刷式密封流动传热特性数值方法

李浩; 孙丹; 赵欢; 张国臣; 冯毓钟

doi:10.13224/j.cnki.jasp.20200446

刷式密封流动传热特性数值方法

doi: 10.13224/j.cnki.jasp.20200446

沈阳航空航天大学辽宁省航空推进系统先进测试技术重点实验室，沈阳110136

基金项目: 国家自然科学基金（52075346，51675351）；中国博士后科学基金（2018M633572）；辽宁省自然科学基金（2019-ZD-0236）

详细信息

作者简介:
李浩（1997-），男，硕士生，主要从事刷式密封摩擦热效应研究。

通讯作者:
孙丹（1981-），男，教授，博士，主要从事透平机械先进密封技术研究。E-mail：phd_sundan@163.com

中图分类号: V233;TK263.2
计量
- 文章访问数: 480
- HTML浏览量: 130
- PDF量: 171
- 被引次数: 0
出版历程
- 收稿日期: 2020-10-24
- 刊出日期: 2021-09-28

Numerical method of flow and heat transfer characteristics of brush seals

Key Laboratory of Advanced Measurement and Test Technique forAviation Propulsion System，Liaoning Province，Shenyang Aerospace University，Shenyang 110136，China

摘要

摘要: 开展了刷式密封流动传热特性数值方法研究，分别建立了刷式密封多孔介质、稳态实体与瞬态流固热耦合求解模型，设计搭建了刷式密封泄漏流动特性实验装置，在实验验证数值方法准确性基础上，对比分析了3种数值方法的差异性，研究了刷式密封流动传热特性，揭示了刷式密封的封严与传热机理。研究结果表明：在研究工况下，刷式密封多孔介质、稳态实体、瞬态流固热耦合模型泄漏量计算值与实验值的对比误差分别为9.8%~17.1%、8.1%~10%、6.92%~9.01%。刷式密封多孔介质模型计算速度较快，但需通过实验修正孔隙率，湍流模型对稳态实体模型流动传热特性结果影响较大，瞬态流固热耦合模型考虑了流场、刷丝及摩擦热三者间相互耦合作用，计算精度较高，但所需计算时间较长；同一压比下刷丝束温度从上游至下游逐渐增加，刷丝束最高温度随压比的增加而增大。气流流经刷丝间隙形成的节流效应致使泄漏气流能量耗散是刷式密封封严的主要原因，泄漏气流与刷丝表面间的对流换热是刷式密封摩擦热耗散的主要形式。
- 刷式密封 /
- 流动传热特性 /
- 多孔介质模型 /
- 稳态实体模型 /
- 瞬态流固热耦合模型
Abstract: Numerical methods for the flow and heat transfer characteristics of brush seals were studied，and the porous media，steady-state solid and transient fluid-solid-heat coupling models of brush seals were established respectively.An experimental device for leakage flow characteristics of brush seals was designed and built.On the basis of verifying the accuracy of the numerical method by experiment，the differences of three numerical methods were compared and analyzed，the flow and heat transfer characteristics of brush seals were studied.The sealing and heat transfer mechanism of brush seals was revealed.The research results showed that：under the working conditions，the error between the leakage calculated by brush seals porous media，steady-state solid and transient fluid-solid-heat coupling model and the experimental values was 9.8%-17.1%，8.1%-10%，6.92%-9.01%，respectively.The calculation speed of brush seals porous media model was faster，but experiment was required for correction of the porosity；the turbulence model had great influence on the flow and heat transfer characteristics of steady-state solid model；the transient fluid-solid-heat coupling model considered the interaction among flow，bristle and frictional heat，and the calculation accuracy was high，but the calculation time was longer.At the same pressure ratio，the temperature of bristle pack gradually increased from upstream to downstream，and the highest temperature of bristle pack increased with the increase of pressure ratio.The main reason for sealing of brush seals was attributable to the throttle effect of air flow through brush wire gap resulting in energy dissipation of leakage air flow，and the convective heat transfer between the leakage gas flow and the brush wire surface was the main form of friction heat dissipation of brush seals.
- brush seals /
- flow and heat transfer characteristics /
- porous media model /
- steady-state solid model /
- transient fluid-solid-thermal coupling model

HTML

参考文献(24)

[1]	CHEW J W,LAPWORTH B L,MILLENER P J.Mathematical modeling of brush seals[J].International Journal of Heat Fluid Flow,1995,16（6）:493-500.
[2]	CHEW J W,HOGG S L.Porosity modeling of brush seals[J].Journal of Tribology,1997,119（10）:769-775.
[3]	CHEW J W,GUARDINO C.Simulation of flow and heat transfer in the tip region of a brush seal[J].International Journal of Heat Fluid Flow,2004,25（4）:649-658．
[4]	DOGU Y.Investigation of brush seal flow characteristics using bulk porous medium approach[J].Journal of Engineering for Gas Turbines and Power,2005,127（1）:136-144.
[5]	DOGU Y,AKSIT M F.Effects of geometry on brush seal pressure and flow fields:Part Ⅰ front plate configurations[J].Journal of Turbomachinery,2006,128（1）:367-378.
[6]	DOGU Y,AKSIT M F.Effects of geometry on brush seal pressure and flow fields:Part Ⅱ backing plate and configurations[J].Journal of Turbomachinery,2006,128（1）:379-389.
[7]	DOGU Y,AKSIT M F.Brush seal temperature distribution analysis[J].Journal of Engineering for Gas Turbines and Power,2006,128（3）:599-609.
[8]	DOGU Y,AKIST M F,DEMIROGLU M,et al.Evaluation of flow behavior for clearance brush seals[J].Journal of Engineering for Gas Turbines and Power,2008,130（1）:1-9.
[9]	邱波,李军.基于多孔介质局部非热平衡方法的刷式密封耦合传热特性[J].航空动力学报,2015,30（5）:1067-1075.
[10]	邱波,李军.刷式密封传热特性研究[J].西安交通大学学报,2011,45（9）:94-100.
[11]	FRANCESCHINI G,JONES T V,GILLESPIE D R H.Improved understanding of blow-down in filament seals[R].ASME Paper GT2008-51197,2008.
[12]	LELLI D,CHEW J W,COOPER P.Combined three dimensional fluid dynamics and mechanical modeling of brush seals[J].Journal of Turbomachinery,2006,128（1）:188-195.
[13]	黄首清,索双富,李永健,等.刷式密封流场和温度场的3维数值计算[J].清华大学学报（自然科学版）,2014,54（6）:805-810.
[14]	孙丹,刘宁宁,胡广阳,等.考虑刷丝变形的刷式密封流场特性与力学特性流固耦合研究[J].航空动力学报,2016,31（10）:2544-2553.
[15]	李国勤,孙丹,刘永泉,等.基于ALE流固耦合方法的刷式密封泄漏特性理论与实验研究[J].推进技术,2020,41（8）:1850-1860.
[16]	邱波,李军,陈春新,等.基于CFD和FEM方法的刷式密封传热特性研究[J].工程热物理学报,2012,33（12）:2067-2071.
[17]	马登骞,张元桥,李军,等.考虑刷丝变形的后夹板结构对刷式密封泄漏和传热特性影响的研究[J].西安交通大学学报,2019,53（9）:15-25.
[18]	LI Jun,QIU Bo,FENG Zhenping.Experimental and numerical investigations on the leakage flow characteristics of the labyrinth brush seal[J].Journal of Engineering,2012,134（10）:102509.1-102509.9.
[19]	刘伟,范爱武,黄晓明.多孔介质传热传质理论与应用[M].北京:科学出版社,2006.
[20]	YAKHOT V.Renormalization group analysis of turbulence:Ⅰbasic theory[J].Journal of Scientific Computing,1986,1（1）:3-51.
[21]	孙丹,李国勤,艾延廷,等.基于三维实体建模的刷式密封传热机理数值研究[J].航空动力学报,2019,34（8）:1633-1643.
[22]	BERGMAN T L,LAVINE A S,INCROPERA F P,et al.Introduction to heat transfer[M].Hoboken,US:John Wiley & Sons,2011.
[23]	张雄,王天舒,刘岩.计算动力学[M].2版.北京:清华大学出版社,2015.
[24]	孟繁超,董素君,江鸿升,等.长时间流固耦合传热过程的快速算法[J].北京航空航天大学学报,2017,43（6）:1224-1230.
