考虑电涡流效应的射流管伺服阀建模及频率特性

訚耀保; 郭文康; 胡云堂

doi:10.13224/j.cnki.jasp.2020.08.023

考虑电涡流效应的射流管伺服阀建模及频率特性

doi: 10.13224/j.cnki.jasp.2020.08.023

基金项目: 国家自然科学基金（51775383）; 国家重点研发计划（2018YFB2001100）; 江西省科技计划资助项目（20151BDH80064）

计量
- 文章访问数: 441
- HTML浏览量: 135
- PDF量: 313
- 被引次数: 0
出版历程
- 收稿日期: 2019-12-26
- 刊出日期: 2020-08-28

Modeling and frequency characteristics of jet-pipe servo valve considering eddy current effect

1.
School of Mechanical Engineering,Tongji University,Shanghai 201804,China
2.
School of Mechanical and Materials Engineering,Jiujiang University,Jiujiang Jiangxi 332005,China

摘要

摘要: 针对射流管伺服阀在电-磁-力-位移转换过程中的响应滞后问题,建立了考虑电涡流效应的力矩电动机数学模型,获取了力矩电动机的频率特性。以某型射流管伺服阀为例,建立了考虑电涡流效应的射流管伺服阀数学模型,得到了主要性能参数对伺服阀频率特性的影响规律。结果表明:气隙长度、气隙磁导率的增加以及气隙有效面积的减小会导致伺服阀响应变慢,控制线圈匝数不影响伺服阀的频率特性,导磁材料电导率的减小能提高伺服阀的响应速度。对伺服阀进行试验研究,理论值和试验值之间的差值约为5%,验证了所建模型的正确性和有效性。
- 射流管伺服阀 /
- 力矩电动机 /
- 电涡流效应 /
- 等效磁路 /
- 频率特性
Abstract: Considering the problem of response lag of jet pipe servo valve in the process of electric-magnetic-force-displacement conversion, a mathematical model of torque motor considering eddy current effect was established, and the dynamic characteristics of torque motor were obtained. Taking a certain type of jet tube flow servo valve as an example, a mathematical model of jet pipe servo valve considering the eddy current effect was established. The influence of main parameters on the frequency characteristics of the servo valve was obtained. Among them, the increase of air gap length, air gap magnetic permeability, and decrease of air gap effective area caused the servo valve to respond slowly, the number of control coil turns did not affect the frequency characteristics of the servo valve; decreasing the conductivity of the magnetically conductive material can increase the response speed of the servo valve. The servo valve was tested, the difference between the theoretical value and the test value was about 5%, verifying the correctness and effectiveness of this model.
- jet-pipe servo valve /
- torque motor /
- eddy current influence /
- ,equivalent magnetic circuit /
- frequency characteristics

HTML

参考文献(17)

[1]	URATA E.On the torque generated in a servo valve torque motor using permanent magnets［J］.Journal of Mechanical Engineering Science,2007,221(5):519-525.
[2]	JEONG H S.Novel torque motor model for performance design and analysis of a servo valve with per-manent magnets［J］.Journal of Mechanical Science and Technology,2018,32(5):2253-2259.
[3]	LIU C,JIANG H.Influence of magnetic reluctances of magnetic elements on servo valve torque motors［J］.Chinese Journal of Mechanical Engineering,2016,29(1):136-144.
[4]	訚耀保,李聪,李长明,等.力矩马达气隙误差对电液伺服阀零偏的影响［J］.华中科技大学学报(自然科学版),2019,47(3):55-61. YIN Yaobao,LI Cong,LI Changming,et al.Influence of torque motor air-gap error on servo valve zero deviation［J］.Huazhong University of Science and Technology(Natural Science Edition),2019,47(3):55-61.(in Chinese)
[5]	ZHANG Q,YAN L,DUAN Z,et al.High torque density torque motor with hybrid magnetization pole arrays for jet pipe servo valve［J］.IEEE Transactions on Industrial Electronics,2019,67(3):2133-2142.
[6]	MERRITT H E.Hydraulic control systems［M］.New York:John Wiley & Sons,1967.
[7]	MCCLOY D,MARTIN H.Control of fluid power［M］.New York:Halsted Press,1980.
[8]	HIREMATH S S,VENKATESHA C S,KARUNANIDHI S.Investi-gation on the critical parameters affecting the working design dynamics of a torque motor employed in an electro-hydraulic servovalve［J］.Simulation,2019,95(1):31-49.
[9]	LIN S J,AKERS A.A dynamic model of the flapper-nozzle component of an electrohydraulic servo-valve［J］.Journal of Dynamic Systems,Measurement,and Control,1989,111(1):105-109.
[10]	LIAW C J,BROWN F T.Nonlinear dynamics of an electrohydraulic flapper nozzle valve［J］.Journal of Dynamic Systems,Measurement,and Control,1990,112(2):298-304.
[11]	ANDERSON R T,LI P Y.Mathematical modeling of a two spool flow control servovalve using a pressure control pilot［J］.Journal of dynamic systems,measurement,and control,2002,124(3):420-427.
[12]	SHARAN A S,HIREMATH S S,VENKATESH C S.Modeling and simulation of jet pipe servo valve torque motor［J］.Applied Mechanics and Materials,2014,592/593/594:2308-2313.
[13]	THOMAS D W P,PAUL J,OZGONENEL O,et al.Time-domain simulation of nonlinear transformers displaying hysteresis［J］.IEEE Transactions on Magnetics,2006,42(7):1820-1827.
[14]	MANADACHE L,TOPAN D.Managing eddy current losses and ferromagnetic material nonlinearities in distorting regimes［C］∥Proceedings of IEEE International Electric Machines and Drives Conference.Miami:IEEE,2009:1449-1454.
[15]	田源道.电液伺服阀技术［M］.北京:航空工业出版社,2008.
[16]	LI S,SONG Y.Dynamic response of a hydraulic servo-valve torque motor with magnetic fluids［J］.Mechatronics,2007,17(8):442-447.
[17]	李松晶,宋彦伟,聂伯勋.采用磁流体的射流管伺服阀试验研究［J］.机床与液压,2006(9):130-131,120.
