四种风洞收缩段流场特性对比

高丽敏; 刘哲; 蔡明

doi:10.13224/j.cnki.jasp.2020.08.014

四种风洞收缩段流场特性对比

doi: 10.13224/j.cnki.jasp.2020.08.014

基金项目: 国家自然科学基金重大项目（51790512）；民机专项

计量
- 文章访问数: 579
- HTML浏览量: 82
- PDF量: 439
- 被引次数: 0
出版历程
- 收稿日期: 2020-01-08
- 刊出日期: 2020-08-28

Comparison on flow field characteristics of four wind tunnel contraction sections

National Key Laboratory of Science and Technology on Aerodynamic Design and Research,School of Power and Energy,Northwestern Polytechnical University,Xi’an 710072,China

摘要

摘要: 基于西北工业大学高亚声速平面叶栅风洞,测量了维氏收缩段的出口流场,发现其方向场品质较差,相比速度场和总压场,核心区沿周向减小了15%。对四种收缩段进行数值模拟后,对比了收缩段的出口核心区、均匀性及分离特性,发现维氏曲线在前部收缩,进口收缩过急引起旋涡,但出口稳流段较长,因此出口均匀性更好。双三次曲线在后部收缩,主流区顺压梯度更大,因此附面层更薄,气流偏角更小,分离特性更好,但出口过冲更大。现有维氏收缩段的三维结构在拓宽核心区同时对气流扰动较大,恶化速度场与方向场,气流偏角增加最大达43%。进口管径对双三次收缩段的流场特性影响不大。
- 气流品质 /
- 收缩曲线 /
- 流场测量试验 /
- 收缩段出口流场 /
- 分离特性
Abstract: Based on the high subsonic linear cascade wind tunnel of Northwestern Polytechnical University, the outlet flow field of Witozinsky contraction section was measured, and the poor directional field quality was found. Besides, the core area was reduced by 15% at pitchwise compared with the velocity and total pressure fields. Then exit core area, uniformity and separation characteristics of four contraction sections were compared by simulation. It was found that Witozinsky curve contracted at front, and contracting too fast caused vortex at inlet, but the outlet uniformity was better due to the longer outlet steady flow section. In contrast, double cubic curve mainly contracted at rear with greater forward pressure gradient of mainstream, so there existed thinner boundary layer, smaller deviation angle and better separation characteristics. The existing three-dimensional structure of Witozinsky contraction section widens the core area while disturbing airflow, deteriorating the velocity and direction fields, and increasing the deviation angle up to 43%. The inlet pipe diameter has little effect on the flow field characteristics of the double cubic contractions.
- airflow quality /
- contraction curve /
- flow field measurement experiment /
- ,contraction outlet flow field /
- separation characteristic

HTML

参考文献(21)

[1]	楚武利,刘前智,胡春波.航空叶片机原理［M］.西安:西北工业大学出版社,2009.
[2]	胡骏.航空叶片机原理［M］.北京:国防工业出版社,2014.
[3]	孙邵鹏,徐明方,王发祥,等.高速风洞和低速风洞流场品质规范［M］.北京.国防科学技术工业委员会,1991.
[4]	伍荣林,王振羽.风洞设计原理［M］.北京:北京航空学院出版社,1985.
[5]	程开甲,李元正.高低速风洞气动与结构设计［M］.北京:国防工业出版社,2003.
[6]	徐文峰,孙鹏,黄龙盛,等.扇形叶栅进口收缩段气动设计与实验研究［C］∥中国工程热物理学会热机气动热力学论文集.北京:中国工程热物理学会,2019:192031.1-192031.11.
[7]	刘卫红.轴对称收缩段设计研究［J］.空气动力学学报1998,16(2):111-115. LIU Weihong.The design and study of the axisymmetric convergent section［J］.Acta Aerodynamica Sinica,1998,16(2):111-115.(in Chinese)
[8]	周勇为,常熹钰,易仕和.低湍流度磁悬浮风洞的气动和结构设计［J］.流体力学实验与测量,2001,15(4):1-6. ZHOU Yongwei,CHANG Xiyu,YI Shihe.The aerodynamic and structural design of low turbulence intensity of MSWT［J］.Experiments and Measurements in Fluid Mechanics,2001,15(4):1-6.(in Chinese)
[9]	李强,丁珏,翁培奋.低湍流度低速风洞及气动设计［J］.上海大学学报,2007,13(2):203-207. LI Qiang,DING Jue,WENG Peifen.Aerodynamic and structural design of low-velocity and low-turbulence wind tunnel［J］.Journal of Shanghai University,2007,13(2):203-207.(in Chinese)
[10]	韩建涛,王晏根,阳诚武,等.跨音速涡轮平面叶栅风洞收缩段设计方法研究［J］.燃气轮机技术,2017,30(2):17-22. HAN Jiantao,WANG Yangen,YANG Chengwu,et al.Wind tunnel contraction design for transonic turbine linear cascade test［J］.Gas Turbine Technology,2017,30(2):17-22.(in Chinese)
[11]	王帅,刘小康,陆龙生.直流式低速风洞收缩段收缩曲线的仿真分析［J］.机床与液压,2012,40(11):100-104. WANG Shuai,LIU Xiaokang,LU Longsheng.Numerical analysis on contraction curve of low-speed blow down wind tunnel［J］.Machine Tool and Hydraulics,2012,40(11):100-104.(in Chinese)
[12]	王喜魁.风洞高次曲线收缩段壁型及其性能［J］.空气动力学学报,1997,15(2):251-255. WANG Xikui.The high-order curve wall shape and the characteristics of the tapering section of the wind tunnel［J］.Acta Aerodynamica Sinica,1997,15(2):251-255.(in Chinese)
[13]	仇健.基于CFD的汽车风洞收缩段设计及流场品质分析［D］.长沙:湖南大学,2011. QIU Jian.The automotive wind tunnel contraction section design and the flow field quality analysis based on CFD［D］.Changsha：Hunan University，2011.(in Chinese)
[14]	吴宗成,陈晏清,万曦.水洞收缩段流场的数值模拟及优选［J］.北京航空航天大学学报,1998,24(3):67-70. WU Zongcheng,CHEN Yanqing,WAN Xi.Numerical simulation and optimization for contraction flow of water tunnel［J］.Journal of Beijing University of Aeronautics and Astronautics,1998,24(3):67-70.(in Chinese)
[15]	苏耀西,林超强,洪流.矩形风洞收缩段流场的计算和分析［J］.空气动力学学报,1991,9(4):379-386. SU Yaoxi,LIN Chaoqiang,HONG Liu.Flow analysis of rectangular wind tunnel contraction［J］.Acta Aerodynamica Sinica,1991,9(4):379-386.(in Chinese)
[16]	MOREL T.Comprehensive design of axisymmetric wind tunnel contractions［R］.ASME Paper 75-FE-17,1975.
[17]	BORGER G G.The optimization of wind tunnel conreactions for the subsonic range［R］.NASA TTF-16899,1976.
[18]	BELL J H,MEHTA R D.Contraction design for small low-speed wind tunnels［R］.Palo Alto，CA，US：Stanford University,1988.
[19]	FANG F M,CHEN J C,HONG Y T.Experimental and analytical evaluation of flow in a square-to-square wind tunnel contraction［J］.Journal of Wind Engineering and Industrial Aerodynamics,2001,89(3/4):247-262.
[20]	张连河,范洁川.三维收缩段优化设计研究［J］.空气动力学学报,2003,21(4):417-423. ZHANG Lianhe,FAN Jiechuan.Research of optimized design of the three-dimensional contraction［J］.Acta Aerodynamica Sinica,2003,21(4):417-423.(in Chinese)
[21]	李国文,徐让书.风洞收缩段曲线气动性能研究［J］.实验流体力学,2009,23(4):73-76,81. LI Guowen,XU Rangshu.Study of the performance of contractive curve for the wind tunnel［J］.Journal of Experiments in Fluid Mechanics,2009,23(4):73-76,81.(in Chinese)
