倾转四旋翼飞行器直升机模式操纵策略研究

周攀; 陈仁良; 俞志明

doi:10.13224/j.cnki.jasp.20200384

倾转四旋翼飞行器直升机模式操纵策略研究

doi: 10.13224/j.cnki.jasp.20200384

南京航空航天大学航空学院直升机旋翼动力学国家级重点实验室，南京 210016

基金项目: 国家自然科学基金（11672128）；江苏高校优势学科建设工程资助项目

详细信息

作者简介:
周攀（1992-），男，博士生，主要从事直升机飞行力学与控制方面的研究。

中图分类号: V212.4
计量
- 文章访问数: 415
- HTML浏览量: 104
- PDF量: 173
- 被引次数: 0
出版历程
- 收稿日期: 2020-09-13
- 刊出日期: 2021-10-28

Investigation of control strategy for quad-tilt-rotor aircraft in helicopter mode

National Key Laboratory of Science and Technology on Rotorcraft Aeromechanics，College of Aerospace Engineering，Nanjing University of Aeronautics and Astronautics，Nanjing 210016，China

摘要

摘要: 由于倾转四旋翼飞行器具有特殊的构型，针对直升机模式下的操纵策略，建立了样机的非线性飞行动力学模型并结合试验数据进行了验证，提出了适用于直升机模式的四种操纵方式，对比了不同操纵方式相应的配平值、操纵功效及操纵耦合，随后确定了一组相对合理的操纵方式，解决了倾转四旋翼飞行器在直升机模式下操纵冗余的问题。分析了重心位置对所确定操纵方式的配平特性和操纵功效的影响。结果表明：纵横向通道下总距差动引起的操纵功效比周期变距联动大得多；偏航通道下周期变距差动引起的操纵功效大于总距差动，横向周期变距差动引起的交叉耦合小于纵向周期变距差动；正常重心位置所得到的配平量和交叉耦合最小。
- 倾转四旋翼飞行器 /
- 飞行动力学模型 /
- 配平 /
- 操纵策略 /
- 操纵功效 /
- 操纵冗余
Abstract: Quad-tilt-rotor aircraft is a vehicle of particular configuration.For its strategy of the helicopter mode，a nonlinear flight dynamic model was established for a prototype，and some relevant test were carried out.Four control strategies were proposed，and a relatively reasonable control strategy was determined by comparing the trim values，control efficiency and cross coupling.The control redundant problem of quad-tilt-rotor aircraft in helicopter mode was solved under the strategy.At last，the influence of the center of gravity location on trim characteristics and control efficiency was analyzed.The results showed that the main control efficiency of longitudinal and lateral channel obtained by collective differential was much greater than by linkage of cyclic pitch.The main control efficiency of yaw channel obtained by cyclic pitch differential was greater than by collective differential.The cross coupling of yaw channel obtained by lateral cyclic pitch differential was less than longitudinal cyclic pitch differential.The values of trimming and cross coupling were the minimum at the normal position of center of gravity.
- quad-tilt-rotor aircraft /
- flight dynamic model /
- trim /
- control strategy /
- control efficiency /
- control redundant

HTML

参考文献(20)

[1]	陈恒,左晓阳,张玉琢.倾转旋翼飞机技术发展研究[J].飞行力学,2007,25（1）:5-8.
[2]	薛蒙,孙强.倾转旋翼机军事需求与关键技术分析[J].直升机技术,2020（1）:47-49，27.
[3]	BRAGANCA E.The V-22 osprey:from trouble past to viable and flexible option[J].Joint Force Quarterly,2012,66:80-84.
[4]	KING D W.A system engineering approach to carefree maneuvering in the BA609[R].Grapevine,US:American Helicopter Society,2005.
[5]	SNYDER D E.The quad tiltrotor:its beginning and evolution[R].Arlington,US:International Powered Lift Conference,2000.
[6]	RADHAKRISHMAN A,SCHMITZ F H.Quad tilt rotor aerodynamics in ground effect[R].Toronto,Canda:AIAA Applied Aerodynamics Conference,2006.
[7]	RADHAKRISHMAN A.An experimental investigation of ground effecton a quad tilt rotor in hover and low speed forward flight[D].College Park,US:University of Maryland,2006.
[8]	YEO H,JOHNSON W.Performance and design investigation of heavy lift tilt-rotor with aerodynamic interference effects[J].Journal of Aircraft,2009,46（4）:1231-1239.
[9]	潘浙平.倾转四旋翼飞行器倾转过渡走廊计算方法研究[D].南京:南京航空航天大学,2019.
[10]	周攀,陈仁良,俞志明.倾转四旋翼飞行器直升机模式操稳特性分析[J].西北工业大学学报,2021,39（3）:675-684.
[11]	俞志明,陈仁良,孔卫红.倾转四旋翼飞行器倾转过渡走廊分析方法研究[J].北京航空航天大学学报,2020,46（11）:2106-2113.
[12]	WANG Z G,ZU R,DUAN D Y,et al.Tuning of ADRC for QTR in transition process based on NBPO hybrid algorithm[J].IEEE Access,2019（7）:177219-177240.
[13]	蒋海辉.倾转四旋翼飞行器操纵策略研究[D].南京:南京航空航天大学,2019,35-50.
[14]	严旭飞,陈仁良.倾转旋翼机动态倾转过渡过程的操纵策略优化[J].航空学报,2017,38（7）:520865.1-520865.11.
[15]	曹芸芸,陈仁良.倾转旋翼飞行器的操纵策略和配平方法[J].南京航空航天大学学报,2009,41（1）:6-10.
[16]	夏青元,徐锦法,金开保.倾转旋翼飞行器的建模和操纵分配策略[J].航空动力学报,2013,28（9）:2016-2028.
[17]	余新,陈仁良.基于增益调度与光滑切换的倾转旋翼机的最优控制[J].北京航空航天大学学报,2021,47（6）:1186-1198.
[18]	TALBOT P D,TINLING B E ,DECKER W A.A mathematical model of a single main rotor helicopter for piloted simulation [R].San Jose,US:NASA Technical Memorandum 84281,1982.
[19]	曹芸芸.倾转旋翼飞行器飞行动力学数学建模方法研究[D].南京:南京航空航天大学,2012.
[20]	FERGUSON S W.A mathematical model for real time flight simulation of a generic tilt-rotor aircraft [R].NASA CR-166536,1988.
