湍流参数对风扇宽频噪声预测影响

杨野; 王良锋; 洪少尊; 刘旭亮; 杨党国

doi:10.13224/j.cnki.jasp.20200357

湍流参数对风扇宽频噪声预测影响

doi: 10.13224/j.cnki.jasp.20200357

杨野^1,2,
王良锋^1,2,
洪少尊^1,2,
刘旭亮¹,
杨党国^1,2, ,

1.
中国空气动力研究与发展中心空气动力学国家重点实验室，四川绵阳 621000
2.
中国空气动力研究与发展中心高速空气动力研究所，四川绵阳 621000

基金项目: 国家自然科学基金（11972360）

详细信息

作者简介:
杨野（1994-），男，研究实习员，硕士，主要从事叶轮机械气动声学研究。

通讯作者:
杨党国（1980-），男，研究员，博士，主要从事复杂流动机理、气动噪声测量与控制研究。E-mail：yangdg-cardc@163.com

中图分类号: V231.3
计量
- 文章访问数: 291
- HTML浏览量: 85
- PDF量: 115
- 被引次数: 0
出版历程
- 收稿日期: 2020-08-27
- 刊出日期: 2021-10-28

Influence of turbulent parameters on fan broadband noise prediction

1.
State Key Laboratory of Aerodynamics，China Aerodynamics Research and Development Center，Mianyang Sichuan 621000，China
2.
High Speed Aerodynamics Institute，China Aerodynamics Research and Development Center，Mianyang Sichuan 621000，China

摘要

摘要: 对于现代先进涡扇发动机，占比越来越大的风扇/压气机宽频噪声成为亟需解决的问题。基于三维风扇声源模型，开展了湍流输入参数对宽频噪声预测影响的研究。结果表明：后传声功率级比前传声功率级普遍高5 dB左右；当湍流参数增大时，也会较大幅度改变前传和后传的声功率级，但对频谱形状影响较小；声功率级随湍流积分尺度增大而减小，随背景湍流速度、中心线湍流速度、湍流宽度增大而增大，其中背景湍流速度对宽频噪声影响最大。发现湍流参数通过作用于上洗速度谱来影响宽频噪声预测结果。
- 宽频噪声预测 /
- 三维声源模型 /
- 快速预测方法 /
- 湍流参数 /
- 背景湍流速度
Abstract: For modern advanced turbofan engines，the increasing broadband noise of fan/compressor has become an urgent problem.Based on the 3D fan sound source model，the influence of turbulent input parameters on broadband noise prediction was studied.As a result，the back-transmission sound power level was generally about 5 dB higher than the front-transmission sound power level.When the turbulent parameters increased，the front-transmission and the back-transmission sound power level could also change greatly，but had little influence on the spectrum shape；the sound power level decreased with the increase of the turbulence integral scale，and increased with the background turbulence velocity，the centerline turbulence velocity and the turbulence width，of which the background turbulence velocity had the greatest influence on the broadband noise.It was found that the turbulent parameters affected the prediction results of broadband noise by acting on the upwash velocity spectrum.
- broadband noise prediction /
- 3D sound source model /
- fast prediction method /
- turbulent parameters /
- background turbulence velocity

HTML

参考文献(18)

[1]	何琳，朱海潮，邱小军，等.声学理论与工程应用[M].北京:科学出版社,2006.
[2]	HUFF D L.Fan noise prediction: status and needs[R].NASA TM-97-206533,1997.
[3]	PEAKE N,PARRY A B.Modern challenges facing turbomachinery aeroacoustics[J].Annual Review of Fluid Mechanics,2011,44（1）:227-248.
[4]	许尧.发动机风扇与外涵道噪声传播计算及优化[D].上海:上海交通大学,2013.
[5]	GANZ U W,JOPPA P D,PATTEN T J,et al.Boeing 18-inch fan rig broadband noise test[R].NASA-CR-1998-208704,1998.
[6]	JACOB M C,BOUDET J,CASALINO D,et al.A rod-airfoil experiment as benchmark for broadband noise modeling[J].Theoretical and Computational Fluid Dynamics,2005,19（3）:171-196.
[7]	TAM C K,JU H.Airfoil tones at moderate Reynolds number[J].Journal of Fluid Mechanism,2012,690:536-570.
[8]	MANI R.Noise due to interaction of inlet turbulence with isolated stators and rotors[J].Jounal of Sound and Vibration,1971,17（2）:251-560.
[9]	AMIET R K.Acoustic radiation from an airfoil in a turbulent stream[J].Journal of Sound and Vibration,1975,41（4）:407-420.
[10]	GLEGG S A L.Broadband fan noise generated by small scale turbulence[R].NASA CR-207752,1998.
[11]	HANSON D B.Theory for broadband noise of rotor and stator cascades with inhomogeneous inflow turbulence including effects of lean and sweep[R].NASA CR-2001-210762,2001.
[12]	EVERS I,PEAKE N.On sound generation by the interaction between turbulence and a cascade of airfoils with non-uniform mean flow[J].Journal of Fluid Mechanics,2002,463:25-52.
[13]	NALLASAMY M,ENVIA E.Computation of rotor wake turbulence noise[J].Journal of Sound and Vibration,2005,282（3）:649-678.
[14]	GRACE S M,MAUNUS J,SONDAK D L.Effect of CFD wake prediction in a hybrid simulation of fan broadband interaction noise[R]AIAA 2011-2875,2011.
[15]	ATASSI H M,VINOGRADOV I V.A model for fan broadband interaction noise in nonuniform flow[R].AIAA 2005-2880,2005.
[16]	ATASSI H M,VINOGRADOV I V.Modelling broadband fan noise and comparison with experiments[R].AIAA 2007-3691,2007.
[17]	ZHANG Weiguang,WANG Xiaoyu,SUN Xiaofeng.Prediction of fan broadband noise using lifting surface method[J].AIAA Journal,2015,53（10）:2845-2855.
[18]	POSSON H,MOREAU S,ROGER M.Fan-OGV broadband noise prediction using a cascade response[R].AIAA 2009-3150,2009.
