短壳绝热面积对液氢贮箱绝热性能影响

胡正根; 湛利华; 朱文俐

doi:10.13224/j.cnki.jasp.2020.08.024

短壳绝热面积对液氢贮箱绝热性能影响

doi: 10.13224/j.cnki.jasp.2020.08.024

基金项目: 国家重点基础研究发展计划（2017YFB0306300）；装备预先研究项目（305060509）

计量
- 文章访问数: 354
- HTML浏览量: 62
- PDF量: 284
- 被引次数: 0
出版历程
- 收稿日期: 2020-04-01
- 刊出日期: 2020-08-28

Effect of short-shell insulated area on thermal insulation performance of liquid hydrogen tank

1.
College of Mechanical and Electrical Engineering,Central South University,Changsha 410083,China
2.
Beijing Aerospace Systems Engineering Research Institute,China Academy of Launch Vehicle Technology,China Aerospace Science and Technology Corporation,Beijing 100076,China

摘要

摘要: 基于计算流体动力学(CFD)方法研究了典型5 m直径液氢贮箱在短壳未包裹绝热材料、50%面积及100%面积包裹绝热材料3种情况下对贮箱内液氢蒸发特性的影响。数值计算基于流体体积(VOF)模型计算两相流,基于Lee模型计算气液界面传质率,考虑了短壳包裹泡沫表面及未包裹泡沫的暴露表面结霜对漏热的影响,构建的数值模型及界面传质计算具有清晰的气液界面,准确地捕捉到了液氢液面的变化。结果表明:短壳是液氢贮箱漏热的主要因素,对液氢蒸发率影响起重要作用;相对于短壳未绝热,50%绝热使得液氢贮箱气相平均温度从110 K下降到32 K,绝热面积占比增加到100%时,气相平均温度下降到约23 K,绝热改善效果相对降低;比较短壳绝热面积占比从50%增加到100%与从0增加到50%对相对蒸发率影响,前者差异较小,仅降低24%,而后者差异明显,下降了409%。研究结果指导了液氢贮箱绝热结构的优化设计。
- 液氢贮箱 /
- 短壳结构 /
- 绝热性能 /
- 计算流体动力学(CFD) /
- 流体体积(VOF)
Abstract: Based on the computational fluid dynamics (CFD) method, the effect of the magnitude of typical 5 m diameter tank short-shell insulated area (non adiabatic, 50% adiabatic and 100% adiabatic) on the evaporation characteristics of liquid hydrogen tank was studied. The volume of fluid (VOF) model was used to calculate the two-phase flow with the Lee model for calculations of the mass transfer rate in the gas-liquid interface. The heat transfer boundary conditions due to possible frosting on the foam surface and the bare metal surface were considered. The numerical model and the interface mass transfer calculation had clear gas-liquid interface, and helped to accurately capture the change of liquid hydrogen level. The numerical results showed that short-shell was the main factor of heat leakage in liquid hydrogen tank and played an important role in the effect of liquid hydrogen evaporation rate. The average temperature of the gas phase decreased from 110 K in 0 case to 32 K in 50% case, while it only decreased to 23 K when the adiabatic area continued to increase to 100%, and the improvement effect of the adiabatic area was relatively reduced. Compared with the effect of the increase of the adiabatic proportion of short shell from 50% to 100% and from 0 to 50% on the relative evaporation rate, the difference of the former was small, only 24%, while the difference of the latter was obvious, with a decrease of 409%. The research results provide a guide to the optimization design of the thermal insulation structure of the liquid hydrogen storage tank.
- liquid hydrogen tank /
- short-shell structure /
- thermal insulation performance /
- ,computational fluid dynamics(CFD) /
- volume of fluid(VOF)

HTML

参考文献(21)

[1]	ZHANG Xiaobin,YAO Lei,QIU Limin,et al.Experimental study on cryogenic moisture uptake in polyurethane foam insulation material［J］.Cryogenics,2012,52(12):810-815.
[2]	SALERNO L,PLACHTA D W,HASTINGS L J,et al.An overview of NASA efforts on zero boiloff storage of cryogenic propellants［J］.Cryogenics,2001,41(11/12):833-839.
[3]	KARTUZOVA O,KASSEMI M,AGUI J,et al.Self-pressurization and spray cooling simulations of the multipurpose hydrogen test bed (MHTB) ground-based experiment［R］.Cleveland,OH:AIAA/ASME/SAE/ASEE Joint Propulsion Conference,2014.
[4]	SCHWEICKART,RUSSELL B.Thermodynamic analysis of a demonstration concept for the long-duration storage and transfer of cryogenic propellants［J］.Cryogenics,2014,64:283-288.
[5]	KARTUZOVA O,KASSEMI M.CFD modeling of the multipurpose hydrogen test bed (MHTB) self-pressurization and spray bar mixing experiments in normal gravity:effect of the accommodation coefficient on the tank pressure［R］.Orlando FL:AIAA Propulsion and Energy Forum,2015.
[6]	KASSEMI M,KARTUZOVA O.Effect of interfacial turbulence and accommodation coefficient on CFD predictions of pressurization and pressure control in cryogenic storage tank［J］.Cryogenics,2016,74:138-153.
[7]	GRAYSON G D,LOPEZ A,CHANDLER F O.Cryogenic tank modeling for the saturn AS-203 experiment［R］.Sacramento,CA:the 42nd AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit,2006.
[8]	KUMAR S P,PRASAD B V S S S.Influence of surface evaporation on stratification in liquid hydrogen tanks of different aspect ratios［J］.International Journal of Hydrogen Energy,2007,32(12):1954-1960.
[9]	WEN H L.A pressure iteration scheme for two-phase flow modeling［R］.Los Alamos,NM:Energy Division Los Alamos Scientific Laboratory,1980.
[10]	KASSEMI I M,BARSI S.Numerical and experimental comparisons of the self-pressurization behavior of an LH2 tank in normal gravity［J］.Cryogenics,2008,48(3/4):122-129.
[11]	MAJUMDAR A,VALENZUELA J,ANDRE L C,et al.Numerical modeling of self-pressurization and pressure control by a thermodynamic vent system in a cryogenic tank［J］.Cryogenics,2016,74:113-122.
[12]	WANG Lei,LI Yanzhong,LI Cui,et al.CFD investigation of thermal and pressurization performance in LH2 tank during discharge［J］.Cryogenics,2013,57:63-73.
[13]	LIU Zhan,LI Yanzhong,JIN Yonghua.Pressurization performance and temperature stratification in cryogenic final stage propellant tank［J］.Applied Thermal Engineering,2016,106:211-220.
[14]	王磊,厉彦忠,李翠,等.液体火箭贮箱增压排液过程温度场数值研究［J］.航空动力学报,2011,26(8):1893-1899. WANG Lei,LI Yanzhong,LI Cui,et al.Numerical study on temperature distribution of tank pressurization process of liquid rocket during outflow［J］.Journal of Aerospace Power,2011,26(8):1893-1899.(in Chinese)
[15]	程向华,厉彦忠,陈二锋,等.回流口位置对液体火箭液氧贮箱热分层的影响［J］.航空动力学报,2009,24(1):224-229. CHENG Xianghua,LI Yanzhong,CHEN Efeng,et al.Effect of the return flow locations on the thermal stratification in liquid oxygen tank of rocket［J］.Journal of Aerospace Power,2009,24(1):224-229.(in Chinese)
[16]	FU Juan,BENGT Sunden,CHEN Xiaoqian.Influence of wall ribs on the thermal stratification and self-pressurization in a cryogenic liquid tank［J］.Applied Thermal Engineering,2014,73(2):1421-1431.
[17]	CHEN Liang,LIANG Guozhu.Simulation research of vaporization andpressure variation in a cryogenic propellant tank at the launch site［J］.Microgravity Science and Technology,2013,25(4):203-211.
[18]	陈亮,梁国柱,魏一,等.低温推进剂贮箱压力变化的CFD仿真［J］.航空动力学报,2015,30(6):1470-1477. CHEN Liang,LIANG Guozhu,WEI Yi,et al.CFD simulation of cryogenic propellant tank pressure variation［J］.Journal of Aerospace Power,2015,30(6):1470-1477.(in Chinese)
[19]	王舜浩,朱文俐,胡正根,等.液氢缩比贮箱蒸发特性数值模拟机实验研究［J］.化工学报,2019,70(3):840-849. WANG Shunhao,ZHU Wenli,HU Zhenggen,et al.Numerical simulation and experimental validation of evaporation characteristics of scaled liquid hydrogen tank［J］.CIESC(Chemical Industry and Engineering Society of China) Journal,2019,70(3):840-849.(in Chinese)
[20]	ZHOU Rui,ZHU WenLi,HU Zhenggen,et al.Simulations on effects of rated ullage pressure on the evaporation rate of liquid hydrogen tank［J］.International Journal of Heat and Mass Transfer,2019,134:842-851.
[21]	BRACKBILL J U,KOTHE D B,ZEMACH C.A continuum method for modelingsurface tension［J］.Journal of Computational Physics,1992,100(2):335-354.
