DENG Xiaozhong,et al.Research on nonlinear dynamics of spiral bevel gear and hypoid gear［J］.Journal of Aerospace Power,2004,19(1):54-57.(in Chinese)
[3]	林何,王三民,董金城.多激励下某直升机传动系统动载特性［J］.航空动力学报,2015,30(1):219-227. LIN He,WANG Sanmin,DONG Jincheng.Dynamic load characteristics of a helicopter transmission system under multiple excitations［J］.Journal of Aerospace Power,2015,30(1):219-227.(in Chinese)
[4]	王三民,沈允文,董海军.含间隙和时变啮合刚度的弧齿锥齿轮传动系统非线性振动特性研究［J］.机械工程学报,2003,39(2):28-32. WANG Sanmin,SHEN Yunwen,DONG Haijun.Research on nonlinear vibration characteristics of spiral bevel gear transmission system with clearance and time-varying meshing stiffness［J］.Journal of Mechanical Engineering,2003,39(2):28-32.(in Chinese)
[5]	王三民,沈允文,董海军.含摩擦和间隙直齿轮副的混沌与分叉研究［J］,机械工程学报,2002,38(9):8-11. WANG Sanmin,SHEN Yunwen,DONG Haijun.Research on chaos and bifurcation of spur gear pairs with friction and clearance［J］.Journal of Mechanical Engineering,2002,38(9):8-11.(in Chinese)
[6]	王三民,李继庆,陈作模.弹性支承条件下中央弧齿锥齿轮传动的接触稳定性研究［J］.机械科学与技术,1996,15(1):1-5,36. WANG Sanmin,LI Jiqing,CHEN Zuomo.Research on contact stability of central spiral bevel gear transmission under elastic support［J］.Mechanical Science and Technology,1996,15(1):1-5,36.(in Chinese)
[7]	冯治恒.螺旋锥齿轮多体多自由度非线性动力学研究［D］.重庆:重庆大学,2011. FENG Zhiheng.Research on multi-DOF nonlinear dynamic of helical bevel gear［D］.Chongqing:Chongqing University,2011.(in Chinese)
[8]	冯治恒,王时龙,雷松,等.时变摩擦系数对准双曲面齿轮动力学行为的影响［J］.重庆大学学报(自然科学版),2011,34(12):9-15. FENG Zhiheng,WANG Shilong,LEI Song,et al.Influence of time-varying friction coefficient on the hyperbolic gear dynamic behavior［J］.Journal of Chongqing University(Natural Science Edition),2011,34(12):9-15.(in Chinese)
[9]	苏进展,方宗德,贺朝霞.基于啮合特性的弧齿锥齿轮动力学研究［J］.机械科学与技术,2016,35(1):50-55. SU Jinzhan,FANG Zongde,HE Zhaoxia.Study on dynamic of spiral bevel gears on meshing characteristics［J］.Mechanical Science and Technology,2016,35(1):50-55.(in Chinese)
[10]	WANG J,LIM T C,LI M.Dynamics of a hypoid gear pair considering the effects of time-varying mesh parameters and backlash nonlinearity［J］.Journal of Sound and Vibration,2007,308(1/2):302-329.
[11]	CASTRO J,SEABRA J.Coefficient of friction in mixed film lubrication:Gears versus twin-discs［J］.Proceedings of the Institution of Mechanical Engineers:Part J Journal of Engineering Tribology,2007,221(3):399-411.
[12]	LITVIN F L,ZHANG Y,HANDSCHUH R F.Local synthesis and tooth contact analysis of face-milled spiral bevel gears［R］.NASA-CR-4342,1991.
[13]	CASTRO J,SEABRA J.Global and local analysis of gear scuffing tests using a mixed film lubrication model［J］.Tribology International,2008,41(3):244-255.
[14]	袁杰红,林泽锦.弧齿锥齿轮摩擦功率损失计算［J］.国防科技大学学报,2012,34(5):115-120. YUAN Jiehong,LIN Zejin.Calculation of friction power loss of spiral bevel gear［J］.Journal of National University of Defense Technology,2012,34(5):115-120.(in Chinese)
[15]	ZHU Dong,HU Yuanzhong.A computer program package for the prediction of EHL and mixed lubrication characteristics,friction,subsurface stresses and flash temperatures based on measured 3-D surface roughness［J］.Tribology Transactions,2001,44(3):383-309.
[16]	HAMROCK B J,DOWSON D.Isothermal elasto hydrodynamic lubrication of point contacts:Part Ⅲ fully flooded results［J］. Journal of Lubrication Technology,1977, 99(2):264-275.
[17]	温诗铸.摩擦学原理［M］.北京:清华大学出版社,1990.
