考虑局部应力效应的轮盘子午面破裂转速预测

全昌彪; 米栋; 刘扬; 廖明夫; 胡清清

doi:10.13224/j.cnki.jasp.20200421

考虑局部应力效应的轮盘子午面破裂转速预测

doi: 10.13224/j.cnki.jasp.20200421

全昌彪^1,2,
米栋²,
刘扬²,
廖明夫^1, ,,
胡清清³

1. 西北工业大学动力与能源学院, 西安 710072;
2. 中国航空发动机集团有限公司湖南动力机械研究所, 湖南株洲 412002;
3. 浙江大学化工机械研究所, 杭州 310027

基金项目:

航空科学基金（2015ZB08016）

详细信息

作者简介:
全昌彪(1987-),男,高级工程师,博士生,主要从事航空发动机结构强度及转子动力学研究。E-mail:equalman99@126.com

通讯作者:
廖明夫(1960-),男,教授、博士生导师,博士,主要从事转子动力学、旋转机械故障诊断、风力发电研究。E-mail:mfliao@nwpu.edu.cn

中图分类号: V231.95
计量
- 文章访问数: 139
- HTML浏览量: 6
- PDF量: 159
- 被引次数: 0
出版历程
- 收稿日期: 2020-10-10
- 刊出日期: 2021-07-28

Prediction of hoop mode burst speed of disk considering local stress effect

1. School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China;
2. Hunan Aviation Powerplant Research Institute, Aero Engine Corporation of China, Zhuzhou Hunan 412002, China;
3. Institute of Process Equipment, Zhejiang University, Hangzhou 310027, China

摘要

摘要: 平均应力法用于航空发动机轮盘破裂转速预测时结果一般偏大，对于带螺栓孔的轮盘破裂转速预测误差更大。考虑局部应力效应对平均应力法进行修正，引入修正因子来表征轮盘子午面平均周向应力和危险部位局部应力对轮盘破裂转速的加权影响。通过开展典型轮盘材料GH4169的光滑试样和缺口试样拉伸试验，并开展了两件模拟盘破裂转速测量试验，得到修正因子与缺口强度比的关系，然后同时采用这两种方法对某涡轮盘的破裂转速进行了预测，并开展了验证试验。试验结果表明：平均应力法预测结果偏大，误差达到了9.4%，而考虑局部应力修正后，预测值仅略低于试验值，误差仅2.67%。考虑局部应力效应的轮盘子午面破裂转速预测方法简单可靠，具有较高的工程实用价值。
- 平均应力法 /
- 破裂转速 /
- 局部应力 /
- 修正因子 /
- 缺口强度比
Abstract: Prediction result of burst speed of a aeroengine disk is usually slight larger than testing result when using the average stress method. The error tends to be much larger especially for the disk with a bolt hole. The average stress method was modified taking consideration of the effect of local stress.A correction factor was implanted to distinguish weight effect of the average hoop stress from that of the local stress of critical position at disk burst speed. Tensile test of standard cylinder and notched specimens of GH4169 and burst speed measurement test of two simulated disks were carried out. Notch strength ratio related to correction factor was calculated. Then the relationship between correction factor and notch strength ratio was obtained. Burst speed of a disk was predicted using these two methods and the burst speed measurement test was conducted. It concluded that the predicted result was larger than test data when using the average stress method with the error of 9.4%. When local stress was taken into consideration, the result was closely approximated to test data with the error of 2.67%. The prediction method of hoop mode burst speed of a disk considering local stress effect was of remarkable engineering practical worth value to its' simple formality and the reliable results.
- average stress method /
- burst speed /
- local stress /
- correction factor /
- notch strength ratio
