基于响应传递比的转子叶片动应变重构

朱昱达,  乔百杰,  符顺国,  敖春燕,  陈雪峰

downloadPDF
文章导航 > 航空动力学报  > 2021 >  36(8): 1690-1701
朱昱达, 乔百杰, 符顺国, 敖春燕, 陈雪峰. 基于响应传递比的转子叶片动应变重构[J]. 航空动力学报, 2021, 36(8): 1690-1701. doi: 10.13224/j.cnki.jasp.20200440
引用本文: 朱昱达, 乔百杰, 符顺国, 敖春燕, 陈雪峰. 基于响应传递比的转子叶片动应变重构[J]. 航空动力学报, 2021, 36(8): 1690-1701. doi: 10.13224/j.cnki.jasp.20200440
shu
ZHU Yuda, QIAO Baijie, FU Shunguo, AO Chunyan, CHEN Xuefeng. Dynamic strain reconstruction of rotating blade based on response transmissibility[J]. Journal of Aerospace Power, 2021, 36(8): 1690-1701. doi: 10.13224/j.cnki.jasp.20200440
Citation: ZHU Yuda, QIAO Baijie, FU Shunguo, AO Chunyan, CHEN Xuefeng. Dynamic strain reconstruction of rotating blade based on response transmissibility[J]. Journal of Aerospace Power, 2021, 36(8): 1690-1701. doi: 10.13224/j.cnki.jasp.20200440
shu

基于响应传递比的转子叶片动应变重构

doi: 10.13224/j.cnki.jasp.20200440

  • 1. 西安交通大学 机械工程学院, 西安 710049;

  • 2. 西安交通大学 机械制造系统工程国家重点实验室, 西安 710061;

  • 3. 中国航空发动机集团有限公司 四川燃气涡轮研究院, 成都 610500

基金项目:

国家自然科学基金（52075414，5170539）；中国航空发动机集团有限公司四川燃气涡轮院稳定支撑项目（J20192020）

详细信息
    作者简介:

    朱昱达(1995-),男,硕士生,主要从事航空发动机叶片动应变场重构技术研究。

    通讯作者:

    乔百杰(1985-),男,副教授、硕士生导师,博士,主要从事航空发动机叶片动应力重构技术研究。E-mail:qiao1224@xjtu.edu.cn

  • 中图分类号: V231.92

Dynamic strain reconstruction of rotating blade based on response transmissibility

  • 1. School of Mechanical and Engineering, Xi'an Jiaotong University, Xi'an 710049, China;

  • 2. The State Key Laboratory for Manufacturing Systems Engineering, Xi'an Jiaotong University, Xi'an 710061, China;

  • 3. Sichuan Gas Turbine Establishment, Aero Engine Corporation of China, Chengdu 610500, China

    摘要
  • 摘要: 提出基于响应传递比的转子叶片动应变重构方法，从系统应变频响特性出发，在频域获得应变-应变响应传递比关于模态振型的解析表达式，建立叶片已知测点应变与不可测位置应变的映射关系；开展高速旋转叶片动应变测量实验，建立叶片有限元模型，并采用转子叶片前4阶固有频率的实验结果修正有限元模型；开展考虑转速影响的转子叶片模态分析，提取对应的应变模态振型，计算得到单模态振动下应变-应变响应传递比；综合应变响应传递比和实测动应变重构叶片不可测位置的动应变。实验结果表明：与应变片实测结果相比，基于响应传递比的转子叶片动应变重构结果相对误差小于10%。



    Abstract: A dynamic strain reconstruction method of rotating blades based on response transmissibility was proposed. Based on the characteristics of system strain frequency response, an analytical expression of the strain-strain response transmissibility with respect to the modal shape was obtained within the frequency domain,and the mapping between the measured and unmeasured strains on the blade was established. Experiments for the blade dynamic strain measurement were conducted under the high-speed rotating condition. Then, the finite element model of the blade was established and updated by using the first four natural frequencies from experiments. The modal analysis of the rotating blades was conducted considering the prestress of rotational speed. The blade strain mode shapes were extracted from the finite element model and the strain-strain response transmissibility on single-mode resonance was calculated. Experimental results showed that the relative errors between the measured dynamic strains measured by strain gauges and the reconstructed dynamic strains based on the response transmissibility were less than 10%.



    • HTML
    • 参考文献(19)
  • [1] 张部声, 祝济之, 史剑, 等. 某型钛铝合金航空发动机叶片高温高周振动疲劳实验[J]. 航空动力学报,2020,35(6):1169-1175. ZHANG Busheng,ZHU Jizhi,SHI Jian,et al.Test of vibration fatigue for the TiAl alloy aeroengine blade at high tem-perature and high cycle[J]. Journal of Aerospace Power, 2020,35(6):1169-1175.(in Chinese)
    [2] 刘美茹, 滕光蓉, 肖潇, 等. 基于叶尖定时的航空发动机涡轮叶片振动测量[J].航空动力学报,2020,35(9):1954-1963. LIU Meiru,TENG Guangrong,XIAO Xiao,et al.Vibration measurement of turbine rotor blades of areo-engine based on blade tip-timing[J]. Journal of Aerospace Power, 2020, 35(9):1954-1963.(in Chinese)
    [3] 洪杰, 马艳红, 张大义. 航空燃气轮机总体结构设计与动力学分析[M].北京:北京航空航天大学出版社,2014.
    [4] 吴淑明, 胡海峰, 赵志斌, 等. 增强稀疏分解及其在叶片振动参数识别中的应用[J]. 机械工程学报, 2019, 55(19):19-27. WU Shuming, HU Haifeng, ZHAO Zhibin, et al.Enhancing sparse decomposition based blade vibration parameter identification[J].Journal of Mechanical Engineering,2019,55(19):19-27.(in Chinese)
    [5] 李伟. 航空发动机叶片失效分析中的共性问题[J]. 燃气涡轮试验与研究,2002,15(2):28-30,53. LI Wei.Common characteristics in failure analysis of aeroengine blade[J]. Gas Turbine Experiment and Research, 2002, 15(2):28-30,53.(in Chinese)
    [6] CHEN Z,YANG Y,XIE Y,et al.Non-contact crack detection of high-speed blades based on principal component analysis and Euclidian angles using optical-fiber sensors[J].Sensors and Actuators:A Physical,2013,201(6):66-72.
    [7] KNAPPETT D, GARCIA J. Blade tip timing and strain gauge correlation on compressor blades[J]. Proceedings of the Institution of Mechanical Engineers:Part G Journal of Aerospace Engineering,2008,222(4):497-506.
    [8] HEATH S, IMREGUN M. A survey of blade tip-timing measurement techniques for turbomachinery vibration[J]. Journal of Engineering for Gas Turbines and Power, 1998, 120(4):784-791.
    [9] ZIELINSKI M,ZILLER G.Optical blade vibration measurement at MTU[R]. Brüssel, Belgium:AGARD-PEP Symposium on Advanced Non-intrusive Instrumentation for Propulsion Engines,1997.
    [10] RUSSHARD P.Test cell instrumentation and measurement techniques blade tip timing[R]. Shanghai:EMTD Company Limited,2017.
    [11] 段发阶, 李刚, 叶德超, 等. 基于叶尖定时的叶片动应力反演方法[J].纳米技术与精密工程,2016,14(3):161-166. DUAN Fajie,LI Gang,YE Dechao,et al.Method for inversing dynamic stress of blade on tip-timing[J]. Nanotechnology and Precision Engineering,2016,14(3):161-166.(in Chinese)
    [12] 敖春燕, 乔百杰, 刘美茹, 等.基于非接触式测量的旋转叶片动应变重构方法[J].航空动力学报,2020,35(3):569-580. AO Chunyan, QIAO Baijie, LIU Meiru, et al. Dynamic strain reconstruction method of rotating blades based on no-contact measurement[J]. Journal of Aerospace Power, 2020, 35(3):569-580.(in Chinese)
    [13] 刘美茹, 朱靖, 梁恩波, 等.基于叶尖定时的航空发动机压气机叶片振动测量[J].航空动力学报,2019,34(9):1895-1904. LIU Meiru, ZHU Jing, LIANG Enbo, et al. Vibration measurement on compressor rotor blades of aero-engine based on tip-timing[J]. Journal of Aerospace Power, 2019, 34(9):1895-1904.(in Chinese)
    [14] BAQERSAD J, BHARADWAJ K.Strain expansion-reduction approach[J].Mechanical Systems and Signal Processing, 2018,101(8):156-167.
    [15] ILIOPOULOS A,SHIRZADEH R,WEIJTJENS W,et al. A modal decomposition and expansion approach for prediction of dynamic responses on a monopile offshore wind turbine using a limited number of vibration sensors[J].Mechanical Systems and Signal Processing,2016,68/69(7):84-104.
    [16] CHEN Y, LOGAN P, AVITABILE P, et al. Non-model based expansion from limited points to an augmented set of points using chebyshev polynomials[J]. Experimental Techniques,2019,43(5):521-543.
    [17] CHEN Y, AVITABILE P, PAGE C, et al. A polynomial based dynamic expansion and data consistency assessment and modification for cylindrical shell structures[J]. Mechanical Systems and Signal Processing, 2021, 154:107574.1-107574.15.
    [18] 倪振华.振动力学[M].西安:西安交通大学出版社, 1989.
    [19] GUPTA D K, DHINGRA A K. Input load identification from optimally placed strain gages using D-optimal design and model reduction[J].Mechanical Systems and Signal Processing,2013,40(2):556-570.
