二冲程重油直喷发动机混合气形成研究

赵振峰; 俞春存; 董雪飞; 王蕾

doi:10.13224/j.cnki.jasp.20200370

二冲程重油直喷发动机混合气形成研究

doi: 10.13224/j.cnki.jasp.20200370

1. 北京理工大学机械与车辆学院, 北京 100081;
2. 航天时代飞鸿技术有限公司航天时代飞鸿技术股份有限能源与动力技术研究室, 北京 100081

详细信息

作者简介:
赵振峰(1974-),男,副教授、博士生导师,博士,从事航空活塞发动机领域研究。

中图分类号: V234
计量
- 文章访问数: 696
- HTML浏览量: 154
- PDF量: 311
- 被引次数: 0
出版历程
- 收稿日期: 2020-09-03
- 刊出日期: 2021-08-28

Research on mixture formation of two-stroke heavy fuel direct injection engine

1. School of Mechanical Engineering, Being Institute of Technology, Beijing 100081, China;
2. Energy and Power Technology Research Department, Aerospace Times FeiHong Technology Company Limited, Beijing 100081, China

摘要

摘要: 针对航空煤油蒸发困难、二冲程发动机油耗高的问题，建立了二冲程重油直喷发动机的三维仿真模型，并通过试验验证了模型的准确性。在此基础上研究了发动机的换气及混合气形成过程。研究结果表明：推迟喷油在减少燃油短路时间的同时，避开了排气流量较大的自由排气阶段，可以提升燃油捕获率；提前喷油，利用废气的高温可以加快煤油的蒸发进程，并且喷油过晚会导致煤油蒸发不完全、油气混合不均。所研究发动机在下止点前80°曲轴转角开始喷油可以保证燃油蒸发和均匀混合的同时提升燃油的捕获率。此时发动机具有较高的指示功率和较低的燃油消耗率，分别为84.0 kW和360.3 g/kWh。该研究结果可以为二冲程重油直喷发动机的喷油参数优化提供理论支撑。
- 二冲程 /
- 直喷 /
- 航空煤油 /
- 混合气形成 /
- 计算流体动力学（CFD）仿真
Abstract: In view of the problems of difficulty in evaporation of aviation kerosene and high fuel consumption of two-stroke engines,a three-dimensional simulation model of a two-stroke direct injection engine fueled with aviation kerosene was established,and the accuracy of the model was verified through experiments. On this basis, scavenging and mixture formation process was studied. The research results showed that postponing fuel injection reduced the short-circuit time of fuel, and at the same time avoided the free exhaust phase with large exhaust mass flow, which can improve the fuel capture rate. Utilizing the high temperature of exhaust gas can speed up the evaporation process of kerosene. Injection too late could lead to incomplete evaporation and uneven mixture of fuel and fresh charge. For this engine,80° before bottom dead center indicated an appropriate injection timing enabling fuel evaporation and uniform mixing while increasing the fuel capture rate. At this time, the engine had higher indicated power and lower indicated thermal efficiency, which were 84. 0 kW and 360. 3 g/kWh, respectively. The research results can provide theoretical support for the optimization of the fuel injection parameters of the two-stroke direct injection engine.
- two-stroke /
- direct injection /
- aviation kerosene /
- mixture formation /
- computational fluid dynamics (CFD) simulation

HTML

参考文献(19)

[1]	卢东亮,郑君,胡崇波, 等. 通用航空活塞发动机的发展现状研究[J].内燃机与配件,2019,10(8):64-66. LU Dongliang,ZHENG Jun,HU Chongbo.Study on the development status of general aviation piston engine[J].Internal Combustion Engines and Parts, 2019, 10(8):64-66. (in Chinese)
[2]	张奇,杜发荣. 小功率航空活塞发动机重油技术进展[J]. 小型内燃机与车辆技术,2014,43(4):81-85. ZHANG Qi,DU Farong.Small aero-piston engine heavy fuel technology development summary[J].Small Internal Com-bustion Engine and Vehicle Technique, 2014, 43(4):81-85. (in Chinese)
[3]	杜春媛,田梦园,胡春明. 二冲程重油航空发动机技术发展分析[J].小型内燃机与车辆技术,2020,49(3):92-96. DU Chunyuan, TIAN Mengyuan, HU Chunming.Technical development analysis of two-stroke heavy fuel aero engine[J].Small Internal Combustion Engine and Vehicle Technology,2020,49(3):92-96.(in Chinese)
[4]	胡春明,谷俊,周浩.活塞式航空直喷发动机的燃烧特性[J]. 航空动力学报,2015,30(10):2368-2375. HU Chunming,GU Jun,ZHOU Hao.Combustion characteristics for direct injection piston aviation engine[J]. Journal of Aerospace Power,2015,30(10):2368-2375.(in Chinese)
[5]	胡春明,王书典,毕延飞, 等. 活塞式航空煤油发动机的直喷特性[J].航空动力学报,2017,32(5):1035-1042. HU Chunming, WANG Shudian, BI Yanfei, et al. Combustion characteristics of direct injection piston aviation kerosene engine[J]. Journal of Aerospace Power, 2017, 32(5):1035-1042(in Chinese)
[6]	杨白凡. 二冲程点燃式缸内直喷重油发动机性能试验研究[D].南京:南京航空航天大学,2016. YANG Baifan. Research on a 2-stroke DISI heavy fuel engine's performance[D]. Nanjing:Nanjing University of Aeronautics and Astronautics,2016.(in Chinese)
[7]	白洪林. 空气辅助直喷汽油机喷雾特性及缸内混合气形成的研究[D].天津:天津大学,2015. BAI Honglin. Research on spray characteristics and mixture formation of the air-assisted direct injection gasoline engine[D].Tianjin:Tianjin University,2015.(in Chinese)
[8]	李骥琦. 低压空气辅助直喷发动机缸内混合气形成的试验研究[D].天津:天津大学,2012. LI Jiqi. Experimental research of in-cylinder mixture formation of an air-assist direct injection engine[D].Tianjin:Tianjin University,2015.(in Chinese)
[9]	LIU R, WEI M, YANG H.Cold start control strategy for a two-stroke spark ignition diesel-fuelled engine with air-assisted direct injection[J]. Applied Thermal Engineering, 2016, 108:414-426.
[10]	耿钊,赵振峰,李鸿, 等. 点燃式航空重油活塞发动机冷起动控制策略[J].航空动力学报,2020,35(1):185-195. GENG Zhao, ZHAO Zhenfeng, LI Hong, et al. Cold start control strategy of spark igniting type heavy oil piston aero-engine[J].Journal of Aerospace Power,2020,35(1):185-195. (in Chinese)
[11]	杨立青,张兆亮,秦静. 小型二冲程汽油机短路损失的数值可视化模拟[J].内燃机与配件,2016(10):8-13. YANG Liqing,ZHANG Zhaoliang,QIN Jing.Numerical visualization of air short-circuiting in a small two-stroke SI engine[J]. Internal Combustion Engine and Parts, 2016(10):8-13.(in Chinese)
[12]	王蕾,赵振峰,俞春存, 等. 航空活塞二冲程汽油机排气口高度优化研究[J].航空动力学报,2019,34(2):442-450. WANG Lei,ZHAO Zhenfeng,YU Chuncun,et al.Optimization research of the exhaust height on aviation piston two-stroke gasoline engine[J].Journal of Aerospace Power,2019, 34(2):442-450.(in Chinese)
[13]	郭栋,骞剑策,赵振峰,等. 航空活塞二冲程发动机的可变排气阀换气过程[J].航空动力学报,2020,35(3):471-481. GUO Dong, QIAN Jiance, ZHAO Zhenfeng, et al. Ventilation process of variable exhaust valve of aviation piston two-stroke engine[J]. Journal of Aerospace Power, 2020, 35(3):471-481.(in Chinese)
[14]	贾倩倩. 小型航空二冲程直喷汽油活塞发动机燃油喷射及燃烧特性研究[D].北京:北京交通大学,2014. JIA Qianqian.Study on the fuel injection and combustion preperty of light-weight, two-stroke, GDI aeroengine[D]. Beijing:Beijing Jiaotong University,2014.(in Chinese)
[15]	CATHCART G, ZAVIER C. Fundamental characteristics of an air-assisted DI combustion system as applied to 4-stroke automotive gasoline engines[R]. Society of Automotive Engineers,SAE Paper 2000-010256,2000.
[16]	高宏力,张付军,王苏飞,等. 航空煤油活塞发动机空气辅助喷射系统喷雾特性试验研究[J]. 兵工学报,2019,40(5):927-937. GAO Hongli, ZHANG Fujun, WANG Sufei, et al. Experimental study of air-assisted spray characteristics of aviation kerosene piston engine[J]. Acta Armamentarii, 2019, 40(5):927-937.(in Chinese)
[17]	HU Jingchao, LIU Bolan, ZHANG Chao, et al. Experimental study on the spray characteristics of an air-assisted fuel injection system using kerosene and gasoline[J]. Fuel. 2019, 235:782-94.
[18]	王思奇,杨海青. 航空重油发动机气助雾化喷嘴雾化机理仿真[J].内燃机学报,2018,36(2):127-135. WANG Siqi, YANG Haiqing. Simulation on atomization mechanism of air-assisted injector for aircraft heavy fuel engine[J].Transactions of CSICE,2018,36(2):127-135.(in Chinese)
[19]	贝太学,魏民祥,刘锐,等. 异步点火相位对二冲程发动机爆震燃烧的影响[J].航空动力学报,2017,32(2):322-329. BEI Taixue,WEI Minxiang,LIU Rui,et al.Effects of asynchronous ignition phase on knock combustion of two-stroke engine[J].Journal of Aerospace Power,2017,32(2):322-329. (in Chinese)
