灭火弹气体发生器内流场数值模拟

李云峰; 邓康清; 鲁锐华; 秦沛文; 郭春亮; 闫立帆; 黄昌龙

doi:10.13224/j.cnki.jasp.20200385

灭火弹气体发生器内流场数值模拟

doi: 10.13224/j.cnki.jasp.20200385

1.
中国航天科技集团有限公司湖北航天化学技术研究所航天化学动力技术重点实验室，湖北襄阳 441003
2.
中国航天科技集团有限公司湖北航天化学技术研究所，湖北襄阳 441003

详细信息

作者简介:
李云峰（1995-），男，硕士生，灭火弹设计与仿真。E-mail：fibonacci2037@163.com

中图分类号: V435
计量
- 文章访问数: 477
- HTML浏览量: 105
- PDF量: 219
- 被引次数: 0
出版历程
- 收稿日期: 2020-09-13
- 刊出日期: 2021-09-28

Numerical simulation of internal flow field in gas generator of fire extinguishing bomb

1.
Key Laboratory of Aerospace Chemical Power Technology， Hubei Institute of Aerospace Chemical Techologh， China Aerospace Science and Technology Corporation，Xiangyang Hubei 441003，China
2.
Hubei Institute of Aerospace Chemistry Technology， China Aerospace Science and Technology Corporation，Xiangyang Hubei 441003，China

摘要

摘要: 为了提高灭火弹灭火性能，优化灭火弹结构设计，利用Fluent对灭火弹气体发生器内流场进行仿真计算，通过改变气体发生器开孔情况及发生剂参数调整弹内流场分布。计算结果显示：当首孔距离等于15倍气体发生器排气孔孔径时，灭火弹壳体近壁面存在5个大小相近且数值较高的压强峰，压力分布最利于灭火弹壳体预制孔槽破裂；灭火弹内气体发生器上排气孔对称性越强，发生器内压力分布越均匀。经过试验验证，仿真所得压力-时间曲线与试验测得数据吻合良好，说明该模型适用于灭火弹内流场仿真。
- 灭火弹 /
- 气体发生器 /
- 内流场 /
- 数值模拟 /
- 排气孔分布
Abstract: In order to improve the fire-fighting performance and optimize the structure design of fire extinguishing bombs，Fluent was used to simulate the flow field in the gas generator of fire extinguishing bombs，and the flow field distribution in the bomb was adjusted by changing the opening of the gas generator and the parameters of the propellant.The calculation results showed that when the first hole distance was equal to 15 times the gas generator exhaust hole diameter，there were 5 pressure peaks of similar size and higher value on the near wall surface of the fire extinguishing bomb shell，and the pressure distribution was most conducive to the rupture of the prefabricated hole slot of the fire extinguishing bomb shell；the stronger symmetry of the exhaust holes on the gas generator in the fire extinguishing bomb indicated more uniform pressure distribution in the generator.The experimental verification showed that the pressure-time curve obtained by the simulation was in good agreement with the measured data，indicating that the model is suitable for simulation of the internal flow field of the fire extinguishing bomb.
- fire extinguishing bomb /
- gas generator /
- internal flow field /
- numerical simulation /
- vent distribution

HTML

参考文献(19)

[1]	刘耀鹏,王克印,黄勇，等.灭火弹爆炸抛撒效应数值模拟与分析[J].陕西理工学院学报（自然科学版）,2013,29（1）:36-41.
[2]	牛兴林,张春阳,孟春祥.迫击炮森林灭火弹适用性及药剂分散技术[J].消防科学与技术,2012,31（2）:177-179.
[3]	吴长龙.森林灭火航弹二元中心爆管研究[D].哈尔滨：哈尔滨工程大学,2016.
[4]	赵浩合,武建德,王紫民.一种新型迫击炮灭火弹的外弹道仿真研究[J].消防科学与技术,2016,35（4）:546-548.
[5]	王紫民,武建德.一种新型森林灭火弹的仿真设计[J].消防科学与技术,2015,34（5）:623-625.
[6]	陈吉潮,王克印,刘耀鹏.基于MATLAB的某一森林灭火弹外弹道仿真与运用[J].陕西理工学院学报（自然科学版）,2012,28（1）:53-58.
[7]	韩宝成,雷红飞,徐豫新，等.液体灭火弹动态抛撒区域工程计算方法[J].含能材料,2011,19（3）:310-314.
[8]	陈玉昆,王克印,黄海英，等.中心装药灭火弹结构与爆轰抛撒关系分析[J].消防科学与技术,2014,33（8）:946-948.
[9]	朱聪,梁增友,邓德志，等.装药结构对灭火弹灭火剂抛撒影响研究[J].弹箭与制导学报,2020,40（4）:85-88.
[10]	刘刚.气动发射式高层建筑灭火炮研究[D].哈尔滨：哈尔滨工程大学,2012.
[11]	张亚东,熊敏,董明洋,等.电磁弹射灭火弹消防系统研究[J].强激光与粒子束,2020,32（2）:127-132.
[12]	姚磊.基于PAC的航弹投放系统研究[D].哈尔滨：哈尔滨工程大学,2016.
[13]	LIU Wanli,CHEN Xiong,LI Yingkun.Numerical simulation on cold-flow impact of the soft pulse separation device in dual pulse solid rocket motor[J].Journal of Physics:Conference Series,2020,1510（1）:012016.1-012016.6.
[14]	FRENCH A D,PANELLI M,DI LORENZO G,et al.Combustion instability and pressure oscillation numerical simulation in a solid rocket motor[R].AIAA 2017-4952,2017.
[15]	FAVINI B,ZAGHI S,SERRAGLIA F,et al.3D numerical simulation of ignition transient in SRM[R].AIAA 2006-4953,2006.
[16]	汤亮,邓康清,余小波,等.隔舱式双脉冲发动机第Ⅱ脉冲点火过程数值仿真[J].航空动力学报,2020,35（7）:1541-1548.
[17]	孟亮飞,田发林,周长省.阶梯装药固体火箭发动机点火内流场特性研究[J].弹箭与制导学报,2010,30（5）:127-130.
[18]	王珊珊,王浩,张博孜,等.大长径比、高密实火药床点火管点传火特性的影响因素[J].爆炸与冲击,2014,34（4）:489-494.
[19]	翁春生,王浩.计算内弹道学[M].北京：国防工业出版社,2006.
