半潜入喷管收敛段碳/酚醛材料烧蚀特性

巩伦昆; 邓哲; 魏晓林

doi:10.13224/j.cnki.jasp.20200413

半潜入喷管收敛段碳/酚醛材料烧蚀特性

doi: 10.13224/j.cnki.jasp.20200413

1.
中国兵器工业集团有限公司西安近代化学研究所，西安 710065
2.
中国兵器工业集团有限公司山西北方兴安化学工业有限公司，太原 030008

详细信息

作者简介:
巩伦昆（1989-），男，助理研究员，博士，研究方向为火箭发动机设计。

中图分类号: V235
计量
- 文章访问数: 346
- HTML浏览量: 140
- PDF量: 101
- 被引次数: 0
出版历程
- 收稿日期: 2020-09-30
- 刊出日期: 2021-11-28

Ablation characteristics of carbon/phenolic at converging section in semi-submerged nozzle

1.
Xi'an Modern Chemistry Research Institute，China North Industries Group Corporation Limited，Xi'an 710065，China
2.
Shanxi North Xing'an Chemical Industry Company Limited，China North Industries Group Corporation Limited，Taiyuan 030008，China

摘要

摘要: 采用流固热耦合数值方法，以及Abaqus的ALE（arbitrary Lagrangian-Eulerian，任意拉格朗日欧拉方法）自适应网格技术，对位于半潜入喷管收敛段的碳/酚醛的烧蚀现象进行了预估，与试验结果进行了对比分析。结果表明：在收敛段，Al/Al₂O₃液滴或颗粒对材料的传热烧蚀起到了关键作用，当气流与材料表面平行时，液滴或颗粒的影响很小；从碳/酚醛热分解角度出发，基于完全碳化即被剥蚀的假设，基本能够预估碳/酚醛材料的烧蚀特征，烧蚀速率大约为0.3 mm/s；后效碳化对材料碳化过程的影响明显，发动机工作期间，分解层的厚度大约为2.0 mm，考虑后效作用，分解层厚度可能会增加至4.0 mm左右；与喉衬接触的材料区域，喉衬的传热会明显加剧材料的碳化过程。
- 碳/酚醛 /
- 机械侵蚀 /
- 流固热耦合 /
- 固体火箭发动机 /
- 收敛段
Abstract: By solid-gas heat coupled numerical method and the ALE （arbitrary Lagrangian-Eulerian） adaptive meshing technique，the ablation of carbon/phenolic at the converging section in semi-submerged nozzle was investigated，and the results were validated by comparing the results with the experiment data.The results showed that the Al/Al₂O₃ particles and droplets had great effect on the heat transfer and ablation process at the converging section.The effects of Al/Al₂O₃ on the ablation can be ignored when the gas traveled almost parallel to the surface.Based on the decomposition mechanism of phenolic，the ablation characteristics of carbon/phenolic can be predicted assuming that the fully charred material was ablated immediately，and the ablation rate was about 0.3 mm/s.The char formation process after the motor burnout was very important for the carbon/phenolic.The thickness of pyrolysis zone was about 2.0 mm during the operating process of the motor，and may increase to 4.0 mm considering the pyrolysis process after motor burnout.The ablation of carbon/phenolic in contact with the carbon/carbon throat can be enhanced owing to the heat flux through carbon/carbon throat heat transfer.
- carbon/phenolic /
- mechanical erosion /
- solid-gas coupled heat transfer /
- solid rocket /
- convergence section

HTML

参考文献(21)

[1]	郑雷，蔡峨，冯文澜.碳酚醛材料的温度场及烧蚀研究[J].推进技术，1990,1:14-19.
[2]	BIANCHI D,TURCHI A,NASUTI F,et al.Chemical erosion of carbon-phenolic rocket nozzles with finite-rate surface chemistry[J].Journal of Propulsion and Power,2013,29（5）:1220-1230.
[3]	CROSS P G,BOYD I D.Two-dimensional modeling of ablation and pyrolysis with application to rocket nozzles[J].Journal of Propulsion and Power,2017,54（1）:212-224.
[4]	CROSS P G.Coupled simulations of finite-rate ablation with pyrolysis in rocket nozzles[J].Journal of Thermophysics and Heat Transfer,2020,34（2）:381-392.
[5]	CHENG G C,VENKATACHARI B S,COZMUTA I.Multi-scale simulations of in-depth pyrolysis of charring ablative thermal protection material[J].Computers and Fluids,2011,45:191-196.
[6]	张拜.防热材料烧蚀行为和热响应的数值仿真研究[D].兰州：兰州理工大学，2019.
[7]	张运法.低密度碳/酚醛复合材料高温响应数值模拟分析[D].哈尔滨：哈尔滨工业大学，2019.
[8]	王潇敏.树脂基热防护材料烧蚀传热机理及参数分析[D].合肥：中国科学技术大学，2018.
[9]	LI Weijie,HUANG Haiming,WANG Qing,et al.Protection of pyrolysis gases combustion against charring materials surface ablation[J].International Journal of Heat and Mass Transfer,2016,102:10-17.
[10]	NEILSON J H,GILCHRIST A.Erosion by a stream of solid particles[J].Wear,1968,11（2）:111-122.
[11]	NEILSON J H,GILCHRIST A.An experimental investigation into aspects of erosion in rocket motor nozzles[J].Wear,1968,11（2）:123-143.
[12]	OKA Y I,OKAMURA K,YOSHIDA T.Practical estimation of erosion damage caused by solid particle impact:Part 1 effects of impact parameters on a predictive equation[J].Wear,2005,259（1/2/3/4/5/6）:95-101.
[13]	OKA Y I,YOSHIDA T.Practical estimation of erosion damage caused by solid particle impact:Part 2 mechanical properties of materials directly associated with erosion damage[J].Wear,2005,259（1/2/3/4/5/6）:102-109.
[14]	THAKRE P,RAWAT R,CLAYTON R.Mechanical erosion of graphite nozzle in solid-propellant rocket motor[J].Journal of Propulsion and Power,2013,29（3）:593-602.
[15]	GEISLER R L.A global view of the use of aluminum fuel in solid rocket motors[J].AIAA-2002-3748,2002.
[16]	邓为.固体火箭发动机喷管内粒子侵蚀数值研究[D].哈尔滨:哈尔滨工程大学，2017.
[17]	常桁，刘一白，刘宇，等.固体火箭发动机碳基材料喷管机械侵蚀特性[J].航空动力学报，2016，31（3）:756-762.
[18]	YANG B C，CHEUNG F B.Numerical investigation of thermo-chemical and mechanical erosion of ablative materials[R].AIAA-93-2045,1993.
[19]	YANG B C，CHEUNG F B,KOO J H.Prediction of thermo-mechanical erosion of high-temperature ablatives in the SSRM Facility[R].AIAA-95-0254,1995.
[20]	POTTS R L.Hybrid integral/quasi-steady solution of charring abaltion[J].AIAA-90-1677,1990.
[21]	鲍福廷，侯晓.固体火箭发动机设计[M].北京：中国宇航出版社，2016.
